Dimplex DHCER20WIFI User manual

2kW Ceramic Heater

with Wi-Fi

Model: DHCER20WIFI

INSTRUCTION MANUAL

PLEASE READ THE INSTRUCTION MANUAL CAREFULLY BEFORE USING THE UNIT

TABLE OF CONTENTS

WARNINGS AND PRECAUTIONS.......................................................1

STRUCTURE ...................................................................................3

OPERATION....................................................................................4

CLEANING AND MAINTENANCE .......................................................10

TECHNICAL REFERENCE DATA ........................................................12

WARRANTY ....................................................................................12

WARNINGS AND PRECAUTIONS

Warnings

Never place the unit near gas appliances, flames or

flammable liquids.

Never hit or shake the unit. Doing so may cause damage.

Never cover or obstruct the air inlet or outlet.

Doing so may cause overheating.

Never spray water on or place the unit near water.

Doing so may cause electric shock.

Never connect other appliances to the same power outlet.

Never connect or disconnect the power plug with wet hands.

Doing so may cause electric shock.

Never insert fingers or objects through the guards when the unit

is operating.

Never use an extension cord.

Always have a professional technician, manufacturer or service agent

replace a damaged power cord.

Precautions

This appliance is for indoor use only.

Do not use the unit near windows or where water collects. Rain and

water collection may lead to a risk of fire or electric shock.

Do not place the unit in a damp place or where humidity is high

(such as a bathroom).

Do not leave the unit operating while unattended.

Do not place the unit in direct sunlight to avoid surface

discolouration.

This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person

responsible for their safety.

Children should be supervised to ensure they do not play with the

appliance.

Avoid electromagnetic interference. Keep the unit at least 1 metre

away from electric appliances such as televisions and radios.

Avoid scratching and damaging the surface. Do not use chemical

solvents (i.e. Benzene, alcohol) to clean the surface.

Place the unit on a stable surface when operating.

Unplug the unit before cleaning, servicing or maintenance.

Electrical connections must be in accordance with National or

Local Codes.

The rear of the unit must be at least 50cm away from the wall.

Do not place the appliance on its side, back or front while in storage

or transport. The unit must be left in an upright position 2 hours

before operation.

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in order

to avoid a hazard.

WARNING: do not cover the heater. This may cause the unit to

overheat.

Do not use the heater in the immediate surroundings of bathtubs,

showers, washing stands or swimming pools.

The heater must not be located immediately below a socket‐outlet.

STRUCTURE

1. Buttons

2. Eco button

3. Display panel

4. Front cover

5. Front grille

6. Oscillating base

7. Base

8. Wi-Fi button

9. Back grille

10. On/Off switch

11. Power cord

OPERATION

DISPLAY PANEL

Power indicator

Temperature indicator

ECO function indicator

Timer indicator

Wi-Fi indicator

Swing indicator

Low power indicator

High power indicator

CONTROL PANEL

REMOTE CONTROL

ON/OFF button

Timer/Temperature button

Low / High Power button

Timer/Temperature set button

ECO button

Swing button

ON / OFF

This button is used to switch the unit ON and OFF.

TIMER

A timer can be set so the unit turns off automatically after a set period.

When Pressing the TIMER button once, the ‘h’ indicator will illuminate. Press

the ‘+/-’button to set the timer between 0-12 hours. Each press of the ‘+/-’

button increases/decreases the set time in 1 hour increments. If a time isn’t

set within 5 seconds, the unit will exit the timer function and revert to

displaying the room temperature.

LOW / HIGH POWER

By simply pressing this button, you can regulate the mode from LOW Power

to HIGH Power depending on your needs. The unit automatically starts in

LOW Power mode.

SWING

The unit will begin to oscillate after pressing the SWING button, the indicator

light will illuminate. To turn off the SWING function, press the swing button

again, and the swing will stop and the indicator light will switch off.

ECO MODE

When ECO Mode is selected, the unit will automatically adjust to suitable

settings according to the room temperature. When the room temperature is

below 18°C, the unit will operate in HIGH Power, and when the room is

above 18°C, the machine will operate in LOW Power. When the room

reaches 22°C the unit will stop working, until the room temperature

decreases, and will resume working again.

WI-FI

You can operate the unit wirelessly when connected to Wi-Fi. You’ll need a

Wi-Fi connection, and mobile device with the Dimplex CONNECT IT app

installed.

1. Connect mobile device to Wi-Fi and download the Dimplex CONNECT

IT app from the App Store, or Google Play.

2. Once installed, launch the app.

3. Press and hold the Wi-Fi button at the back of the unit (8) until the

Wi-Fi indicator light flashes rapidly

4. Click ‘Add the new device’. The SSID should automatically pick up

the Wi-Fi connection name.

5. Enter the Wi-Fi password ‘123456’ and hit connect.

6. Once connected you can control the unit via your mobile device and

with a 3G or 4G network connection.

You can update the device name & password by following the steps below:

*If you need to change Wi-Fi networks, press the Wi-Fi button at the back of

the unit (8), which will restore to factory settings. Then follow the steps

above to connect to a new network.

Step 1

Step 2

Step 3

Step 4

The connected

device appears in the

home screen. You

can change the

model name &

update the password

from this screen.

For Android –press

& hold the model

number to edit.

For iPhone –swipe

left on the model

until you see the

above change.

Rename the above

fields to desired

name / password

and submit.

The new device

name will appear in

the top left hand

corner in the control

panel screen.
