DirectOut Technologies ANDIAMO.AES Installation instructions

ANDIAMO.AES (SRC)

Hardware Guide

Version 2.0

page 2 of 48

ANDIAMO.AES (SRC) Hardware Guide - Version 2.0

graphic in whole or in part for any reason is expressly prohibited, unless prior written

consent is obtained from the DirectOut GmbH.

All trademarks and registered trademarks belong to their respective owners. It cannot

be guaranteed that all product names, products, trademarks, requisitions, regulations,

guidelines, speciﬁcations and norms are free from trade mark rights of third parties.

All entries in this document have been thoroughly checked; however no guarantee for

correctness can be given.

DirectOut GmbH cannot be held responsible for any misleading or incorrect

information provided throughout this manual.

DirectOut GmbH reserves the right to change speciﬁcations at any time without notice.

DirectOut Technologies® is a registered trademark of the DirectOut GmbH.

page 3 of 48

ANDIAMO.AES (SRC) Hardware Guide - Version 2.0

Table of contents

About This Document 5

How to Use This Document.......................................................................... 5

Conventions .................................................................................................. 5

CHAPTER 1: Overview 6

Introduction ................................................................................................... 6

Feature Summary.......................................................................................... 7

Applications................................................................................................... 7

CHAPTER 2: Legal issues & facts 8

Before Installing This Device......................................................................... 8

Defective Parts/Modules ............................................................................. 8

First Aid (in case of electric shock)................................................................ 9

Updates ....................................................................................................... 10

Conditions of Warranty ............................................................................... 10

Intended Operation .................................................................................... 10

Conformity & Certiﬁcates ........................................................................... 11

Contact........................................................................................................ 11

Contents...................................................................................................... 12

Accessories................................................................................................. 13

CHAPTER 3: Installation 15

Installing the Device .................................................................................... 15

CHAPTER 4: Operation 20

Introduction ................................................................................................. 20

Global Control.............................................................................................. 21

Menu Control .............................................................................................. 22

Clocking....................................................................................................... 24

Sample Rates .............................................................................................. 28

Output Format............................................................................................. 29

User Bit Routing .......................................................................................... 30

Level Meters - digital I/O ............................................................................. 31

Signal Routing ............................................................................................. 32

Connecting MADI ....................................................................................... 35

Connecting Word clock ............................................................................... 36

Connecting USB.......................................................................................... 36

Connecting AES3 ........................................................................................ 37

CHAPTER 5: Menu Navigation 38

Signal Routing ............................................................................................. 38

System Settings .......................................................................................... 39

CHAPTER 6: Troubleshooting and Maintenance 41

Troubleshooting........................................................................................... 41

Maintenance................................................................................................ 41

page 4 of 48

ANDIAMO.AES (SRC) Hardware Guide - Version 2.0

CHAPTER 7: Technical Data 42

Appendix A - DSUB-25 Pin assignment 44

Index 45

page 5 of 48

ANDIAMO.AES (SRC) Hardware Guide - Version 2.0

About This Document

How to Use This Document

This document guides you through the installation and operation of the device. For

information about the graphical user interface (GUI) please consult the ofﬂine help

available from our website or use the online help within the gui.

Use the Table of Contents at the beginning of the manual or Index Directory at the

end of the document to locate help on a particular topic. You can access more

information and latest news by visiting on the DirectOut website at

www.directout.eu.

Conventions

The following symbols are used to draw your attention to:

TIPS!

indicate useful hints and shortcuts.

NOTES!

are used for important points of clariﬁcation or cross references.

WARNINGS!

alert you when an action should always be observed.

This document relates to:

• ANDIAMO.AES - ﬁrmware version 2.7

• ANDIAMO.AES SRC - ﬁrmware version 2.7

The front panel of the two versions differs and the related sections are marked

accordingly.

page 6 of 48 ANDIAMO.AES (SRC) Hardware Guide - Version 2.0

CHAPTER 1: Overview

Introduction

The ANDIAMO.AES is a 64-channel AES3/MADI interface with a built-in routing

matrix. It provides two MADI inputs and outputs, 32 AES3 inputs and outputs for

bi-directional conversion of 64 audio-channels between AES3 and MADI.

With two RU height and two redundant power supplies the device offers best and

safe audio quality at a minimal need of rackspace.

The ﬁrst 16 AES inputs of the SRC version are equipped with sample rate

converters - switchable in groups of eight channels to handle asynchronous

signals.

page 7 of 48

ANDIAMO.AES (SRC) Hardware Guide - Version 2.0

CHAPTER 1: Overview

Feature Summary

MADI Ports 2 x SC-Socket multi/single-mode (SC/SC)

1 x SC-Socket multi/single-mode &

1 x coaxial BNC connector, 75 Ω (BNC/SC)

MADI Formats 56/64 channel, 48k/96k Frame, S/MUX 2/4

AES Ports 32 x AES3 input and output via DSUB-25,

AES59 compliant

Sample Rate Converter 16 x stereo on AES3 inputs (SRC version)

Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz ±12.5%

Clock Inputs 1 x Word clock, coaxial BNC,

75 Ω termination switchable,

This input also accepts an AES3 frame (AES11).

Clock Outputs 1 x Word clock, coaxial BNC

USB Port USB 2.0 port for ﬁrmware updates and remote

control

Routing Matrix Signal routing on a per channel basis

192x192 routing matrix.

Remote Control Software Remote control via USB, Serial over MADI,

MIDI over MADI or DO.Net

Power Supply This device is equipped with two wide range power

supplies (84 V to 264 V AC / 47 Hz to 63 Hz / safety

class 1)

Applications

ANDIAMO.AES (SRC) can be used for conversion, distribution and routing of digital

signals.

Typical applications include:

• signal routing / distribution (192 x 192 cross points)

• conversion from / to AES to / from MADI

• integration of asynchronous AES signals [AES SRC]

• format conversion of MADI signals

• ...

page 8 of 48

ANDIAMO.AES (SRC) Hardware Guide - Version 2.0

CHAPTER 2: Legal issues & facts

Before Installing This Device

WARNING!

Please read and observe all of the following notes before installing

this product:

• Check the hardware device for transport damage.

• Any devices showing signs of mechanical damage or damage from the

spillage of liquids must not be connected to the mains supply, or

disconnected from the mains immediately by pulling out the power lead.

• All devices must be grounded. The device is grounded through its

IEC power connections.

• All devices must be connected to the mains using the three-cord power

leads supplied with the system. Only supply electrical interfaces with the

voltages and signals described in these instructions.

• Do not use the device at extreme temperatures. Proper operation can

only be guaranteed between temperatures of 5ºC and 45ºC and a

maximum relative humidity of 80%, non-condensing.

• The cabinet of the device will heat up. Do not place the device close

to heating sources (e.g. heaters). Observe the environmental conditions.

Defective Parts/Modules

WARNING!

This device contains no user-serviceable parts. Therefore do not open the device.

In the event of a hardware defect, please send the device to your DirectOut

representative together with a detailed description of the fault.

We would like to remind you to please check carefully whether the failure is

caused by erroneous conﬁguration, operation or connection before sending parts

for repair.

page 9 of 48

ANDIAMO.AES (SRC) Hardware Guide - Version 2.0

CHAPTER 2: Legal issues & facts

First Aid (in case of electric shock)

WARNING!

• Do not touch the person or his/her clothing before power is turned off,

otherwise you risk sustaining an electric shock yourself.

• Separate the person as quickly as possible from the electric power source

as follows:

- Switch off the equipment.

- Unplug or disconnect the mains cable.

• Move the person away from the power source by using dry insulating

material (such as wood or plastic).

• If the person is unconscious:

- Check their pulse and reanimate if their respiration is poor.

- Lay the body down and turn it to one side. Call for a doctor immediately.

• Having sustained an electric shock, always consult a doctor.

page 10 of 48

ANDIAMO.AES (SRC) Hardware Guide - Version 2.0

CHAPTER 2: Legal issues & facts

Updates

DirectOut products are continually in development, and therefore the information

in this manual may be superseded by new releases. To access the latest

documentation, please visit the DirectOut website:

www.directout.eu.

WARNING!

No compensation can be claimed for damages caused by operation of this unit

other than for the intended use described above. Consecutive damages are also

excluded explicitly. The general terms and conditions of business of DirectOut

GmbH are applied.

Conditions of Warranty

This unit has been designed and examined carefully by the manufacturer and

complies with actual norms and directives.

Warranty is granted by DirectOut GmbH over the period of two years for all

components that are essential for proper and intended operation of the device. The

date of purchase is applied for this period.

Consumable parts (e.g. battery) are excluded from warranty claims.

WARNING!

All claims of warranty will expire once the device has been opened or modiﬁed, or

if instructions and warnings were ignored.

For warranty claims please contact the dealer where your device was acquired.

This guide refers to ﬁrmware version 2.7

Intended Operation

The ANDIAMO.AES (SRC) is designed for conversion of audio signals from digital

to digital. In this context digital audio refers to a MADI signal (AES10) and AES

signal (AES3).
