Castor is a freestanding lift stand, which together with a rail and a lift unit, functions as a stationary patient lift. It is ideal
for occasional lifting needs in a specific location, or where it is not possible to install a permanent rail system on the
ceiling. Castor is made of aluminium, which makes it light in relation to its large lifting capacity.
Direct Healthcare Group’s SystemRoMedic product series includes a range of lifts, slings and other accessories.
SystemRoMedic adopts a holistic approach to patient transfers and is organized in four categories: transfer, positioning,
support and lifting.
Visual inspection
Inspect Castor and lift unit functions regularly. Check to ensure that material is free from damage.
Before use:
Check to ensure that the lift stand and lift unit are correctly assembled.
Check all mounts and safety latches.
Always read the manuals for all assistive devices used during a transfer.
Keep the manual where it is accessible to users of the product.
The lift may only be used by persons who have received instruction in the operation of the lift.
Functional inspection
Always read the manual
1. Rail (not included)
2. Corner piece
3. Bolts with nuts for mounting
4. Lift unit (not included)
5. Upright
6. Carrier handle for uprights
7. Locking handle for uprights
8. Foot
3
5
4
2
6
1
7
8
2
8
5
3
6
7
3
3
Instructions for use - English
Castor Gantry
Component parts:
1. Two supporting feet
2. Two uprights with carrier handles
3. Rail (not included, ordered
separately)
4. Two corner pieces
Eight bolts with nuts for mounting
uprights and rail
Assembly
Assembly of uprights
1. Insert each upright in it´s foot and adjust to the desired
height.
2. Use the locking handles to secure the uprights at the
desired height.
4IFU
1
2
3
4
4
1
2
Mounting overhead rail and lift unit
1, 2. Insert the upright in the corner piece and secure with two bolts.
Do the same with the other upright and corner piece.
3. Mount the bolts on the rail, on both sides.
4. Insert the rail in one of the corner pieces and tighten.
NOTE! Remember to mount the lift unit/carriage before mounting the other upright.
5. Mount the lift unit according to one of the following alternatives:
1. Lift unit with built-in carriage:
The lift unit is mounted on the rail (see image) before the other end of the rail is secured to the corner piece.
2. Portable lift unit with separate carriage:
Mount the carriage on the rail before the other end of the rail is secured to the corner piece. When the entire lift stand is
assembled, the portable lift unit can be installed.
For operating instructions, see the manual for the respective lift unit.
6. To prevent the lift unit from travelling along the rail during assembly of the second upright, the lift unit must be
anchored to the first upright. We recommend the use of an end stop for anchoring the lift unit. After assembly, this can
be moved to the other end of the rail and left in place.
7. Secure the other end of the rail to the other corner piece, as in image 4, 7.
5IFU
2
(8) (7)
(9)
150 mm
1
Final inspection
Inspect Castor for signs of wear and damage. Ensure that Castor stands stable on the floor, so that it does not tilt,
and check that the uprights are adjusted to the same height.
Check to ensure that all locking handles and bolts are securely tightened.
Test lift function by lifting a person (not a patient) using an approved sling.
Keep the instruction manual where it is accessible to users of the product.
Safe working load
Different products on the same lift system (lift unit, slingbar, sling, scales and other lifting accessories) may have different
allowable safe working loads. The lowest allowable safe working load always determines the maximum load of the
assembled system. Always check the safe working loads for the lift and accessories before use. Contact your dealer if
you have any questions.
Important information
• Castor must be assembled according to the assembly instructions provided with the stand.
• Castor may only be used indoors and on a level floor.
• Lifting accessories must be properly trial fitted and tested in relation to the patient’s needs and functional ability.
• Do not leave the patient unattended during a transfer situation.
• Under no circumstances may max. load be exceeded. See section on safe working load.
• To ensure optimal function, Castor must be inspected regularly. See section on maintenance.
• Warranty applies only if repairs or alterations are done by an authorized technician.
How to use the product
6IFU
Accessories
Locking handle
For easier assembly of the rail, the bolts can be replaced with four
locking handles.
Lift units
SystemRoMedic’s lift units are available in different models and ver-
sions, stationary or portable. The choice of model is determined by
the required lifting capacity, the location and situations in which the
lift is to be used, and the patient’s individual needs.
Slings
SystemRoMedic slings are available in different fabrics and models.
The choice of model and material is determined by the patient’s
functional capacity and the situations in which the product is to be
used.
For further information on slings and other lifting accessories, see
SystemRoMedic’s manuals and brochures.
Positioning aids
TopSheet
SafeHandlingSheet
RoMedicClips.
Articelnumbers for a complete lift stand
Castor, lift stand: 50300004
Rail-64, aluminum, white: 50400262 - 50400266
Rail-120, aluminum, white: 50400277 - 50400290
Rail-160, aluminum, white: 50400295 - 50400299
7IFU
TopSheet
SafeHandlingSheet
RoMedicClips
x2
Maintenance
The lift must undergo thorough inspection at least once per year. This must be done by authorized Direct Healthcare
Group service personnel and in accordance with the periodic inspection for Castor.
Repairs and maintenance may only be done by authorized personnel using original spare parts.
Cleaning
When necessary, clean the lift using warm water or rubbing alcohol. Do not use cleaning agents containing phenol or
chlorine, as this may damage the material.
Dimensions
Note: Column A measurement is in cm and weight is in kg.
Column B measurement is in inches and weight is in lbs.
I is total weight of stand
J is the weight of the heaviest component
Technical information
8IFU
Lr
HHr
Li
L
9IFU
Height (H)
Height to the rail (Hr)
Maximum length (L)
Inner length (Li)
Functional length of rail (Lr)
Total weight
The weight of the heaviest part
50400264 Rail 64-2000 2045-2495 1965-2415 2300 2140 1360-1660 44,8 19
50400265 Rail 64-2200 2045-2495 1965-2415 2500 2340 1560-1860 45,48 19
50400266 Rail 64-2400 2045-2495 1965-2415 2700 2540 1760-2060 46,16 19
50400267 Rail 64-2600 2045-2495 1965-2415 2900 2740 1950-2260 46,84 19
50400268 Rail 64-2800 2045-2495 1965-2415 3100 2940 2160-2450 47,52 19
50400269 Rail 64-3000 2045-2495 1965-2415 3300 3140 2360-2660 48,2 19
50400281 Rail 120-3200 2045-2495 1909-2359 3500 3340 2560-2860 54,96 19
50400282 Rail 120-3400 2045-2495 1909-2359 3700 3540 2760-3060 56,02 19
50400283 Rail 120-3600 2045-2495 1909-2359 3900 3740 2960-3260 57,08 19
50400284 Rail 120-3800 2045-2495 1909-2359 4100 3940 3160-3460 58,14 20,14
50400285 Rail 120-4000 2045-2495 1909-2359 4300 4140 3360-3660 59,2 21,2
50400286 Rail 120-4200 2045-2495 1909-2359 4500 4340 3560-3860 60,26 22,26
50400287 Rail 120-4400 2045-2495 1909-2359 4700 4540 3760-4060 61,32 23,32
50400288 Rail 120-4600 2045-2495 1909-2359 4900 4740 3960-4260 62,38 24,38
50400289 Rail 120-4800 2045-2495 1909-2359 5100 4940 4160-4460 63,44 25,44
50400295 Rail 160-5000 2045-2495 1869-2319 5300 5140 4360-4660 69 31
50400296 Rail 160-5500 2045-2495 1869-2319 5800 5640 4860-5160 72,1 34,1
50400297 Rail 160-6000 2045-2495 1869-2319 6300 6140 5360-5660 75 37,2
50400298 Rail 160-6500 2045-2495 1869-2319 6800 6640 5860-6160 78,3 40,3
50400299 Rail 160-7000 2045-2495 1869-2319 7300 7140 6360-6660 81,4 43,4
