DeLonghi CGH800 Installation instructions manual

PANINI GRILL

GRILL A CONTACT

PARILLA A CONTACTO

GRIGLIA A CONTATTO

IMPORTANT INSTRUCTIONS

SAVE THESE INSTRUCTIONS

MODE D’EMPLOI IMPORTANT

CONSERVEZ LES PRESENTES INSTRUCTIONS

INSTRUCCIONES PARA EL USO

REPASE Y GUARDE ESTAS INSTRUCCIONES

ISTRUZIONI IMPORTANTI

CONSERVARE LE ISTRUZIONI

CGH800

CGH800USA/CND 25-06-2003 19:22 Pagina 1

CGH800USA/CND 25-06-2003 19:22 Pagina 2

DESCRIPTION OF

APPLIANCE

AHandle

BGrill plate release

catch

CNon-stick top grill

plate

DHandgrip

ECord wrap

FNon-stick bottom

grill plate

GCooking level

indicator

HThermostat knob

I"READY" indicator

light

L"ON/OFF" indicator

light

MOil and grease

drainage

NOil and grease

drainage cup

MIN

MED

MAX

ON/OFF

READY

ON/OFF

READY

MIN

MED

MAX

Pos.1 Pos.2

DESCRIPTION DE

L’APPAREIL

APoignée

BClip de verrouillage

CPlaque supérieure

anti-adhésive

DPoignées pour mani-

puler l'appareil

ERange-cordon

FPlaque inférieure

anti-adhésive

GIndicateur de cuisson

HBouton thermostat

IVoyant lumineux

"READY"

LVoyant lumineux

"ON/OFF"

MÉcoulement des

graisses

NBac à graisses

DESCRIPCION DEL

APARATO

AAsa

BGancho de cierre

CPlancha superior

antiadherente

DEmpuñadura

EPortacable

FPlancha inferior

antiadherente

GIndicador de grado

de cocción

HMando del

termostato

ILámpara piloto

“READY”

LLámpara piloto

“ON/OFF

MSalida grasa

NRecipiente recoge

grasa

DESCRIZIONE

DELL’APPARECCHIO

AManiglia

BGancio di chiusura

CPiastra superiore

antiaderente

DImpugnatura

EPortacavo

FPiastra inferiore

GIndicatore grado

cottura

HManopola termostato

ILampada spia

“READY”

LLampada spia

“ON/OFF”

MDrenaggio grassi

NContenitore raccogli

grasso

CGH800USA/CND 25-06-2003 19:22 Pagina 3

Thank you for purchasing a De’Longhi product.

De’Longhi is well known throughout Europe and the world for

its high-quality, long-lasting Italian designed products.

We are sure that you will enjoy your De’Longhi product for

many years to come.

If you have any questions or comments regarding your new

De’Longhi product, or any of our products, please feel free to

1-800-322-3848

We will be happy to answer any questions you have.

Buon Appetito

CGH800USA/CND 25-06-2003 19:22 Pagina 4

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed,

including the following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs as the upper surface may become

very hot during use.

3. To protect against electrical shock, do not immerge cord, plugs or any part of the unit

in water or any liquid.

4. Close supervision is necessary when any appliance is used by or near children.

5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on

or taking off parts, and before cleaning the appliance.

6. Do not operate any appliance with a damaged cord or plug or after the appliance

malfunctions, or has been damaged in any manner. Return appliance to the nearest

authorized service center for examination, repair or adjustment.

7. The use of accessory attachments not recommended by the appliance manufacturer

may cause injuries.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces.

10. Do not place on or near a hot gas or electric burner, or in a heated oven.

11. Plug cord into wall outlet. To disconnect turn any control to “Off”, then remove plug

from wall outlet.

12. Do not use this appliance for other than intended use.

13. Do not immerge in water.

14.

Extreme caution must be used when moving an appliance containing hot oil or

other hot liquids.

WARINING: charcoal or similar combustible fuels must not be used with this appliance.

SAVE THESE INSTRUCTIONS

Your product is equipped with a polarized alternating current line plug (a plug having one

blade wider than the other). This plug will fit into the power outlet only one way. This is a

safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If

the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not

defeat the safety purpose of the polarized plug.

USA

CGH800USA/CND 25-06-2003 19:22 Pagina 5

INSTALLING THE GRILL

1. Before using the grill, make sure that it has not been damaged in any way

during transportation.

2. Place the appliance on a flat surface well out of the reach of children, as high

temperatures are generated during use.

3. Before plugging the appliance into the outlet, check that:

•the supply voltage corresponds to that indicated on the rating plate fitted on

the appliance;

•the power on the outlet is minimum 10A;

•the outlet is suitable for the type of plug fitted on the appliance; if not it

should be changed;

•the outlet is grounded. The manufacturer does not accept any liability for

damage caused as a result of non-compliance with this requirement.

4Before using the grill for the first time, switch it on and let it to heat up in the

barbecue grill position (pos.2) without any food, for at least 5 minutes; open the

window in order to eliminate any unpleasant smell that tends to be given off

when an appliance is new.

USING THE APPLIANCE

-Plug into the outlet and adjust the thermostat (H) to the required position. The

ON/OFF indicator light (L) will come on. Pre-heat the appliance with the grill pla-

tes closed.

-When the appliance has reached the required temperature, the "READY" indicator

light (I) will come on.

- Place the food to be grilled on the grill plates.

- Place the oil and grease drainage cup (N) under the oil and grease drainage chan-

nel.

-To turn the appliance off, turn the thermostat knob counter-clockwise until it

stops and unplug from the outlet.

-After cooking, unplug the appliance and leave to cool.

- The release catch (B) enables the appliance to be closed (position 1) for easy

transport.

- The appliance has a hinged top plate to adapt to foods of any thickness.

Never touch the plates with sharp implements as this could damage the

coating.

COOKING TIPS

-Thawed and marinated meat should be dried thoroughly before being placed on

the grill.

-Meat should be seasoned before grilling but salt can be added at time of serving.

-Food which is to be contact-grilled should be uniformly thick to ensure even

browning.

-When cooking fish, the bottom plate (F) must always be greased.

-Anumber of recipes suitable for the grill have been provided.

Please note that the cooking times given are only approximate.

They may vary, depending on the food being cooked (temperature prior to

cooking, water content) and individual preference.

CGH800USA/CND 25-06-2003 19:22 Pagina 6

CLEANING

CAUTION: make sure your grill is unplugged and cooled before attempting to

clean. To protect against electric shock, do not immerse cord, plug or unit in

water or other liquid.

1. The outside of your grill can be cleaned by wiping the surface with a damp, soft

cloth.

CAUTION: never immerse the grill in water or other liquid.

2. Clean the grill plates by wiping the surface with a damp, soft cloth.

Clean the oil and grease drainage cup with warm water and mild detergent.

Rinse and dry thoroughly.

CGH800USA/CND 25-06-2003 19:22 Pagina 7

FOOD TEMP.

SETTING GRILL

POSITION TIME REMARKS AND TIPS

Pork Chops (1) max 1 6’-8’ Pork chops should be of even thickness.

Hamburger (2) max 1 3’-5’ Wait 2-3’ before opening the plate, otherwise

the burgers will break up.

Steak (1) med 1 2’-3’ Meat cooked rare in time indicated

Pork steak (1) max 1 2’-3’ Meat cooked rare in time indicated

Spare ribs (3) max 1 15’-18’ Turn ribs after 10’

Liver (2) med 1 2’-3’ Clean liver thoroughly

Kebabs (3) max 1 8’-10’ Turn after 4-5’

Chicken (1 kg) med 1 75’-80’ Cut open in half, do not turn

Sausage (3) max 1 3’-5 Cut in half

Fresh sausage (2) max 1 4’-6’ Cut in half

Salmontroutfillet(1) med 2 16’-20’

Grease the plate and turn halfway through cooking

Salmon steak (1) med 2 16’-20’

Grease the plate and turn halfway through cooking

Sole (1) med 2 18’-22’

Grease the plate and turn halfway through cooking

Aubergines

(6 slices) med 1 6’-8’ Slice evenly

Courgettes

(7 slices) med 1 6’-8’ Slice evenly

1 pepper/capsi-

cum (quarters) med 1 6’-8’ Close the grill plates and press down

Onions (sliced) med 1 6’-8’ Slice evenly

Polenta (slices) med 1 20’-25’ Cut into 1.5 cm (1/2 inch) thick slices. Leave to

cook with plates closed for 15’

Filled bread rolls med 1 3’-9’ Use soft rolls

Toasted sandwi-

ch/Panini med 1 2’-3’ Place only half a cheese slice in each sandwich

as it tends to spill as it melts.

CGH800USA/CND 25-06-2003 19:22 Pagina 8

LIMITED WARRANTY

What Does This Warranty Cover? We warrant each appliance to be free from

defects in material and workmanship. Our obligation under this warranty is limi-

ted to replacement or repair, free of charge at our factory or authorized service

centers, of any defective or parts thereof other than parts damaged in transit,

which shall be returned to us, transportation prepaid. Please be advised that any

shipping cost for replacement items will be charged to the consumer.This war-

ranty shall apply only if the appliance is used in accordance with the factory

directions which acompany it.

How Long Does The Coverage Last? This warranty runs for one year from the

date of delivery and applies only to the original purchase for use.

What Does This Warranty Not Cover? This warranty does not cover defects or

damage of the appliance which result from repairs or alterations to the appliance

outside our factory or authorized service centers, nor shall it apply to any

appliance which has been subject to abuse, misuse, negligence or accidents.

Also, consequential and incidental damages resulting from the use of this pro-

duct or arising out of any breach of contract or breach of this warranty are not

recoverable under this warranty. Some states do not allow the exclusion or limi-

tation of incidental or consequential damages, so the above limitation may not

apply to you.

How Do You Get Service? If repairs become necessary or spare parts are nee-

ded, please write to: De’Longhi America Inc.

Park 80 West Plaza One, 4th floor

Saddle Brook N.J. 07663

or call Service Tel. No. 1-800-322-3848

The above warranty is in lieu of all other express warranties and representations.

All implied warranties are limited to the applicable warranty period set forth

above. This limitation does apply if you enter into an extended warranty with De'

Longhi. Some states do not allow limitations on how long an implied warranty

lasts, so the above exclusions may not apply to you. De' Longhi does not

authorize any other person or company to assume for it any liability in

connection with the sale or use of its appliance.

How Does State Law Apply? This warranty gives you specific legal rights, and

you may also have other rights which vary from state to state.

CGH800USA/CND 25-06-2003 19:22 Pagina 9

Nous vous remercions d'avoir choisi

un produit De' Longhi.

De' Longhi est une marque connue en Europe

et dans le monde entier pour sa haute qualité,

et pour ses produits durables et au design italien.

Nous sommes certains que vous apprécierez v

otre appareil De' Longhi

pendant de nombreuses années.

CGH800USA/CND 25-06-2003 19:22 Pagina 10

Other manuals for CGH800

Table of contents

Languages:

Other DeLonghi Grill manuals

DeLonghi

DeLonghi BQ20 User manual

DeLonghi

DeLonghi CGH 902 User manual

DeLonghi

DeLonghi BG14 User manual

DeLonghi

DeLonghi DELUX9FS21 User manual

DeLonghi

DeLonghi CG660 User manual

DeLonghi

DeLonghi CGH Series User manual

DeLonghi

DeLonghi BQ 100 User manual

DeLonghi

DeLonghi CGH 902 User manual

DeLonghi

DeLonghi CONTACT-GRILL User manual

DeLonghi

DeLonghi BQ 100 Instruction manual

DeLonghi

DeLonghi BG410 User manual

DeLonghi

DeLonghi CG6001 User manual

DeLonghi

DeLonghi DeLongi Bg24 User manual

DeLonghi

DeLonghi Grill User manual

DeLonghi

DeLonghi DELUX8BIS21 User manual

DeLonghi

DeLonghi Barbecue User manual

DeLonghi

DeLonghi Grill User manual

DeLonghi

DeLonghi CGH800 Installation instructions manual

DeLonghi

DeLonghi CGH1112D User manual

DeLonghi

DeLonghi CGH902C User manual

DeLonghi

DeLonghi CG104 User manual

DeLonghi

DeLonghi PERFECTO BG22 User manual

DeLonghi

DeLonghi DELUX9FS21 User manual

DeLonghi

DeLonghi CG 196 User manual

Popular Grill manuals by other brands

Orbegozo

Orbegozo GR 2300 instruction manual

bora

bora PT11 Operating and installation instructions

Klarstein

Klarstein 10031664 manual

Garland

Garland MWE3W Installation and operation manual

Char-Broil

Char-Broil 463722714 Product guide

Nexgrill

Nexgrill 720-0830HK Operating instruction

Kenmore

Kenmore 415.16123800 Use and care guide

Camp Chef

Camp Chef PG24CLAU Warning & instruction booklet

Tucker Barbecues

Tucker Barbecues GTR Series Assembly, installation and operating instructions

Monogram

Monogram ZGG540NCP1SS owner's manual

Equipex

Equipex Sodir Savoy Operation manual

Gaggenau

Gaggenau VR 414 610 use and care manual

Miele

Miele KM 408-1 operating instructions

George Foreman

George Foreman GGR50B owner's manual

AOG

AOG T series quick start guide

Gorenje

Gorenje TG2000CB Instruction manua

Weber

Weber Genesis Silver-B Permamount NG 051701 owner's guide

Glen

Glen SA 3037 user guide
