Dimplex XLS User manual



ContactDetails



Pleasenotethatsomeofthecontactdetailson

thisPDFdocumentmaynotbecurrent.



Pleaseusethefollowingdetailsifyouneedto

contactus:



Telephone:08448793588

Email:[email protected]



Thecustomersupportsectionofourwebsitealsofeaturesawide

rangeofinformationwhichmaybeofusetoyouandisavailable

24hoursaday.Itincludes:



•Operatingandinstallationinstructions

•Easy‘Howtouse’guidesforstorageheaters

•Serviceandrepairs

•Wheretobuyourproducts

•Literaturedownloads

•Heatingrequirementcalculator



Visit‐www.dimplex.co.uk/support

A division of GDC Group Ltd

Millbrook House Grange Drive Hedge End Southampton SO30 2DF

www.dimplex.co.uk

istered No: 1313016 En

land

VAT GB 287 1315 50004

EEE Producer Registration Number –

WEE/GE0057TS

Paper from sustainable sources

Quick Start Guide

XLS Storage Heater QS030

This guide is for quick reference only. Refer to XLS/XLSN installation and operating instructions for further information

XLstorage heater Control positions

Dimplex UK Ltd, Millbrook House, Hedge End, Southampton, SO30 2DF. For further assistance please contact Dimplex customer services on 0845 600 5111. Web-site: www.dimplex.co.uk

Heater controls

WARNING: Walls, curtains and furniture should be at least 75mm away from the top and sides of the heater. Furniture and other

obstructions should be at least 150mm from the front of the heater. DO NOT COVER or obstruct the air inlet or outlet grilles.

PLEASE REFER TO THE OPERATING AND INSTALLATION INSTRUCTIONS FOR FURTHER SAFETY ADVICE.

* NOTE: Changes to the input control setting will not come in to affect until the next period of off peak (cheap rate) electricity is available.

If you are unsure when your off peak supply is available, contact your electricity provider.

Input control — controls the temperature of the heater

Adjust control for the first few days until your ideal room temperature is found,

then leave on this setting. Heater will automatically adjust for changing weather.*

Boost control — controls the amount of heat given later in the day

Normally leave boost setting at minimum. Turn up if more heat is required later

in the day. Leaving the control on a higher setting will provide automatic boost

each day.

On/Off switch

Leave on for heating season
