Dimplex SIL48 User manual

Owner’s Manual

CONSUMER SAFETY INFORMATION: PLEASE READ THIS MANUAL BEFORE INSTALLING AND

OPERATING THIS APPLIANCE. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN A

POSSIBLE ELECTRIC SHOCK, FIRE HAZARD, AND/OR INJURY AND WILL VOID THE WARRANTY.

To view the full line of Dimplex products, visit www.dimplex.com

7215870100R03

Share the warmth and leave a review.

dimplex.com/sharethewarmth

Models

SIL48

SIL48M

SIL60

SIL60M

SIL72

SIL96

Your input helps to create even better

products and experiences.

We value your feedback!

Table of Contents

Conventions used in this manual:

!NOTE: Procedures and techniques considered important enough to emphasize.

CAUTION: Procedures and techniques which, if not carefully followed, will result in

damage to the equipment.

WARNING: Procedures and techniques which, if not carefully followed, will expose the

user to the risk of ﬁre, serious injury, or death.

Welcome..............................................................3

IMPORTANT INSTRUCTIONS ..............................4

Speciﬁcations.......................................................6

Installation ............................................................7

Operation ...........................................................16

Maintenance ......................................................19

Troubleshooting..................................................21

Technical Support...............................................21

Warranty.............................................................22

Welcome

Please use our convenient online registration page to record your model and serial

numbers for future reference at:

www.dimplex.com/register

CAUTION: Read all instructions and warnings carefully before starting installation.

Failure to follow these instructions may result in a possible electric shock or ﬁre hazard

and will void the warranty.

Serial Number

Model Number

PRECAUCION

ATTENTION

CAUTION

XXXXX

XXXXXXXXXX

AIR HEATER

CHAUFFE-AIR

CALENTADOR DE AIRE

WATTS

VATIOS

VOLTS

VOLTIOS

CAT. #

№ DE CAT.

CAT. NO.

CSA #

SERIAL NO. / № DE SÉRIE /№ DE SERIE:

MADE IN CHINA FOR: / FAIT EN CHINE POUR:

HECHO EN CHINA POR:

NO NEED TO RETURN TO THE STORE

Questions with operation or assembly? Require Parts Information?

Product Under Manufacturer’s Warranty?

For Troubleshooting and Technical Support

OR Toll-Free 1-888-346-7539

In order to better serve you, please have your model and serial numbers

ready or register your product online before calling (see above).

Read this manual before attempting

to install or use the electric fireplace.

Always comply with the warnings and

safety instructions contained in this

manual to prevent personal injury or

property damage.

When using electrical appliances, basic

precautions should always be followed

to reduce the risk of fire, electric shock

and injury to persons, including the

following:

• This appliance is hot when in use. To

avoid burns, do not let skin touch hot

surfaces. Keep combustible materials,

such as furniture, pillows, bedding,

papers, clothes and curtains at least 3

ft. from the front of this appliance and

keep away from sides and rear.

• Extreme caution is necessary when

any heater is used by, or near, children

or invalids, and whenever the heater is

left operating and unattended.

• Do not operate any heater with a

damaged cord or plug, after the

appliance malfunctions, or if it has

been dropped or damaged in any

manner. Disconnect from power

and call Technical Service or have it

inspected by a qualified electrician.

• To disconnect the fireplace, turn the

controls off, then remove the plug from

the outlet.

• Do not use outdoors.

• Do not insert or allow foreign objects

IMPORTANT INSTRUCTIONS

to enter any ventilation or exhaust

opening as this may cause an electric

shock, fire, or damage the fireplace.

• All electrical heaters have hot, and

arcing, or sparking parts inside. Do not

use it in areas where gasoline, paint or

flammable liquids are used or stored.

• Use this appliance only as described

in the manual. Any other use not

recommended by the manufacturer

may cause fire, electric shock or injury

to persons.

• If possible, always unplug this

appliance when not in use.

• Any repairs to this fireplace should

be carried out by a qualified service

person.

• Under no circumstances should this

fireplace be modified. Parts that have

to be removed for servicing must

be replaced prior to operating this

fireplace again.

• This heater is not intended for use in

bathrooms, laundry areas and similar

indoor locations. Never place the

heater where it may fall into a bathtub

or other water containers.

• Always connect to properly grounded

outlets.

• Do not run cord under carpeting.

Do not cover cord with throw rugs,

runners or the like. Arrange the cord

away from heavily trafficked areas,

where it will not be tripped over.

SAVE THESE INSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

NO USER-SERVICEABLE PARTS INSIDE

• Always plug heaters directly into a wall

outlet/receptacle. Never use with an

extension cord or a relocatable power

tap (outlet/power strip).

• To prevent a possible fire, do not block

air intakes or exhaust in any manner.

Do not use on soft surfaces, like bed,

where opening may become blocked.

• There is a resettable cutout switch

inside the heater. Should the heater

overheat, the cutout will turn the

fireplace heater off. To reset the cutout

switch unplug the unit and wait 5

minutes before plugging it back in.

Caution: If you need to continuously

reset the cutout, unplug the unit and

call Technical Support.

• Remote control contains a small

battery. Keep away from children. If

swallowed, seek medical attention

immediately.

IMPORTANT INSTRUCTIONS

FCC Compliance

CAUTION: This equipment has been

tested and found to comply with the limits for

Class B digital devices, pursuant to part 15

of the FCC rules. These limits are designed to

provide reasonable protection against harmful

interference in a residential installation. The

equipment generates, uses and can radiate

radio frequency energy and, if not installed

and used in accordance with the instructions,

may cause harmful interference to radio or

television reception, which can be determined

by turning the equipment off and on. The

user is encouraged to try and correct the

interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the

equipment and the receiver

• Connect the equipment into an outlet on

a circuit different from that to which the

receiver is connected

• Consult the dealer or an experienced radio/

TV technician for help

This device complies with Part 15 of the FCC

rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful

interference, and

2. This device must accept any interference

received, including interference that may

cause undesired operation.

Modifications not approved by the party

responsible for compliance could void user’s

authority to operate the equipment. This

Class B digital apparatus complies with

Canadian ICES-003.

Speciﬁcations

Electrical

Voltage: 120VAC 60Hz

Watts: 1400 Watts

Amps: 12 A

Wiring: Plug-In

Bulb Type: LED

Approvals:

Dimensions

SIL48/SIL48M

Width: 41-1/4" (104.6 cm)

Height: 18-1/8" (46.0 cm)

Height with feet: 21-1/2" (54.7 cm)

Depth: 5-1/4" (13.3 cm)

Depth with feet: 11" (27.9 cm)

Weight

40.8 lbs (18.5 kg)

SIL60/SIL60M

Width: 51-7/8" (131.8 cm)

Height: 18-1/8" (46.0 cm)

Height with feet: 21-1/2" (54.7 cm)

Depth: 5-1/4" (13.3 cm)

Depth with feet: 11" (27.9 cm)

Weight

63.5 lbs (28.9 kg)

SIL72

Width: 64" (162.6 cm)

Height: 18-1/8" (46.0 cm)

Height with feet: 21-1/2" (54.7 cm)

Depth: 5-1/4" (13.3 cm)

Depth with feet: 11" (27.9 cm)

Weight

77.8 lbs (35.3 kg)

SIL96

Width: 96" (243.4 cm)

Height: 18-1/8" (46.0 cm)

Height with feet: 21-1/2" (54.7 cm)

Depth: 5-1/4" (13.3 cm)

Depth with feet: 11" (27.9 cm)

Weight

105.8 lbs (48 kg)

Installation

GROUNDING INSTRUCTIONS

• This product is equipped with a cord that has an

equipment-grounding conductor and a grounding

plug. The plug must be plugged into an appropriate

outlet that is properly installed and grounded in

accordance with all local codes and ordinances.

• This heater is for use on 120 volts. The cord has a

plug as shown.

• A 15 Amp, 120 Volt circuit is required. A dedicated circuit is preferred,

but not essential in all cases. A dedicated circuit will be required if,

after installation, the circuit breaker trips or the fuse blows on a

regular basis when the heater is operating. Additional appliances

on the same circuit may exceed the current rating of the circuit breaker.

WARNING: Electrical outlet wiring must comply with local building codes and other

applicable regulations to reduce the risk of fire, electric shock, or injury to persons.

Grounding

Package Contents

Tools required

G H

Installation

IN-WALL INSTALLATION

Model A B C

Sierra 48 - SIL48 41.6 / 105.7 6.5 / 16.5 18.5 / 47.0

Sierra 60 - SIL60 52.4 / 133.1 6.5 / 16.5 18.5 / 47.0

Sierra 72 - SIL72 64.4 / 163.6 6.5 / 16.5 18.5 / 47.0

Sierra 96 - SIL96 88.4 / 224.5 6.5 / 16.5 18.5 / 47.0

Cabinet - in / cm

Model D E F

Sierra 48 - SIL48 41.2 / 104.6 4.7 / 11.9 18.1 / 46.0

Sierra 60 - SIL60 51.9 / 131.8 4.7 / 11.9 18.1 / 46.0

Sierra 72 - SIL72 64.0 / 162.6 4.7 / 11.9 18.1 / 46.0

Sierra 96 - SIL96 88.0 / 223.5 4.7 / 11.9 18.1 / 46.0

Firebox - in / cm

Installation

IN-WALL INSTALLATION

Other manuals for SIL48

This manual suits for next models

Table of contents

Other Dimplex Indoor Fireplace manuals

Dimplex

Dimplex Prism 50 User manual

Dimplex

Dimplex XLF5017-XD User manual

Dimplex

Dimplex DF3033ST User manual

Dimplex

Dimplex CAS500R User manual

Dimplex

Dimplex ASP20 User manual

Dimplex

Dimplex MIDI FIRE MIDI32B User manual

Dimplex

Dimplex Vivente VVT775 Instruction Manual

Dimplex

Dimplex RBF30-AU User manual

Dimplex

Dimplex CDFI1000P User manual

Dimplex

Dimplex RLG20 User manual

Dimplex

Dimplex THWG XLF50 User manual

Dimplex

Dimplex Revillusion Haydn User manual

Dimplex

Dimplex Revillusion RBF30WC User manual

Dimplex

Dimplex DFOP25 User manual

Dimplex

Dimplex XHD26L User manual

Dimplex

Dimplex Ignite XLF50 User manual

Dimplex

Dimplex DFR2551G User manual

Dimplex

Dimplex FABER ALBANY ECO ABN15 ECO User manual

Dimplex

Dimplex Cassette L Pebble User manual

Dimplex

Dimplex WYN20 User manual

Dimplex

Dimplex DFP15-1134NG User manual

Dimplex

Dimplex Nardini NDN20 User manual

Dimplex

Dimplex 6908760100 User manual

Dimplex

Dimplex DIMPLEX ELECTRIC FIREPLACE User manual

Popular Indoor Fireplace manuals by other brands

Brigantia

Brigantia 35-DVRS31N-2 User's installation, operation and maintenance manual

Nordpeis

Nordpeis Bergen Installation and user manual

Superior

Superior BCT2536TMN Installation and operation instructions

Quadra-Fire

Quadra-Fire 5100I-GD-B owner's manual

Renaissance

Renaissance RUMFORD 1000 user manual

Lacunza

Lacunza IV-800 Instruction book

Baxi

Baxi 940 Installer and owner guide

Dru

Dru Maestro 60/2 Tall RCH installation manual

Diamond Fireglass

Diamond Fireglass SS-O22 General assembly, installation, and operation instructions

HearthStone

HearthStone Windsor Bay 8830 Owner's manual and installation guide

Napoleon

Napoleon ASCENT B42 quick start guide

Enviro

Enviro E33GI owner's manual

Smeg

Smeg L30 FABE Installation & user's instructions

KEDDY

KEDDY K700 Installation instructions care and firing instructions

Godin

Godin 3451 manual

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Installation and operation instructions

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 operating manual

Desa

Desa CCFPDFT Owner's operating & installation manual
