Denon DRA-900H User manual
Quick
Start
Guide
DRA-900H
NETWORK STEREO RECEIVER
1. DRA-900HE2_QSG_ENG_00A_230622.indd 11. DRA-900HE2_QSG_ENG_00A_230622.indd 1 2023/07/05 15:04:462023/07/05 15:04:46
1
Thank you for choosing a Denon stereo receiver.
This guide provides step-by-step instructions for setting up your stereo receiver.
Please do not return this unit to the store – call for assistance.
If you need help… :
If you need additional help in solving problems, contact Denon customer service in your area.
www.denon.com
Welcome
1. DRA-900HE2_QSG_ENG_00A_230622.indd 11. DRA-900HE2_QSG_ENG_00A_230622.indd 1 2023/07/05 15:04:462023/07/05 15:04:46
2
EN
DE
FR
IT
ES
NL
SV
RU
PL
Before you begin
• When connecting this unit to a device that is compatible with the Deep Color, 4K and ARC functions, use a “High Speed HDMI cable with
Ethernet” that displays the HDMI logo.
• When connecting this unit to a device that is compatible with 8K and 4K 120Hz video, use a certified “Ultra High Speed HDMI cable”. If you
use a different HDMI cable, the video may not display or other problems may occur.
Optional
TV Subwoofer cable
HDMI® cable Ethernet cable
Subwoofer Wi-Fi® router
Required for setup
Speakers
Speaker cables
or
1. DRA-900HE2_QSG_ENG_00A_230622.indd 21. DRA-900HE2_QSG_ENG_00A_230622.indd 2 2023/07/05 15:04:462023/07/05 15:04:46
3
Setup by connecting to TV Page4
Setup
Setup without connecting to TV Page9
What’s in the box
Quick Start
Guide Power cord
Safety
instructions
DAB/FM indoor
antenna
Cautions on
using batteries
Remote control
(RC-1259)
Notes on radio 2× R03/AAA
batteries
Receiver
1. DRA-900HE2_QSG_ENG_00A_230622.indd 31. DRA-900HE2_QSG_ENG_00A_230622.indd 3 2023/07/05 15:04:472023/07/05 15:04:47
4
EN
DE
FR
IT
ES
NL
SV
RU
PL
Rotate the antenna upwards for the best possible
reception.
Optional
If you are connecting the receiver to a wired network, connect
an Ethernet cable (not included) between the receiver and your
router. Do not connect the Ethernet cable if you are connecting
the receiver to a wireless network.
Router
LAN port
• The antennas are required for both Bluetooth and Wi-Fi
functions.
Setup by connecting to TV
Rotate the antennas
1. DRA-900HE2_QSG_ENG_00A_230622.indd 41. DRA-900HE2_QSG_ENG_00A_230622.indd 4 2023/07/05 15:04:472023/07/05 15:04:47
5
HDMI IN
(ARC)
HDMI OUT
TV
(ARC)
HDMI cable
Receiver (Rear panel)
Using a high quality HDMI cable*, connect one end to the HDMI
port labeled “ARC” on your TV. Connect the other end to the
HDMI OUT TV port on your receiver.
What is ARC?
Audio Return Channel or “ARC” sends audio back to the receiver
using the same HDMI cable that sends video from your receiver
to your TV. This allows your receiver to process the sound from
your TV’s built-in tuner and apps.
* For 4K TVs, we recommend using an HDMI cable labeled “High
Speed” and “with Ethernet” .
* For 8K TVs, we recommend using an HDMI cable labeled
“Ultra High Speed”.
Connect the receiver to your TV
Place the receiver near your TV and connect the power
cord.
TV
Receiver
Power cord
Connect the power cord
1. DRA-900HE2_QSG_ENG_00A_230622.indd 51. DRA-900HE2_QSG_ENG_00A_230622.indd 5 2023/07/05 15:04:472023/07/05 15:04:47
6
EN
DE
FR
IT
ES
NL
SV
RU
PL
TV remote control
HDMI
or
INPUT
TV/
VIDEO
TV remote control
Turn on the TV
Select the appropriate HDMI
input on your TV
Install batteries in the receiver
remote control
• Batteries can be taken out in reversed order.
1. DRA-900HE2_QSG_ENG_00A_230622.indd 61. DRA-900HE2_QSG_ENG_00A_230622.indd 6 2023/07/05 15:04:472023/07/05 15:04:47
7
• In case the unit was already setup back in time the Setup
Assistant won't start automatically and you only see the
Denon logo on screen. In such case you can access the Setup
Assistant by pressing SETUP on the remote control and
selecting Setup Assistant from the menu.
Press Xon the remote control.
Turn on the receiver
Verify that you can see this screen on your TV.
Please select a language...
Stereo Receiver Setup Assistant
[1/7]
Français
Deutsch
Italiano
Español
English
If this screen is not displayed, please go back and retry the
steps again in the recommended sequence.
Verify the connection
1. DRA-900HE2_QSG_ENG_00A_230622.indd 71. DRA-900HE2_QSG_ENG_00A_230622.indd 7 2023/07/05 15:04:482023/07/05 15:04:48
8
EN
DE
FR
IT
ES
NL
SV
RU
PL
The TV is now connected to the receiver.
The Setup Assistant will walk you through connecting and
configuring your speakers and components to your Denon
receiver. Use the remote control and follow the instructions
on the TV screen to complete the receiver settings using the
Setup Assistant.
Setup Assistant Complete!
Setup is now complete.
Your Stereo Receiver is now properly configured to provide you
with the best possible sound and video experience.
Enjoy!
Done
After completing the on-screen
Setup Assistant Page20
Follow the on-screen Setup
Assistant Firmware update
If you see this screen after completing Setup Assistant, select
Update Now to make sure your new receiver is up to date with
the latest firmware and features.
The following features are available for your Stereo Receiver.
Estimated time to install: min
Update Later Update Now
1. DRA-900HE2_QSG_ENG_00A_230622.indd 81. DRA-900HE2_QSG_ENG_00A_230622.indd 8 2023/07/05 15:04:482023/07/05 15:04:48
9
Setup without connecting
to TV
Connect your speakers
21 3 4
Subwoofer RL
10 mm
Connect your source device
Ex.) Connect to CD player
L
R
L
R
CD player
1 2 3 4
1. DRA-900HE2_QSG_ENG_00A_230622.indd 91. DRA-900HE2_QSG_ENG_00A_230622.indd 9 2023/07/05 15:04:482023/07/05 15:04:48
