Directed Audio COMP-X 5158 User manual
COMP-X
5108
SEALED BOX ONE DRIVER
NORMAL
LOADING
BOX SEALED
SIZE Q FB F3 HUMP NOTE
0.125 1.157 90.76 67.51 15.14
0.250 0.876 68.65 57.89 10.29
0.375 0.759 59.49 55.72 7.45
0.500 0.693 54.33 55.47 5.43
0.625 0.650 50.99 55.83 3.87
0.750 0.620 48.63 56.37 2.60
0.875
1.000
1.125
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET, PORTS IN INCHES AND FREQUENCIE
S
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
DIRECTED
COMP-X
5108
SEALED BOX TWO DIRVER
NORMAL
LOADING
BOX SEALED
SIZE Q FB F3 HUMP NOTE
0.125
0.250 1.157 90.76 67.51 15.14
0.375 0.979 76.73 60.92 12.30
0.500 0.876 68.65 57.89 10.29
0.625 0.807 63.31 56.41 8.72
0.750 0.759 59.49 55.72 7.45
0.875 0.722 56.60 55.47 6.37
1.000 0.693 54.33 55.47 5.43
1.125 0.670 52.50 55.61 4.61
1.250 0.650 50.99 55.83 3.87
1.375 0.634 49.71 56.09 3.21
1.500 0.620 48.63 56.37 2.60
1.625 0.608 47.69 56.66 2.04
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET, PORTS IN INCHES AND FREQUENCIE
S
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
DIRECTED
COMP-X
5108
SEALED BOX TWO DRIVER
ISOBARIC
LOADING
BOX SEALED
SIZE Q FB F3 HUMP NOTE
0.125 0.876 68.65 57.89 10.29
0.250 0.693 54.33 55.47 5.43
0.375 0.620 48.63 56.37 2.60
0.500
0.625
0.750
0.875
1.000
1.125
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET, PORTS IN INCHES AND FREQUENCIE
S
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
DIRECTED
COMP-X
5128
SEALED BOX ONE DIRVER
NORMAL
LOADING
BOX SEALED
SIZE Q FB F3 HUMP NOTE
0.125 0.935 96.33 78.26 9.52
0.250 0.686 70.70 72.95 4.66
0.375 0.580 59.77 75.59 1.83
0.500
0.625
0.750
0.875
1.000
1.125
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET, PORTS IN INCHES AND FREQUENCIE
S
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
DIRECTED
COMP-X
5128
SEALED BOX TWO DRIVER
NORMAL
LOADING
BOX SEALED
SIZE Q FB F3 HUMP NOTE
0.125
0.250 0.935 96.33 78.26 9.52
0.375 0.778 80.16 73.54 6.68
0.500 0.686 70.70 72.95 4.66
0.625 0.624 64.36 73.99 3.10
0.750 0.580 59.77 75.59 1.83
0.875
1.000
1.125
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET, PORTS IN INCHES AND FREQUENCIE
S
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
DIRECTED
COMP-X
5128
SEALED BOX TWO DRIVER
ISOBARIC
LOADING
BOX SEALED
SIZE Q FB F3 HUMP NOTE
0.125 0.686 70.70 72.95 4.66
0.250 0.519 53.47 78.87 -0.19
0.375
0.500
0.625
0.750
0.875
1.000
1.125
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET, PORTS IN INCHES AND FREQUENCIE
S
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
DIRECTED
COMP-X
5158
SEALED BOX ONE DRIVER
NORMAL
LOADING
BOX SEALED
SIZE Q FB F3 HUMP NOTE
0.125
0.250 1.148 110.13 82.14 12.79
0.375 0.950 91.15 73.42 9.95
0.500 0.834 80.00 69.63 7.94
0.625 0.756 72.48 68.13 6.37
0.750 0.699 67.01 67.84 5.10
0.875 0.655 62.80 68.23 4.02
1.000 0.620 59.46 68.98 3.08
1.125 0.591 56.72 69.90 2.26
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET, PORTS IN INCHES AND FREQUENCIE
S
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
DIRECTED
COMP-X
5158
SEALED BOX TWO DRIVER
NORMAL
LOADING
BOX SEALED
SIZE Q FB F3 HUMP NOTE
0.125
0.250
0.375
0.500 1.148 110.13 82.14 12.79
0.625 1.034 99.18 76.86 11.23
0.750 0.950 91.15 73.42 9.95
0.875 0.886 84.96 71.14 8.87
1.000 0.834 80.00 69.63 7.94
1.125 0.791 75.91 68.68 7.11
1.250 0.756 72.48 68.13 6.37
1.375 0.725 69.55 67.87 5.71
1.500 0.699 67.01 67.84 5.10
1.625 0.675 64.78 67.97 4.54
1.750 0.655 62.80 68.23 4.02
1.875 0.636 61.04 68.57 3.54
2.000 0.620 59.46 68.98 3.08
2.125 0.605 58.02 69.43 2.66
2.250 0.591 56.72 69.90 2.26
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET, PORTS IN INCHES AND FREQUENCIE
S
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
DIRECTED
COMP-X
5158
SEALED BOX TWO DRIVER
ISOBARIC
LOADING
BOX SEALED
SIZE Q FB F3 HUMP NOTE
0.125 1.148 110.13 82.14 12.79
0.250 0.834 80.00 69.63 7.94
0.375 0.699 67.01 67.84 5.10
0.500 0.620 59.46 68.98 3.08
0.625 0.567 54.43 70.88 1.52
0.750
0.875
1.000
1.125
1.250
1.375
1.500
1.625
1.750
1.875
2.000
2.125
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET, PORTS IN INCHES AND FREQUENCIE
S
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
DIRECTED
COMP-X
5108
VENTED BOX ONE DRIVER
NORMAL
LOADING
BO
X
VENTED PORT DIA.
SIZE FB F3 RPL 2 2.5 3 3.5 456810
0.125 60.95 83.94 6.31 16.62
0.250 48.82 59.36 4.29 12.63
0.375 42.88 48.46 3.11 10.72 17.20
0.500 39.11 41.97 2.27 9.52 15.33
0.625 36.42 37.54 1.62 8.67 14.00
0.750 34.35 34.27 1.08 8.03 13.00 19.16
0.875 32.70 31.73 0.63 7.51 12.20 18.00
1.000 31.33 29.68 0.24 7.09 11.54 17.06
1.125 30.17 27.98 -0.10 6.74 10.98 16.26
1.250 29.17 26.54 -0.41 6.43 10.51 15.57
1.375 28.30 25.31 -0.69 6.17 10.09 14.97
1.500 27.52 24.23 -0.94 5.93 9.72 14.44
1.625 26.82 23.28 -1.17 5.72 9.40 13.97
1.750 26.19 22.43 -1.39 5.53 9.10 13.54
1.875 25.62 21.67 -1.59 5.36 8.83 13.16
2.000 25.10 20.99 -1.78 5.20 8.59 12.80
2.125 24.62 20.36 -1.96 5.06 8.36 12.48
2.250
2.375
2.500
2.625
2.750
2.875
3.000
3.125
3.250
3.375
3.500
3.625
3.750
3.875
4.000
4.125
4.250
4.375
4.500
4.625
4.750
4.875
5.000
NOTE: ALL BOXES ARE IN CUBIC FEET, PORTS IN INCHES AND FREQUENCIES IN HERTZ.
ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
© Copyright 2001 by Directed Electronics, Inc. All rights reserved
DIRECTED
