VENT-FREE NATURAL GAS HEATER

OWNER’S OPERATION AND INSTALLATION MANUAL

VN600BA

6000 Btu/Hr Manually-

Controlled Models

WARNING:Iftheinformationinthismanualis

not followed exactly, a fire or explosion may

result causing property damage, personal in-

jury, or loss of life.

— Do not store or use gasoline or other

flammable vapors and liquids in the

vicinity of this or any other appliance.

— WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do

not use any phone in your building.

• Immediatelycallyourgassupplierfrom

a neighbor’s phone. Follow the gas

supplier’s instructions.

• If you cannot reach your gas supplier,

call the fire department.

— Installation and service must be per-

formed by a qualified installer, service

agency, or the gas supplier.

WARNING: Improper installa-

tion,adjustment,alteration,ser-

vice,ormaintenancecancause

injury or property damage. Re-

fer to this manual for correct

installationandoperationalpro-

cedures. For assistance or ad-

ditional information consult a

qualified installer, service

agency, or the gas supplier.

WARNING: This is an

unvented gas-fired heater. It

uses air (oxygen) from the

room in which it is installed.

Provisionsforadequatecom-

bustion and ventilation air

mustbeprovided.Referto

Air

For Combustion and Ventila-

tion

onpage4ofthismanual.

This appliance may be installed in an aftermarket*, permanently located, manufactured

(mobile) home, where not prohibited by local codes.

This appliance is only for use with the type of gas indicated on the rating plate. This

appliance is not convertible for use with other gases.

*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer

104271

BLUE FLAME NATURAL GAS HEATER

Carbon Monoxide Poisoning: Early signs

ofcarbonmonoxidepoisoningresemblethe

flu, with headaches, dizziness, and/or nau-

sea. If you have these signs, the heater may

not be working properly. Get fresh air at

once! Have heater serviced. Some people

are more affected by carbon monoxide than

others. These include pregnant women,

peoplewithheartorlungdiseaseoranemia,

those under the influence of alcohol, and

those at high altitudes.

Natural Gas: Natural gas is odorless. An

odor-making agent is added to natural gas.

Theodorhelpsyoudetectanaturalgasleak.

However, the odor added to natural gas can

fade.Naturalgasmaybepresenteventhough

no odor exists.

Make certain you read and understand all

warnings.Keepthismanualforreference.It

isyourguidetosafeandproperoperationof

this heater.

SAFETY

INFORMATION

WARNINGS

IMPORTANT: Read this owner’s

manual carefully and completely

before trying to assemble, oper-

ate, or service this heater. Im-

proper use of this heater can

causeseriousinjuryordeathfrom

burns, fire, explosion, and car-

bon monoxide poisoning.

DANGER: Carbon monoxide

poisoning may lead to death!

WARNING: Any change to

this heater or its controls can be

dangerous.

1. This appliance is only for use with the

typeofgas indicated on therating plate.

Thisappliance is not convertibleforuse

with other gases.

2. If you smell gas

• shut off gas supply

• do not try to light any appliance

• do not touch any electrical switch; do

not use any phone in your building

• immediately call your gas supplier

from a neighbor’s phone. Follow the

gas supplier’s instructions

• ifyoucannot reach your gas supplier,

call the fire department

3. This heater needsfresh, outside air ven-

tilation to run properly.This heater has

an oxygen depletion sensing (ODS)

safety shutoff system. The ODS shuts

down the heater if not enough fresh air

is available. See Air for Combustion

and Ventilation, pages 4 through 6.

4. Keep all air openings in front and bot-

tom of heater clear and free of debris.

This will insure enough air for proper

combustion.

5. If heater shuts off, do not relight until

you provide fresh, outside air. If heater

keeps shutting off, have it serviced.

6. Do not run heater

• where flammable liquids or vapors

are used or stored

• under dusty conditions

7. Before using furniture polish, wax,car-

pet cleaner, or similar products, turn

heater off. If heated, the vapors from

theseproductsmaycreate a white pow-

der residue within burner box or on

adjacent walls or furniture.

8. Do not use heater if any part has been

under water. Immediately call a quali-

fied service technician to inspect the

room heater and to replace any part of

the control system and any gas control

which has been under water.

9. Turn off heater and let cool before ser-

vicing. Only a qualified service person

should service and repair heater.

10. Operating heater above elevations of

4,500 feet could cause pilot outage.

Do not place clothing or other

flammable material on or near

the appliance. Never place any

objects on the heater.

Surface of heater becomes very

hot when running heater. Keep

children and adults away from

hot surface to avoid burns or

clothing ignition. Heater will re-

main hot for a time after shut-

down. Allow surface to cool be-

fore touching.

Carefully supervise young chil-

dren when they are in the same

room with heater.

Make sure grill guard is in place

before running heater.

Keeptheapplianceareaclearand

free from combustible materials,

gasoline and other flammable

vapors and liquids.

Due to high temperatures, the

appliance should be located out

oftrafficandawayfromfurniture

and draperies.

WARNING: Do not use any

accessory not approved for use

with this heater.

104271

OWNER’S MANUAL

PRODUCT

IDENTIFICATION

LOCAL CODES

Install and use heater with care. Follow all

local codes. In the absence of local codes, use

the latest edition of The National Fuel Gas

Code ANS Z223.1 also known as NFPA 54*.

*Available from:

American National Standards Institute, Inc.

1430 Broadway

New York, NY 10018

National Fire Protection Association, Inc.

Batterymarch Park

Quincy, MA 02269

Figure 1 - Vent-Free Natural Gas Heater

Heater

Cabinet

Grill Guard

Glass Panel

Front

Panel

Control Knob

Ignitor Button

1. Remove heater from carton.

2. Remove all protective packaging ap-

plied to heater for shipment.

3. Check heater for any shipping damage.

If heater is damaged, promptly inform

dealer where you bought heater.

UNPACKING

PRODUCT

FEATURES

SAFETY DEVICE

This heater has a pilot with an Oxygen

DepletionSensing(ODS)safetyshutoffsys-

tem.The ODS/pilot is arequiredfeature for

vent-freeroomheaters.TheODS/pilotshuts

offtheheaterifthereisnotenoughfreshair.

PIEZO IGNITION SYSTEM

This heater has a piezo ignitor. This system

requires no matches, batteries, or other

sources to light heater.

104271

BLUE FLAME NATURAL GAS HEATER

Confined and Unconfined Space

The National Fuel Gas Code ANS Z223.1

defines a confined space as a space whose

volume is less than 50 cubic feet per 1,000

Btu per hour (4.8 m3 per kw) of the aggre-

gate input rating of all appliances installed

in that space and an unconfined space as a

space whose volume is not less than 50

cubicfeetper1,000Btuperhour(4.8m3per

kw) of the aggregate input rating of all

appliances installed in that space. Rooms

communicating directly with the space in

whichtheappliancesareinstalled*,through

openings not furnished with doors, are con-

sidered a part of the unconfined space.

This heater shall not be installed in a con-

fined space or unusually tight construction

unlessprovisions are providedforadequate

combustion and ventilation air.

*Adjoiningroomsarecommunicatingonly

iftherearedoorlesspassagewaysorventila-

tion grills between them.

AIR FOR

COMBUSTION AND

VENTILATION

WARNING: This heater shall

notbeinstalledinaconfinedspace

or unusually tight construction

unless provisions are provided

foradequatecombustionandven-

tilation air. Read the following in-

structions to insure proper fresh

air for this and other fuel-burning

appliances in your home.

Today’s homes are built more energy effi-

cient than ever. New materials, increased

insulation, and new construction methods

helpreduceheatlossinhomes.Homeowners

weatherstrip andcaulk aroundwindowsand

doorstokeepthecoldairoutandthewarmair

in. During heating months, home owners

want their homes as airtight as possible.

While it is good to make your home energy

efficient,yourhomeneedstobreathe.Fresh

air must enter your home. All fuel-burning

appliances need fresh air for proper com-

bustion and ventilation.

Exhaustfans,fireplaces,clothesdryers,and

fuel burning appliances draw air from the

house to operate. You must provide ad-

equate fresh air for these appliances. This

will insure proper venting of vented fuel-

burning appliances.

PROVIDING ADEQUATE

VENTILATION

The following are excerpts from National

Fuel Gas Code. NFPA 54/ANS Z223.1, Sec-

tion5.3,AirforCombustionandVentilation.

Allspacesinhomesfallintooneofthethree

following ventilation classifications:

1. Unusually Tight Construction

2. Unconfined Space

3. Confined Space

The information on pages 4 through 6 will

help you classify your space and provide

adequate ventilation

Unusually Tight Construction

The air that leaks around doors and win-

dows may provide enough fresh air for

combustion and ventilation. However, in

buildings of unusually tight construction,

you must provide additional fresh air.

Unusually tight construction is de-

fined as construction where:

a. walls and ceilings exposed to the

outside atmosphere have a con-

tinuous water vapor retarder with

a rating of one perm (6 x 10-11 kg

per pa-sec-m2) or less with open-

ings gasketed or sealed

and

b. weather stripping has been

added on openable windows and

doors

and

c. caulking or sealants are applied

to areas such as joints around

window and door frames, be-

tween sole plates and floors,be-

tween wall-ceiling joints, be-

tween wall panels, at penetra-

tionsforplumbing,electrical,and

gas lines, and at other openings.

If your home meets all of the three

criteria above, you must provide ad-

ditional fresh air. See

Ventilation Air

From Outdoors

, page 6

If your home does not meet all of the

three criteria above, proceed to

De-

termining Fresh-Air Flow For Heater

Location,

page 5

104271

OWNER’S MANUAL

WARNING:Iftheareainwhichtheheatermaybeoperatedissmallerthanthatdefinedasanunconfinedspace

or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of

the methods described in the

National Fuel Gas Code, ANS Z223.1, Section 5.3

or applicable local codes.

Continued

AIR FOR

COMBUSTION AND

VENTILATION

Continued

DETERMINING FRESH-AIR FLOW FOR HEATER LOCATION

Determining if You Have a Confined or Unconfined Space

Use this worksheet to determine if you have a confined or unconfined space.

Space:Includestheroominwhichyouwillinstallheaterplusanyadjoiningroomswithdoorlesspassagewaysorventilationgrillsbetween

the rooms.

1. Determine the volume of the space (length x width x height).

Length x Width x Height = _________________cu. ft. (volume of space)

Example:

Space size 18 ft. (length) x 16 ft. (width) x 8 ft. (ceiling height) = 2304 cu. ft. (volume of space)

If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of

the space.

2. Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support.

_________________

(volume of space) ÷50 cu. ft. =

(Maximum Btu/Hr the space can support)

Example:

2304 cu. ft. (volume of space) ÷50 cu. ft. = 46.1 or 46,100 (maximum Btu/Hr the space can support)

3. Add the Btu/Hr of all fuel burning appliances in the space.

Vent-free heater _______________ Btu/Hr

Gas water heater* _______________ Btu/Hr

Gas furnace _______________ Btu/Hr

Vented gas heater _______________ Btu/Hr

Gas fireplace logs _______________ Btu/Hr

Other gas appliances*+_______________ Btu/Hr

Total =_______________ Btu/Hr

* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.

4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.

____________Btu/Hr (maximum the space can support)

____________Btu/Hr (actual amount of Btu/Hr used)

Example:

46,100 Btu/Hr (maximum the space can support)

50,000 Btu/Hr (actual amount of Btu/Hr used)

ThespaceintheaboveexampleisaconfinedspacebecausetheactualBtu/HrusedismorethanthemaximumBtu/Hrthespacecan support.

You must provide additional fresh air. Your options are as follows:

A. Rework worksheet, adding the space of an adjoining room. If the extra space provides an unconfined space, remove door to adjoin-

ing room or add ventilation grills between rooms. See Ventilation Air From Inside Building, page 6.

B. Vent room directly to the outdoors. See Ventilation Air From Outdoors, page 6.

C. Install a lower Btu/Hr heater, if lower Btu/Hr size makes room unconfined.

If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support, the space is an unconfined space. You will need no

additional fresh air ventilation.

Example:

Gas water heater 44,000 Btu/Hr

Vent-free heater +6,000 Btu/Hr

Total =50,000 Btu/Hr

104271

BLUE FLAME NATURAL GAS HEATER

Figure 2 - Ventilation Air from Inside Building

Remove

Door into

Adjoining

Room,

Option 3

Ventilation Grills

Into Adjoining Room,

Option 2

12"

Ventilation

Grills

into Adjoining

Room,

Option 1

AIR FOR

COMBUSTION AND

VENTILATION

Continued

VENTILATION AIR

Ventilation Air From Inside

Building

Thisfreshairwouldcomefromanadjoining

unconfined space. When ventilating to an

adjoining unconfined space, you must pro-

vide two permanent openings: one within

12" of the ceiling and one within 12" of the

floor on the wall connecting the two spaces

(seeoptions1and2,Figure2).Youcanalso

remove door into adjoining room (see op-

tion 3, Figure 2). Follow the National Fuel

Gas Code NFPA 54/ANS Z223.1, Section

5.3, Air for Combustion and Ventilation for

required size of ventilation grills or ducts.

WARNING: Rework work-

sheet, adding the space of the

adjoiningunconfinedspace.The

combined spaces must have

enough fresh air to supply all

appliances in both spaces.

Figure 3 - Ventilation Air from Outdoors

Outlet

Air Ventilated

Attic

Outlet

Air

Inlet

Air

Inlet Air Ventilated

Crawl Space

Crawl

Space

To Attic

Ventilation Air From Outdoors

Provide extra fresh air by using ventilation

grills or ducts. You must provide two per-

manent openings: one within 12" of the

ceiling and one within 12" of the floor.

Connecttheseitemsdirectlytotheoutdoors

orspacesopentotheoutdoors.Thesespaces

include attics and crawl spaces. Follow the

National Fuel Gas Code NFPA 54/ANS

Z223.1, Section 5.3, Air for Combustion

and Ventilation for required size of ventila-

tion grills or ducts.

IMPORTANT:

Do not provide openings for

inletoroutletairintoatticifattichasathermo-

stat-controlled power vent. Heated air enter-

ing the attic will activate the power vent.

104271

OWNER’S MANUAL

Figure 5 - Mounting Screw Locations

Mounting

Screw

Locations

8 7/8"

Minimum To

Maintain 6"

Clearance

From Wall

7 3/4"

20 1/4"

Minimum To

Maintain 3"

Clearance

From Floor

FLOOR

JOINING WALL

INSTALLING HEATER TO

WALL

Marking Screw Locations

1. Determine whereyouwill locate heater.

2. Mark two mounting screw locations on

wall (see Figure 5).

WARNING:Maintainminimum

clearances shown in Figure 5. If

you can, provide greater clear-

ancesfromfloorandjoiningwall.

Forconvenienceandefficiency,installheater

• where there is easy access for operation,

inspection, and service

• in coldest part of room

Figure4-MountingClearancesAsViewed

From Front of Heater

36"

FLOOR

CEILING

Minimum

Minimum T

Of Carpetin

Combustib

Minimum

From

Sides Of

Heater

Right

Side

Left

Side

INSTALLATION

CHECK GAS TYPE

Use only natural gas. If your gas supply is

notnatural, donotinstall heater.Calldealer

where you bought heater for proper type

heater.

INSTALLATION ITEMS

Beforeinstallingheater,makesureyouhave

the items listed below:

• piping (check local codes)

• sealant (resistant to propane/LP gas)

• equipment shutoff valve *

• ground joint union

• test gauge connection *

• sediment trap

• tee joint

• pipe wrench

* A CSA/AGA design-certified equipment

shutoff valve with 1/8" NPT tap is an ac-

ceptable alternative to test gauge connec-

tion. Purchase the optional A.G.A. design-

certifiedequipmentshutoffvalvefromyour

dealer. See Accessory, page 18.

WARNING: A qualified ser-

vice person must install heater.

Follow all local codes.

LOCATING HEATER

This heater is designed to be mounted on a

wall.

WARNING:Maintainthemini-

mumclearancesshowninFigure

4.Ifyoucan,providegreaterclear-

ancesfromfloor,ceiling,andjoin-

ing wall.

CAUTION: If you install the

heater in a home garage

• heater pilot and burner must

be at least 18 inches above

floor

• locateheaterwheremovingve-

hicle will not hit it

IMPORTANT:

Vent-freeheatersaddmois-

ture to the air. Although this is beneficial,

installing heater in rooms without enough

ventilation air may cause mildew to form

from too much moisture. See Air for Com-

bustion and Ventilation, pages 4 through 6.

WARNING: Never install the

heater

• in a recreational vehicle

• where curtains, furniture,

clothing, or other flammable

objectsarelessthan36inches

from the front, top, or sides of

the heater

• as a fireplace insert

• in high traffic areas

• in windy or drafty areas

Minimum To

Top Surface

Of Carpeting,

Tile Or Other

Combustible

Material

Continued

CAUTION: This heater cre-

ates warm air currents. These

currents move heat to wall sur-

faces next to heater. Installing

heater next to vinyl or cloth wall

coverings or operating heater

where impurities (such as to-

bacco smoke, aromatic candles,

cleaning fluids, oil or kerosene

lamps, etc.) in the air exist, may

discolor walls.

NOTICE: This heater is intended

foruseassupplementalheat.Use

this heater along with your pri-

mary heating system. Do not in-

stall this heater as your primary

heatsource.Ifyouhave a central

heating system, you may run

system’scirculatingblowerwhile

usingheater.Thiswillhelpcircu-

late the heat throughout the

house. In the event of a power

outage, you can use this heater

as your primary heat source.

104271

BLUE FLAME NATURAL GAS HEATER

Installing Two Mounting Screws

Note:

Wall anchors and mounting screws

areinhardwarepackage.Thehardwarepack-

age is provided with heater.

Attaching To Wall Stud Method

For attaching mounting screw to wall stud

1. Drill holeat markedlocation using9/64"

drill bit.

2. Insert mounting screw into wall stud.

3. Tighten screw until 1/16" space (thick-

ness of penny) is between screwhead

and wall.

Attaching To Wall Anchor Method

Follow instructions below to attach mount-

ing screws to hollow walls (wall areas be-

tween studs) or solid walls (concrete or

masonry).

1. Drill holes at marked locations using

5/16"drillbit.For solid walls (concrete

or masonry), drill at least 1 1/4" deep.

2. Fold wall anchor (see Figure 6).

3. Insert wall anchor (wings first) into

hole. Tap anchor flush to wall.

4. For thin walls (1/2" or less), insert red

key into wall anchor. Push red key to

“pop”open anchorwings (seeFigure7).

IMPORTANT:

Do not hammer key!

Forthick walls (over1/2"thick) or solid

walls, do not pop open wings.

5. Tighten two screws until 1/16" space

(thickness of penny) is between

screwheads and wall (see Figure 8).

Figure 6 - Folding Anchor

Figure 7 - Popping Open Anchor Wings

For Thin Walls

Thin Walls (1/4" to 1/2" thick)

ANCHOR

Thin or

Thick Wall

(thick wall

shown)

Solid

Wall

1/16"

Space

Figure 8 - Tightening Anchors

INSTALLATION

Continued

Placing Heater On Mounting

Screws

1. Locate two keyhole slots on back panel

of heater (see Figure 9).

2. Place large openings of slots over

screwheads. Slide heater down until

screws are in small portion of slots.

Figure 11 - Installing Bottom Mounting

Screw

Figure 9 - Location Of Keyhole Slots On

Back Panel Of Heater

Removing Front Panel Of Heater

1. Remove two screws near bottom cor-

ners of front panel.

2. Liftstraightupongrillguarduntilitstops.

Grill guard will slide up about 1/4".

3. Pull bottomoffront panel forward,then

down.

Keyhole Slots

Installing Bottom Mounting

Screw

1. Locate bottom mounting hole. This

hole is near bottom on back panel of

heater (see Figure 11).

2. Mark screw location on wall.

3. Remove heater from wall.

4. If installing bottom mounting screw

into hollow or solid wall, install wall

anchor. Follow steps 1 through 5 un-

der Attaching To Wall Anchor Method.

If installing bottom mounting screw

into wall stud, drill hole at marked lo-

cation using 9/64" drill bit.

5. Replace heater on wall.

6. Insert bottom anchor screw through

backpanel into bottomanchoror drilled

hole (see Figure 11).

7. Tighten screw until heater is firmly se-

cured to wall. Do not over tighten.

Note:

Do not replace front panel at this

time. Replace front panel after making

gas connections and checking for leaks

(see pages 9 and 10).

Figure 10 - Removing Front Panel Of

Heater

104271

OWNER’S MANUAL

* ACSA/AGAdesign-certifiedequipmentshutoffvalvewith1/8"NPTtapisanacceptable

alternative to test gauge connection. Purchase the optional CSA/AGA design-certified

equipment shutoff valve from your dealer. See Accessory, page 18.

Tee Joint

Reducer

Bushing to

1/8" NPT

Plug Tap

Test

Gauge

Connection *

Pressure

Regulator

Tee

Joint

Pipe

Nipple

Cap

Sediment Trap

Heater

Cabinet

3/8" NPT

Pipe Nipple

Ground Joint Union

Equipment

Shutoff

Valve *

From

Gas Meter

(4" W.C. to

10.5" W.C.

Pressure)

Figure 12 - Gas Connection

3" Minimum

CONNECTING TO GAS

SUPPLY

WARNING:Aqualifiedservice

person must connect heater to

gassupply.Followalllocalcodes.

IMPORTANT

:Checkgas line pressurebe-

fore connecting heater to gas line. Gas line

pressure must be no greater than 14 inches

of water. If gas line pressure is higher,

heater regulator damage could occur.

Installationmustincludeaequipmentshutoff

valve,groundjoint union, and plugged 1/8"

NPT tap. Locate NPT tap within reach for

test gauge hook up. NPT tap must be up-

stream from heater (see Figure 12). An

appliancemaingasvalve(equipmentshutoff

valve) shall be provided in an accessible

location for turning on or shutting off the

gas to the appliance.

IMPORTANT:

Installanequipmentshutoff

valve in an accessible location. The equip-

ment shutoff valve is for turning on or

shutting off the gas to the appliance.

CAUTION: Use only new,

black iron or steel pipe. Inter-

nally-tinned copper tubing may

be used in certain areas. Check

your local codes. Use pipe 3/8"

diameter or greater to allow

proper gas volume to heater. If

pipe is too small, undue loss of

pressure will occur.

WARNING: Never connect

heater to private (non-utility) gas

wells. This gas is commonly

known as wellhead gas.

CAUTION:Usepipejointseal-

ant that is resistant to liquid pe-

troleum (LP) gas.

Continued

INSTALLATION

Continued

Install sediment trap (trap) in supply line as

shown in Figure 12. Locate sediment trap

whereitiswithinreachforcleaning.Locate

sediment trap where trapped matter is not

likelyto freeze.A sedimenttrap trapsmois-

ture and contaminants. This keeps them

fromgoinginto heater controls. If sediment

trap is not installed or is installed wrong,

heater may not run properly.

IMPORTANT:

Hold pressure regulator

with wrench when connecting it to gas pip-

ing and/or fittings.

WARNING:Thisappliancere-

quires a 3/8" NPT (National Pipe

Thread) inlet connection to the

pressure regulator.

Apply pipe joint sealant lightly to male

threads. This will prevent excess sealant

fromgoing into pipe. Excesssealantin pipe

could result in clogged heater valves.

104271

BLUE FLAME NATURAL GAS HEATER

CHECKING GAS

CONNECTIONS

WARNING: Test all gas pip-

ing and connections for leaks

after installing or servicing. Cor-

rect all leaks at once.

WARNING: Never use an

open flame to check for a leak.

Apply a mixture of liquid soap

and water to all joints. Bubbles

forming show a leak. Correct all

leaks at once.

Pressure Testing Gas Supply

Piping System

Test Pressures In Excess Of 1/2 PSIG

(3.5 kPa)

1. Disconnect appliance with its appliance

maingasvalve(controlvalve)andequip-

ment shutoff valve from gas supply pip-

ingsystem.Pressuresinexcessof1/2psig

will damage heater regulator.

2. Cap off open end of gas pipe where

equipmentshutoffvalve was connected.

3. Pressurizesupplypiping system by either

usingcompressedairoropeningmaingas

valve located on or near gas meter.

4. Check all joints of gas supply piping

system. Apply mixture of liquid soap

and water to gas joints. Bubbles form-

ing show a leak.

5. Correct all leaks at once.

6. Reconnect heater and equipment

shutoff valve to gas supply. Check re-

connected fittings for leaks.

Test Pressures Equal To or Less Than

1/2 PSIG (3.5 kPa)

1. Close equipmentshutoffvalve(seeFig-

ure 13).

2. Pressurize supply piping system by ei-

ther using compressed air or opening

main gas valve located on or near gas

meter.

3. Check all joints from gas meter to

equipment shutoff valve (see Figure

14). Apply mixture of liquid soap and

water to gas joints. Bubbles forming

show a leak.

4. Correct all leaks at once.

Pressure Testing Heater Gas

Connections

1. Open equipmentshutoffvalve(seeFig-

ure 13).

2. Open main gas valve located on or near

gas meter.

3. Make sure control knob of heater is in

the OFF position.

4. Check alljointsfrom equipment shutoff

valve to control valve (see Figure 14).

Apply mixture of liquid soap and wa-

ter to gas joints. Bubbles forming show

a leak.

5. Correct all leaks at once.

6. Light heater (see Operating Heater,

pages 10 and 11). Check the rest of the

internal joints for leaks.

7. Turn off heater (see To Turn Off Gas

To Appliance, page 11).

8. Replace front panel.

POSI

Figure 13 - Equipment Shutoff Valve

Equipment

Shutoff

Valve

Open

Closed

Figure 14 - Checking Gas Joints

Control Valve Location

Gas Meter

Equipment

Shutoff

Valve

OPERATING

HEATER

FOR YOUR SAFETY

READ BEFORE

LIGHTING

A. Thisappliancehas apilotwhichmust

belighted byhand.Whenlighting the

pilot,followtheseinstructionsexactly.

B. BEFORE LIGHTING smell all

aroundtheapplianceareaforgas.Be

suretosmellnexttothefloor because

some gas is heavier than air and will

settle on the floor.

WHAT TO DO IF YOU SMELL

GAS

• Do not try to light any appliance.

• Donottouchanyelectricswitch;do

notuseanyphone in yourbuilding.

• Immediatelycall yourgassupplier

from a neighbor’s phone. Follow

the gas supplier’s instructions.

• If you cannot reach your gas sup-

plier, call the fire department.

C. Useonlyyour handtopushin or turn

thegascontrolknob. Neverusetools.

If the knob will not push in or turn

by hand, don’t try to repair it, call a

qualified service technician or gas

supplier. Force or attempted repair

may result in a fire or explosion.

D. Do not use this appliance if any part

has been under water. Immediately

call a qualified service technician to

inspect the appliance and to replace

any part of the control system and

any gas control which has been un-

der water.

WARNING: If you do not fol-

low these instructions exactly, a

fireorexplosionmayresultcaus-

ing property damage, personal

injury or loss of life.

INSTALLATION

Continued

Other manuals for Vanguard VN600BA

Table of contents

Other Desa Gas Heater manuals

Desa

Desa ROPANE CONSTRUCTION HEATER User manual

Desa

Desa RCP25 User manual

Desa

Desa Comfort Glow CGP10RLA Quick start guide

Desa

Desa Comfort Glow CCL3924NR Quick start guide

Desa

Desa GWN6 User manual

Desa

Desa HDLE2824NRA User manual

Desa

Desa Comfort Glow CGR35PA Quick start guide

Desa

Desa CBT30NT User manual

Desa

Desa Comfort Glow CGN10T Quick start guide

Desa

Desa Comfort Glow RFN30TA Quick start guide

Desa

Desa Comfort Glow CCL3930NTA Quick start guide

Desa

Desa HDR16PT Original instructions

Desa

Desa Firewerks MVO18VNA Quick start guide

Desa

Desa CGP20B Quick start guide

Desa

Desa VN1000BTA Quick start guide

Desa

Desa Comfort Glow CGP10T Quick start guide

Desa

Desa GWRN10 Original instructions

Desa

Desa Comfort Glow CGD3924PRA Quick start guide

Desa

Desa LSL18NT Original instructions

Desa

Desa FLAME-MAX VYM27NR Quick start guide

Desa

Desa CF18PV Operation manual

Desa

Desa FLAME-MAX FVFM27NR Quick start guide

Desa

Desa GWRP16 Original instructions

Desa

Desa Comfort Glow RFN30T Quick start guide

Popular Gas Heater manuals by other brands

Superior

Superior BGE18NV Installation and operation instructions

Dru

Dru Room-sealed atmospheric gas-fired heating... user manual

klover

klover TKR 35 user guide

Rothenberger Industrial

Rothenberger Industrial 035984 instruction manual

New Buck Corporation

New Buck Corporation 34 user manual

Hargrove

Hargrove Timberland Glow Operation and installation guide

Kinder

Kinder Cameo BF Installation and maintenance instructions

Qlima

Qlima GH 438 B-2 Directions for use

Gasmate

Gasmate AH100 Series instructions

Medallion

Medallion MBP20TLB OWNER'S OPERATION AND INSTALLATION MANUAL

Clarke

Clarke DEVIL 910SS User instructions

Superior

Superior BGE18NR Operation instructions

Brant Radiant Heaters

Brant Radiant Heaters QTD Series User instruction

L.B. White

L.B. White Therma Grow HW220 Owner's manual and instructions

Sealey

Sealey LP35.V5 instructions

Italkero

Italkero Falo Evo User manual and assembly instructions

Williams

Williams 2509822A owner's manual

Romotop

Romotop Heckla 1301 Installation, operator and maintenance manual
