Dini Argeo DGT4X User manual

www.diniargeo.com
DGT4X
Digital weight transmitter with 4 channels
ENGLISH
TECHNICAL MANUAL_V1


3
Optimized layout for A4 print.
TECH_MAN_ENG_DGT4X
Contents
Introduction 7
Transmitter installation 8
Installation requirements 8
Electrical precautions 9
Earthing of the system 11
Technical features 14
Load cell installation 15
Wiring diagrams 16
DGT4X 16
DGT4XAN 17
DGT4XPB 18
DGT4XETHIP, DGT4XETHCAT, DGT4XPRONET, DGT4XMODTCP 19
DGT4XCANOP 20
DGT4XDEVNET 21
Display and function of the keys 22
Quick menu 22
Advanced programming menu 23
Access to the advanced menu and saving the changes 23
Function of the keys in the menu 23
Block diagram of the menu 24
Mode of use of the DGT4X 26
Theoretical calibration 27
Dependent channels 27
Theoretical calibration 28
Independent channels 28
Calibration with sample weights 29
Dependent channels (with digital equalisation) 29
Independent channels 31
Equalisation 33

4
Optimized layout for A4 print.
TECH_MAN_ENG_DGT4X
Manual calibration 34
Quick zero calibration (pre-tare reset) 34
Filter and stability 35
Filter adjustment 35
Stability detection sensitivity 35
Gravity 36
Reset functions and parameters 37
Auto-zeroing on start-up 37
Maximum percentage of manual zeroing 37
Zero tracking 37
Restoring zero 38
Semi-automatic zeroing 38
Tare functions and parameters 38
Tare mode 38
Semi-automatic tare 38
Predetermined tare 39
Clearing the tare 39
Restoring the tare 39
Alibi memory 40
Enabling the alibi memory 40
Saving a weighing operation in the alibi memory 40
Reading the alibi memory 41
Initialising the alibi memory 41
Use functions 42
High resolution 42
Peak detection 42
Converting units of measurement 42
Alibi memory 42
No function 42
Input configuration 43
Output configuration 44
Analog output configuration 45

5
Optimized layout for A4 print.
TECH_MAN_ENG_DGT4X
Serial communication configuration 47
Selection of the PC serial port 47
Configuration of the printer port (COM.PRN) 48
Transmission mode 48
Baud rate, parity, data bits, stop bits 49
Printer power on mode 49
CTS signal 49
Print language 49
Reactivation of printing 50
Configuration of the PC port (COM.PC) 50
Transmission mode 50
Baud rate, parity, data bits, stop bits 51
USB port 51
Configuration of the USB port 51
Communication protocols 52
Standard string 52
Extended string 52
Multi-scale string 53
Serial commands 54
Modbus Protocol 57
Diagnostics 60
Cells / converter test 60
Firmware release 60
Serial number 60
Display 60
Keypad 60
Serial ports 61
CTS signal 61
Inputs 61
Outputs 61
Analog output (mod. DGT4XAN) 61
Programming the Setpoints 61
Restoring factory settings 62
Date and time setting 62
Alarms 63

7
Optimized layout for A4 print.
TECH_MAN_ENG_DGT4X
Dear Customer,
Thank you for purchasing a DINI ARGEO product.
This manual contains all the instructions for a correct installation and commissioning of the DGT4X 4-channel digital weight transmitter.
While thanking you for purchasing this product, we would like to draw your attention to some aspects of this manual.
This booklet provides useful information for the correct operation and maintenance of the scale to which it refers;
it is therefore essential to pay the greatest attention to all those paragraphs that illustrate the simplest and safest way to operate.
It is recommended that you carefully follow the instructions for programming the weight transmitter; performing actions not indicated in
this manual could compromise the proper functioning of the scale.
The utmost care has been taken in compiling this manual, but reports of any inaccuracies are always welcome.
The transmitter is covered by warranty and MUST NOT BE TAMPERED WITH BY THE USER under any circumstances.
Any attempt at repair or modification may expose the user to the danger of electric shock and voids any warranty conditions, relieving
the Manufacturer from all liability.
Any problem with the product must be reported to the manufacturer or to the retailer where it was purchased.
In any case, always TURN OFF THE POWER SUPPLY before any installation or repair operation.
Introduction

8
Optimized layout for A4 print.
TECH_MAN_ENG_DGT4X
Transmitter installation
Installation requirements
Observe the following conditions for correct installation of the transmitter and of the load receiver:
• Flat, level support surface.
• Stability and absence of vibrations.
• Absence of aggressive dusts and vapours.
• Absence of draughts.
• Make sure that the platform is levelled or that the load cells are evenly supported.
• Moderate temperature and humidity (15°C - 30°C and 40% - 70%).
• Do not install in an environment where there is a risk of explosion.
• All transmitter connections must be made in accordance with applicable regulations in the area and environment of installation.
Observe the electrical precautions listed in the section “Electrical precautions”.
• Ensure that it is correctly earthed, see the relevant section “Earthing of the system”.
• Do not perform welding when the load cells have already been installed.
• If necessary, use watertight sheaths and fittings to protect the load cell cables.
• Any junction boxes must be watertight.
• Anything not expressly described in this manual constitutes improper use of the equipment.

9
Optimized layout for A4 print.
TECH_MAN_ENG_DGT4X
Electrical precautions
• Use a regulated mains supply within ± 10% of the rated voltage.
• The electrical protections (fuses, etc.) are the responsibility of the installer.
• Observe the recommended minimum distances between cables of dierent categories (see table on page 10).
• The following cables must comply with the maximum permissible lengths (see table on page 10), they must be shielded and must
beinserted alone in metal conduits or pipes:
- the load cell extension cables;
- the signal amplifier cables;
- the cables for connecting the serial ports;
- the analog output cables.
• The cell or amplifier cables must have an independent input in the electrical panel. They must be connected (if possible) directly to
the terminal block of the transmitter without passing through the conduit with other cables.
• Fit “RC” filters:
- on the contactor coils;
- on the solenoid valve coils;
- on all devices that produce electrical interference.
• If condensation can occur inside the weight transmitter, it is advisable to keep the equipment powered at all times.
• Connections to load cells and any external device must be as short as possible.
• The cable ends (connectors, leads, terminals, etc.) must be installed correctly; the cable shielding must be kept intact until close to
the connection point.
• If the transmitter is placed inside an electrical panel, a shielded cable must also be used for the power supply.

10
Optimized layout for A4 print.
TECH_MAN_ENG_DGT4X
Category I Category II Category III Category IV
Distance
≥ 100 mm
≥ 200 mm
≥ 500 mm
≥ 100 mm
≥ 500 mm
≥ 500 mm
Classification
Fieldbus, LAN network
(PROFIBUS, Ethernet,
Devicenet...).
Shielded data cables
(RS232...).
Shielded cables for
analog digital signals
< 25 V (sensors, load
cells...).
Low voltage power sup-
ply cables (< 60 V).
Coaxial cables.
DC supply cables with
voltage > 60 V and <
400 V.
AC supply cables with
voltage > 25 V and <
400 V.
Power supply cables
with voltage > 400 V.
Telephone cables.
Any cable subject to
lightning danger.
Load cell RS232 RS485 Analog output
50 metres with
6 x 0.25 mm2cable;
100 metres with
6 x 0.5 mm2cable.
15 m with baud rate up to
19200.
1200 m with shielded 2 x
24 AWG twisted pair with
outer braid + aluminium
strip.
CURRENT:
100 metres with 2 x 0.25 mm2cable;
150 metres with 2 x 0.5 mm2cable;
300 metres with 2 x 1 mm2cable.
VOLTAGE:
50 metres with 2 x 0.25 mm2cable;
75 metres with 2 x 0.5 mm2cable;
150 metres with 2 x 1 mm2cable.
RECOMMENDED DISTANCES AND CABLE CLASSIFICATION
MAXIMUM ALLOWED LENGTHS
