Digihome LCD32914FHD SaorView User manual

LCD32914FHD

OPERATING INSTRUCTIONSOPERATING INSTRUCTIONS

COLOUR TELEVISION WITH

REMOTE CONTROL

English - 1 -

Contents

Package Contents .................................................. 2

Features ................................................................. 2

Introduction............................................................. 2

Preparation............................................................. 2

Safety Precautions ................................................. 3

Information for users in EU Countries .................... 3

Remote Control Handset........................................ 4

Inserting Batteries............................................... 4

Environmental Information ..................................... 5

Repair Information .............................................. 5

Remote Control Buttons ......................................... 6

LCD TV and Operating Buttons.............................. 7

Viewing the Connections - Back Connectors ......... 7

Viewing the Connections - Side Connectors .......... 8

Aerial Connection ................................................... 8

Switching On/Off..................................................... 9

To Switch the TV On ........................................... 9

To Switch the TV Off ........................................... 9

First Time Installation.............................................. 9

Connecting to a DVD player via HDMI ................. 10

Connecting to a DVD Player................................. 10

Connecting the LCD TV to a PC............................11

Using Side AV Connectors ....................................11

USB Memory Connection......................................11

USB Memory Connection ..................................11

Input Selection...................................................... 12

Basic Operations .................................................. 12

Operation with the Buttons on the TV............... 12

Operation with the Remote Control .................. 12

Viewing Electronic Programme Guide (EPG)....... 12

Installation ............................................................ 13

Auto Channel Scan (Retune) Menu Operation.... 13

Manual Tuning ..................................................... 14

Digital Manual Search....................................... 14

Analogue Manual Search ................................. 14

Analogue Fine Tune.......................................... 14

Managing Stations: Channel List.......................... 14

Operating the Channel List............................... 14

Moving a Channel............................................. 15

Deleting a Channel ........................................... 15

Renaming a Channel........................................ 15

Locking a Channel............................................ 15

Managing Stations: Favourites............................. 15

Button Functions............................................... 15

Managing Stations: Sorting Channel List ............. 15

On-Screen Information ......................................... 16

Media Playback Using Media Browser................. 16

Viewing Videos via USB .................................. 16

Viewing Photos via USB................................... 17

Media Browser Settings.................................... 17

Changing Image Size: Picture Formats................ 18

Conﬁguring Picture Settings................................. 19

Operating Picture Settings Menu Items............ 19

Picture Settings Menu Items............................. 19

PC Picture Settings........................................... 19

Conﬁguring Sound Settings.................................. 20

Operating Sound Settings Menu Items............. 20

Sound Settings Menu Items.............................. 20

Conﬁguring Your TV’s Settings............................. 20

Operating Settings Menu Items ........................ 20

Using a Conditional Access Module ..................... 21

Viewing Conditional Access Menu (*)............... 21

Conﬁguring Language Preferences...................... 21

Language Settings............................................ 22

Parental Control.................................................... 22

Parental Settings Menu Operation ................... 22

Timers................................................................... 22

Setting Sleep Timer .......................................... 22

Setting Programme Timers............................... 23

Conﬁguring Date/Time Settings............................ 23

Conﬁguring Source Settings................................. 23

Conﬁguring Other Settings ................................... 24

Operation.......................................................... 24

Other Features ..................................................... 25

Teletext ................................................................. 25

Digital Teletext (** for UK only) ......................... 25

Analogue Teletext ............................................. 25

Tips....................................................................... 26

Appendix A: PC Input Typical Display Modes....... 27

Appendix B: AV and HDMI Signal Compatibility

(Input Signal Types).............................................. 27

Appendix C: Supported DVI Resolutions.............. 28

Appendix D: Supported File Formats for USB

Mode..................................................................... 28

Appendix E: Software Upgrade ............................ 29

Speciﬁcations ....................................................... 30

Important Instruction............................................. 31

01_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 101_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 1 02.12.2011 17:37:0202.12.2011 17:37:02

English - 2 -

Package Contents

SCREEN

LANG

RETURN

SOURCE

SOURCE FAV

PRESETS

SLEEP

INFO

EPG

V+

V-

P-

P+

1234

7 8

PIP

SUBTITLE

Remote Control

LCD TV

Batteries: 2 X AAA

Instruction Book

Note: You should check the accessories after

purchasing. Make sure that each accessory is

included.

Features

Remote controlled colour LCD TV.•

Fully integrated Terrestrial digital TV (DVB-T -•

MPEG2, MPEG4)

HDMI connectors for digital video and audio. This•

connection is also designed to accept high deﬁnition

signals.

USB input.•

1000 programmes (analogue+digital).•

OSD menu system.•

Integrated tuner MPEG 2, MPEG 4 compatible.•

Scart socket for external devices (such as video,•

video games, audio set, etc.).

Stereo sound system. (Nicam)•

Teletext, fastext, TOP text.•

Headphone connection.•

Automatic programming system.•

Forward or backward manual tuning.•

Sleep timer / Child lock.•

Automatic sound mute when no transmission.•

NTSC playback.•

AVL (Automatic Volume Limiting).•

Auto power down.•

PLL (Frequency Search).•

PC input.•

Plug&Play for Windows 98, ME, 2000, XP, Vista,•

Windows 7.

Game Mode•

Introduction

Thank you for choosing this product. This manual will

guide you for the proper operation of your TV.

Before operating the TV, please read this

manual thoroughly. Please do keep this

manual in a safe place for future references.

This device is intended to receive and display TV

programs. The different connection options make

an additional expansion of the reception and display

sources possible (receiver, DVD player, DVD recorder,

VCR, PC etc.).

This device is only suitable for dry, indoor use. This

appliance is intended solely for private domestic use

and may not be used for industrial and commercial

purposes. We exclude liability in principle, if the device

is not used as intended, or unauthorized modiﬁcations

have been made. To operate your LCD TV in extreme

ambient conditions may cause the damage of the

device.

Preparation

For ventilation, leave a free space of at least 10 cm

all around the set. To prevent any fault and unsafe

situations, please do not place any objects on top of

the set. Use this device in moderate climates.

10 cm

01_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 201_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 2 02.12.2011 17:37:0302.12.2011 17:37:03

English - 3 -

Safety Precautions

Read the following recommended safety

precautions carefully for your safety.

Power Source

The TV set should be operated only from a 220-240V

AC, 50 Hz outlet. Ensure that you select the correct

voltage setting for your convenience.

Power Cord

Do not place the set, a piece of furniture, etc. on the

power cord (mains lead) or pinch the cord. Handle the

power cord by the plug. Do not unplug the appliance by

pulling from the power cord and never touch the power

cord with wet hands as this could cause a short circuit or

electric shock. Never make a knot in the cord or tie it with

other cords. The power cords should be placed in such a

way that they are not likely to be stepped on. A damaged

power cord can cause ﬁre or give you an electric shock.

When it is damaged and needs to be replaced, it should

be done by qualiﬁed personnel.

Moisture and Water

Do not use this device in a humid and

damp place (avoid the bathroom, the

sink in the kitchen, and near the washing

machine). Do not expose this device to

rain or water, as this may be dangerous

and do not place objects filled with

liquids, such as ﬂower vases, on top.

Avoid from dripping or splashing.

If any solid object or liquid falls into the cabinet, unplug

the TV and have it checked by qualiﬁed personnel

before operating it any further.

Cleaning

Before cleaning, unplug the TV set

from the wall outlet. Do not use liquid

or aerosol cleaners. Use soft and dry

cloth.

Ventilation

The slots and openings on the TV set are intended for

ventilation and to ensure reliable operation. To prevent

overheating, these openings must not be blocked or

covered in anyway.

Heat and Flames

The set should not be placed near to

open ﬂames and sources of intense heat

such as an electric heater. Ensure that

no open ﬂame sources, such as lighted

candles, are placed on top of the TV. Batteries should

not be exposed to excessive heat such as sunshine,

ﬁre or the like.

Lightning

In case of storm and lightning or when

going on holiday, disconnect the power

cord from the wall outlet.

Replacement Parts

When replacement parts are required, make sure that

the service technician has used replacement parts

which are speciﬁed by the manufacturer or have the

same speciﬁcations as the original one. Unauthorized

substitutions may result in ﬁre, electrical shock or

other hazards.

Servicing

Please refer all servicing to qualiﬁed

personnel. Do not remove the cover

yourself as this may result in an electric

shock.

Waste Disposal

Instructions for waste disposal:•

• Packaging and packaging aids are recyclable

and should principally be recycled. Packaging

materials, such as a foil bag, must be kept away

from children.

• Batteries, including those which are heavy metal-

free, should not be disposed of with household

waste. Please dispose of used batteries in an

environmentally friendly manner. Find out about

the legal regulations which apply in your area.

Do not try to recharge batteries, there is a danger•

of explosion. Replace batteries only with the same

or equivalent type.

Information for users in EU

Countries

This symbol on the product or on its packaging means

that your electrical and electronic device

should be disposed at the end of its

service life separately from your household

wastes. There are separate collection

systems for recycling in the EU. For more

information, please contact the local

authority or the dealer where you

purchased the product.

Disconnecting the Device

The mains plug is used to disconnect the TV set

from the mains and therefore it must remain readily

operable.

Headphone Volume

Excessive sound pressure from earphones

and headphones can cause hearing loss.

01_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 301_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 3 02.12.2011 17:37:0302.12.2011 17:37:03

English - 4 -

Installation

To prevent injury, this device must be securely

attached to the wall in accordance with the installation

instructions when mounted to the wall (if the option

is available).

LCD Screen

The LCD panel is a very high technology product with

about a million thin ﬁlm transistors, giving you ﬁne

picture details. Occasionally, a few non-active pixels

may appear on the screen as a ﬁxed blue, green or

red point. Please note that this does not affect the

performance of your product.

Warning! Do not leave your TV in standby or operating

mode when you leave your house.

Connection to a Television Distribution

System (Cable TV etc.) from Tuner

Devices connected to the protective earthing of the

building through the mains connection or through

other apparatus with a connection to protective

earthing-and to a television distribution system using

coaxial cable, may in some circumstances create a

ﬁre hazard.

Connection to a cable distribution system has

therefore to be provided through a device providing

electrical isolation below a certain frequency range

(galvanic isolator, see EN 60728-11).

Licence Notiﬁcation (Optional)

Manufactured under license from Dolby

Laboratories.

TRADEMARK ACKNOWLEDGMENT

“Dolby” and the double-D symbol are trademarks of

Dolby Laboratories.

The Standby On/Off button does not completely switch

off this device, it will still consume power. In order

to fully switch off this device, the power should be

switched off at the mains socket. Because of this the

device should be set up in a way, that unobstructed

access to the mains socket is guaranteed, so that

in case of an emergency the mains plug can be

pulled out immediately. To exclude the danger of ﬁre,

the power cord should be removed from the mains

socket prior to a long period of non-use, i.e. during

vacations.

Electrical device not in the hands of

children

Never let children use any electrical device

unsupervised. Children cannot always recognize

possible dangers. Batteries / accumulators can be

life threatening when swallowed. Store batteries out

of the reach of small children. In case of swallowing

a battery medical aid has to be sought immediately.

Also keep the packaging foils away from children, as

there is danger of suffocation.

Note:The HDMI connection between PC and TV

may cause radio interference in which case it is

recommended to use VGA(DSUB-15) connection.

Remote Control Handset

Inserting Batteries

Remove the battery cover located on the back of•

the handset by gently pulling backwards from the

indicated part.

Insert two• AAA/R3 or equivalent type batteries

inside. Observe the correct polarity (+/-) when

inserting batteries and replace the battery cover.

Note: Remove the batteries from the remote control

handset when it is not to be used for a long period.

Otherwise it can be damaged due to any leakage of

batteries. Remote range is approximately 7m/23ft.

01_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 401_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 4 02.12.2011 17:37:0402.12.2011 17:37:04

English - 5 -

Environmental Information

This television is designed to consume less energy to save environment.•

You not only help to save the environment but also you can save money by reducing electricity bills thanks to the

energy efﬁciency feauture of this TV. To reduce energy consumption, you should take the following steps:

You can use Power Save Mode setting, located in the Feature menu. If you set Power Save Mode as On,•

the TV will switch to energy-saving mode and luminance level of TV set will be decreased to optimum level.

Note that some picture settings will be unavailable to be changed when the TV is in Power Save Mode.

When the TV is not in use, please switch off or disconnect the TV from the mains plug. This will also reduce•

energy consumption.

Disconnect power when going away for longer time.•

Note that annually, using the TV set in Power Save Mode has more power efﬁciency than disconnecting the•

TV from the mains plug instead of keeping stand-by mode. Therefore it is highly recommended to activate

Power Save Mode setting to reduce your annual power consumption.And also it is recommended to disconnect

the TV from the mains plug to save energy more when you do not use.

• Please helps us to save environment by following these steps.

Repair Information

Please refer all servicing to qualiﬁed personnel. Only qualiﬁed personnel must repair the TV. Please contact

your local dealer, where you have purchased this TV for further information.

01_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 501_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 5 02.12.2011 17:37:0402.12.2011 17:37:04

English - 6 -

Remote Control Buttons

SCREEN

LANG

SUBTITLE

PIP

RETURN

SOURCE

SOURCE FAV

PRESETS

SLEEP

INFO

EPG

V+

V-

P-

P+

1234

7 8

14 16

Standby1.

Mono/Stereo - Dual I-II / Currrent Language (*)2.

(in DVB channels)

Image size / Zooms videos (in Media Browser3.

video mode)

Green button/List Schedule(in EPG)/Tag/Untag4.

All(in favourite list)/Play-Slideshow(in Media

Browser)

Red button/Stop(in Media Browser)5.

Numeric buttons6.

Teletext / Mix(in TXT mode)7.

Cursor Left8.

Menu on-off9.

AV / Source selection10.

Favourite Mode Selection(in DVB channels)11.

Volume Up12.

Info / Reveal (in TXT mode)13.

Mute14.

Volume Down15.

Programme Down / Page up(in DVB channels)16.

Electronic programme guide(in DVB channels)17.

Programme Up / Page down(in DVB channels)18.

Sleep Timer19.

Picture mode selecion. / Changes picture mode20.

(in Media Browser video mode)

Okay (Conﬁrm) / Hold (in TXT mode)/ Edit21.

Channel List

Cursor Down22.

Exit / Return / Index page (in TXT mode)23.

Cursor Right / Subpage (in TXT mode)24.

Cursor Up25.

Previous programme26.

Yellow button/Pause (in Media Browser)/27.

Timeline Schedule(in EPG)

Blue button/Edit Channel List/Filter (İn Favourite28.

List&EPG)/Loop-Shufﬂe (in Media Browser)

No function29.

Subtitle on-off (in DVB channels)30.

01_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 601_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 6 02.12.2011 17:37:0402.12.2011 17:37:04

English - 7 -

LCD TV and Operating Buttons

FRONT and REAR VIEW Control buttons VIEW Control Buttons

Standby button1.

TV/AV button2.

Programme Up/Down3.

buttons

Volume Up/Down buttons4.

Note: Press “” / “ ”

buttons at the same time to view

main menu.

Viewing the Connections - Back Connectors

HDMI 1

DMHI 2

SPDIF

Coax.OUT

HDMI 2: HDMI Input1.

HDMI 1: HDMI Input2.

HDMI Inputs are for connecting a device that has an HDMI socket. Your LCD TV is capable of

displaying High Deﬁnition pictures from devices such as a High Deﬁnition Satellite Receiver or DVD

Player. These devices must be connected via the HDMI sockets or Component Socket. These sockets

can accept either 720p or 1080p signals. No sound connection is needed for an HDMI to HDMI

connection.

RF Input3. connects to an aerial antenna system.

Note that if you use a decoder or a media recorder, you should connect the aerial cable through the device

to the television with an appropriate antenna cable, as shown in the illustration in the following pages.

SCART4. input or output for external devices. Connect the SCART cable between SCART socket on TV and

SCART socket on your external device (such as a decoder, a VCR or a DVD player).

Note: If an external device is connected via the SCART socket, the TV will automatically switch to AV mode.

Note: S-VHS signal is supported via the scart socket.

Note: When receiving DTV channels (Mpeg4 H.264) or while in Media Browser mode, output will not be

available via the scart socket.

01_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 701_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 7 02.12.2011 17:37:0402.12.2011 17:37:04

English - 8 -

PC Input5. is for connecting a personal computer to the TV set.

Connect the PC cable between the PC INPUT on the TV and the PC output on your PC.

Note: You can use YPbPr to VGA cable (not supplied) to enable YPbPr signal via PC input.

WARNING: You cannot use PC and YPbPr at the same time.

S/PDIF Coaxial Out6. outputs digital audio signals of the currently watched source.

Use an SPDIF coaxial cable to transfer audio signals to a device that has S/PDIF input

Viewing the Connections - Side Connectors

CI Slot is used for inserting a CI card. A CI card allows you to view all the1.

channels that you subscribe to. For more information, see “Conditional

Access” section.

USB input.2.

Video Input is used for connecting video signals of external devices.Connect3.

the video cable between the VIDEO IN socket on the TV and the VIDEO

OUT jack on your device.

Audio Inputs are used for connecting audio signals of external devices. Connect4.

the audio cable between the AUDIO INPUTS on the TV and the AUDIO OUTPUT

jacks on your device.

Note: If you connect a device to the TV via the VIDEO INPUT, you should also

connect your device with an audio cable to the AUDIO INPUTS of the TV to

enable audio.

Headphone jack is used for connecting an external headphone to the5.

system. Connect to the HEADPHONE jack to listen to the TV from

headphones (optional).

Aerial Connection

Connect the aerial or cable TV plug to the AERIAL INPUT socket located at the rear of the TV.•

HDMI 1

DMHI 2

SPDIF

Coax.OUT

Power Connection

IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.

After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the•

mains. Plug the power cable to the mains socket outlet.

5Vdc-Max500mA

01_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 801_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 8 02.12.2011 17:37:0502.12.2011 17:37:05

English - 9 -

Switching On/Off

To Switch the TV On

Connect the power cord to the 220-240V AC 50 Hz.•

Then the standby LED lights up. (The led will blink

during the standby On/Off)

To switch on the TV from standby mode either:•

Press the “• ” button, P+ / P- or a numeric button

on the remote control.

Press the “• ” button, -or +button on the TV. The

TV will then switch on.

• When the mains power is ﬁrst connected to the device

the light on the front of the unit will start ﬂashing

for few seconds, when it stops ﬂashing (remains

constant) the TV will be in standby mode.

Note: If you switch on your TV via PROGRAMME

UP/DOWN buttons on the remote control or on the

TV set, the programme that you were watching last

will be reselected.

By either method the TV will switch on.

Note: When the device is coming out of standby the

light on the front of the unit will ﬂash until the picture

appears. If you activate the power operation again

(before the light has had time to stop ﬂashing) the

device will turn off into stndaby mode again. This is

normal operation and not a fault

Note: The standby light will blink while the TV is

powering up from Standby mode.

To Switch the TV Off

Press the “• ” button on the remote control or

press the “ ” switch on the TV, the TV will switch

to standby mode.

To power down the TV completely, unplug the•

power cord from the mains socket.

Note: When the TV is switched to standby mode,

standby LED can blink to indicate that features such

as Standby Search, Over Air Download or Timer is

active.

First Time Installation

IMPORTANT: Ensure that the aerial is connected

before switching on the TV for the first time

installation.

When the TV is operated for the ﬁrst time, the•

installation wizard will guide you through the

process. First, language selection screen will be

displayed:

Use “• ” or “ ” buttons to select your language

and press OK button to set the selected language

and continue.

After selecting the language, “• Welcome!” screen will

be displayed, requiring you to set Country, Teletext

Language and Scan Encrypted options.

By pressing “• ” or “ ” button, select the country

you want to set and press “ ” button to highlight

Teletext Language option. Use “ ” or “ ” button

to select desired Teletext Language.

Press “• ” button after setting Teletext Language

option. Scan Encrypted will be then highlighted.

You can set Scan Encrypted as Yes if you want to

scan coded stations.Afterwards select the desired

Teletext Language.

Press• OK button on the remote control to continue

and the following message will be displayed on the

screen:

01_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 901_MB60_[GB]_[VESTEL_UK]_3902UK_IDTV_NICKEL16_woypbpr_32914W_10076108_50202180.indd 9 02.12.2011 17:37:0802.12.2011 17:37:08
