DeLonghi MELODY 3 User manual
www.dolce-gusto.com.au
USER MANUAL
MELODY 3
AUTOMATIC
2
TABLE OF CONTENTS
OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
PRODUCT RANGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
FIRST USE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
PREPARING A BEVERAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
RECOMMENDATIONS FOR A SAFE USE / ECONOMY MODE . . .8
CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
DESCALING AT LEAST EVERY 3-4 MONTHS. . . . . . . . . . . .12-13
IF NO LIQUID COMES OUT... . . . . . . . . . . . . . . . . . . . . . . . 10-11
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14-15
SAFETY PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3
OVERVIEW
6
9
2
8
1Water tank
2Selector wheel
3Cold
5
Locking handle
6Capsule holder
Drip grid
Capsule bin
8
10
4Hot 7Power button
9Drip tray
17/23mm
17/18mm
C
17/23mm
0-12
1.3 l 5-45 °C
41-113 °F
~3 kg
A = 20.0 cm
A
C
B
max. 15 bar B = 30.6 cm
C = 31.5 cm
220-240 V~, 50/60 Hz, 1340-1600W
AUS
LUNGO
543
10
7
OFF
ON
1
4
PRODUCT RANGE
Espresso
Espresso Intenso
60 ml
Espresso Ristretto
40 ml
Latte Macchiato
220 ml
50 ml
170 ml
Espresso Intenso
40 ml
Cappuccino
240 ml
40 ml200 ml
Lungo
120 ml
Chococino®
210 ml
110 ml
100 ml
LUNGO
Hot Beverage
ESPRESSO
CAFFÈ AMERICANO
CAPPUCCINO
Café au Lait
180 ml
Caffè Americano
230 ml
Nestea Peach
200 ml
Espresso
Espresso Intenso
60 ml
Espresso Ristretto
40 ml
Latte Macchiato
220 ml
50 ml
170 ml
Espresso Intenso
40 ml
Cappuccino
240 ml
40 ml200 ml
Lungo
120 ml
Chococino®
210 ml
110 ml
100 ml
12
5
PRODUCT RANGE
CAFÉ AU LAIT
CAPPUCCINO ICE
Café au Lait
180 ml
Caffè Americano
230 ml
Nestea Peach
200 ml
Latte Macchiato
220 ml
50 ml
170 ml
Aroma
200 ml
Caffè Crema Grande
200 ml
Aroma
200 ml
Cappuccino Ice
240 ml
105 ml135 ml
CAPPUCCINO ICE
Cold Beverage
Café au Lait
180 ml
Caffè Americano
230 ml
Nestea Peach
200 ml
NESTEA PEACH
12
LATTE MACCHIATO
Latte Macchiato
220 ml
50 ml
170 ml
Aroma
200 ml
GrandeCaffèCrema
200 ml
Aroma
200 ml
12
6
FIRST USE
1
4
7
2
5
8 9
3
30 sec
ON
6
Rinse water tank at fi rst.
Fill water tank with fresh, drinking water.
Place cap and insert water tank into machine.
Start rinsing with cold water:
Set bar display to max. level with selector
wheel.
Press cold water button.
Machine starts rinsing.
Wait until countdown is fi nished and machine
stops.
Open locking handle and insert empty capsule
holder. Close locking handle.
Place capsule bin under outlet.
Connect power plug to mains power socket.
Machine starts rinsing.
Wait until countdown is fi nished and machine
stops.
Empty capsule bin and refi ll water tank with
fresh, potable water.
Remove protection foil from drip grid. Place
drip grid on drip tray. Then attach drip tray at
desired position on machine.
Switch machine on. While machine is heating
up, power button starts blinking red.
After approx. 30 seconds, power button lights
steady green and machine is ready.
Continue rinsing with hot water:
Set bar display to max. level with selector
wheel.
Press hot water button.
7
30 sec
PREPARING A BEVERAGE
LUNGO
1
4
7
2
5
8
3
6
9
5 sec
ON
Switch machine on. While machine is heating
up, power button starts blinking red. After ap-
prox. 30 seconds, power button lights steady
green and machine is ready.
Use the selector wheel to illuminate the bars
in accordance with the number of bars shown
on capsule, or set the bar display to your own
taste.
Take cup from drip tray. Open the locking
handle.
Adjust drip tray position according to the
chosen beverage (see page 4-5). Place cup on
drip tray.
Press hot or cold water button (depending on
beverage). Beverage preparation starts.
Bar display lights vanish progressively.
Machine stops preparation automatically.
Pull out capsule holder and remove used cap-
sule. Put used capsule in capsule bin.
Open locking handle and pull out capsule
holder. Insert capsule in capsule holder and
insert it back in machine. Close locking handle.
After fi nishing preparation, bar display fl ashes
and power button blinks red for about 5
seconds.
During that time do not open the locking
handle!
Rinse and dry capsule holder with water from
both sides. Insert capsule holder to machine.
Enjoy your beverage!
8
5 sec
ECONOMY MODE
RECOMMENDATIONS FOR A SAFE USE
5 min
ON OFF
After 5 minutes of non-usage the machine
automatically shuts down (Economy Mode).
To restart, press power button.
Never add hot water to the water tank! Never open the locking handle during
beverage preparation!
After fi nishing preparation the bar dis-
play fl ashes and the power button blinks
red for about 5 seconds. During that
time do not open locking handle!
Do not touch used capsule after
beverage preparation! Hot surface, risk
of burns!
9
CLEANING
1
4
78
2
5
3
6
ON
30 sec
Rinse drip tray with water and clean it with a
brush.
Open locking handle and insert empty capsule
holder. Close locking handle and place cap-
sule bin under the delivery outlet.
Wait until countdown is fi nished and water
delivery stops.
Empty and clean capsule bin.
Place drip grid on drip tray. Then attach drip
tray at desired position on machine.
Clean machine with a soft damp cloth. Dry it
afterwards with a soft dry cloth.
Rinse and dry capsule holder with water from
both sides. You can also put it in the dish-
washer.
Switch machine on. While machine is heat-
ing up, power button starts blinking red. After
approx. 30 seconds, power button light turns
green and machine is ready to use.
Rinse and clean water tank. Afterwards refi ll
with fresh, drinking water and insert it to ma-
chine. The water tank is not dishwasher proof!
Rinse the machine as follows:
Light up all bars to max. level using the selec-
tor wheel and press the hot button. Machine
starts rinsing. Lights on the bar display vanish
progressively.
10
IF NO LIQUID COMES OUT...
20 min
1
1 3
54
2
2
A
Error symptoms: Beverage preparation stops
part way during delivery or does not start
at all. Bar display fl ashes and power button
blinks red and green rapidly.
The capsule may be blocked and under pres-
sure.
Then lift the locking handle and remove the
capsule holder.
Throw away the capsule.
Check if there is water in the water tank:
if not, refi ll and press hot/cold button again to
continue preparation; if the water tank is full
proceed as follows:
Do not use force to lift the locking handle. Wait for 20 minutes for the pressure to reduce.
Check if locking handle can be lifted easily: NO - see section A (below) / YES – see section B (next page)
