Digi-tech JAMMAN STEREO User manual

6Removable CompactFlash®Type I memory

card with over 24 minutes of capacity included

(up to 2GB of storage or 6.5 hour*capacity)

6USB port to transfer loops to and from your

computer. Create a library of all your loops

6Balanced XLR mic input with professional-

grade, low impedance input with dedicated

gain control. Perfect for dynamic and self

powered microphones

6CD quality 44.1kHz sampling rate

6Metronome with multiple rhythm sounds

and time signatures

6Rugged metal chassis

6Automatic recording

6Power supply included

6Optional footswitch adds addidtional

Hands-Free™functionality

When we developed the

PDS 8000 looper pedal

almost twenty years ago, it stored

eight seconds of audio. Now

we’ve reinvented it using remov-

able CompactFlash®memory to

store up to 6.5 hours*! A wide

range of features combined with

ease of use make the DigiTech®

JamMan®the perfect looper/

phrase sampler for practicing,

composing, and performing.

• Save up to 99

independent loops.

• Store over 24 minutes of

looping time on the included

CompactFlash card. Upgrade

to a 2GB card to store up to 6.5 hours of audio!

• Connect to your computer via USB and

never lose another loop ever again!

• Record rhythm loops and solo over them

on the ﬂy, completely Hands-Free™.

• Load up the JamMan with bass lines, drums,

harmonies, and more; create an entire backup

band, take it with you, and perform anywhere!

• Slow down or speed up any song

without changing pitch.

The JamMan opens up new horizons to

your musical explorations. The possibili-

ties are literally endless, endless, endless...!

*With optional 2GB card

Twenty years later, 6 hours, 29 minutes & 52 seconds longer 7 www.digitech.com

TWENTYYEARS LATER

6hours,29 minutes & 52 seconds longer!

THE JamMan®

JAMMAN® LOOPER/PHRASE SAMPLER

JamMan® Provides Endless Possibilities for Creativity:

Whether a skilled journeyman or practicing musician

the JamMan®will open doors for creative solutions.

Above is just one of the many possible conﬁgurations that

allows for Hand-Free™ﬂexibility in studio or onstage.

OUTPUT JACK

Connect to

guitar ampliﬁer,

mixer or head-

phones with

plenty of juice

to spare.

FOOTSWITCH JACK

Connect the optional

footswitch to scroll

through 99 loops and

arm the Auto Record

feature, completely

Hands-Free™.

CD/AUX INPUT

Create samples

and play along

with CDs and

MP3s, with or

without the

original vocals!

INSTRUMENT INPUT

Super-quiet, ultra-high

impedance input is

ideal for sensitive

magnetic pickups.

JamMan® CONFIGURATIONS:

BALANCED XLR MIC INPUT

Professional-grade, low

impedance input with

dedicated gain control,

perfect for dynamic

and self-powered

condenser mics.

CompactFlash®

CARD READER

Expandable, swap-

pable, CompactFlash

memory gives you

virtuall unlimited

loop recording time.

AC ADAPTER

The included power

adapter means no

more performance

interruptions.

SPECIFICATIONS:

Included in Box:

JamMan®

CompactFlash® card

Power supply

Manual

Warranty card

Number of Loops Saved:

Up to 99 phrases (restricted

to space on memory card)

Connections:

Instrument Input Jack (¼")

Balanced XLR input

CD/AUX Input

CompactFlash® Type I Storage

Footswitch Jack

Output Jack (¼")

Power Adaptor Jack

USB Jack

Rhythms:

Wood Blocks, Sticks, Click,

Alternative Kick/High Hat,

Studio Kick/High Hat,

Techno Kick/High Hat,

Cowbell, Conga

and Tambourine.

Power Supply:

9V AC

Size:

Width: 6.65 inches 168 mm

Depth: 5.57 inches 141 mm

Height: 2.85 inches 65 mm

Options:

FS3X footswitch

CompactFlash® card

(up to 2 gigabytes in capacity

or 6.5 hours of recording time)

18-0339-A

USB PORT

Transfer loops to and

from your computer.

Create a library of all

your loops!

.0%& %08/ 61

Amplier

Instrument

Footswitch (optional)

switches between loops

CompactFlash®

Storage

MicrophoneCD/MP3 Player

Computer

connectivity

via USB port

INTUITIVE USER INTERFACE AND DISPLAY

High visibility, brightly lit numeric display, buttons,

and LEDs are just right for dark stages and studios.

Make loop changes fast and simple with the Select knob.

Record, play, overdub, undo and more all Hands-FreeTM!

JAMMAN® LOOPER/PHRASE SAMPLER

Twenty years later, 6 hours, 29 minutes & 52 seconds longer 7 www.digitech.com

FEATURES:

Auto-Record:

Start recording the moment

you start playing

Full Range Playback:

Built-in equalizer automatically

optimizes song samples played

through your amp

Minus Center:

Replace the vocals from MP3s

and CDs with your own voice

XLR and ¼" Inputs:

Record and mix your guitar and

vocals at the same time

Time Stretching:

Speed up or slow down loops and

samples, without changing pitch

One-Step Undo:

Instantly erase an unwanted over-

dub (and keep the original loop)

with a single tap of your foot

Tap Tempo:

Easily tap in the tempo with

a button or a footswitch

One-Step Clear:

Erase everything and start over,

without taking your hands off

your guitar
