AVAILABLE MODELS
Sector lights Min. Visibility Colour Nom. Power Art. Code
Starboard 2 NM Green 4,2 W 60.01.00.00
Port 2 NM Red 4,3 W 60.02.00.00
Masthead 5 NM White 11,7 W 60.03.00.00
Stern 2 NM White 4,1 W 60.04.00.00
Stern red (Suez) 2 NM Red 4,3 W 60.04.07.00
Towing 2 NM Yellow 4,3 W 60.04.09.00
Convoy light 1 NM Blue 4,1 W 60.04.10.00
All-round lights Min. Visibility Colour Nom. Power Art. Code
White 2 NM White 4,1 W 60.06.00.00
Manoeuvring 5 NM White 15,9 W 60.06.10.00
Red 2 NM Red 4,3 W 60.07.00.00
Red & White 2 NM Red/White 4,3 / 5,7 W 60.07.06.00
Red & Green 2 NM Red/Green 4,3 / 5,9 W 60.07.08.00
Green 2 NM Green 4,2 W 60.08.00.00
Yellow1) 2 NM Yellow 4,3 W 60.09.00.00
Blue 1 NM Blue 4,1 W 60.10.00.00
Screened lights2) Min. Visibility Colour Nom. Power Art. Code
White 180° 2 NM White 4,1 W 60.06.01.80
Red 180° 2 NM Red 4,3 W 60.07.01.80
Green 180° 2 NM Green 4,2 W 60.08.01.80
1. Yellow signal light to be used in conjunction with sound signal and only applicable for vessels navigating
the European Inland Waterways
2. - Screened navigation lights should NOT be considered as an official sectored navigation light, but as
two navigation lights with horizontal sectors that combined form a single all round light of 360°
- The interpretation of screened navigation lights are stipulated in IMO MSC.1/Circ.1260
