DeLonghi DINAMICA PLUS User manual
Better Everyday
QUICK START
GUIDE
ECAM37095TI
ECAM37095TI
2
EASILY REGISTER YOUR MACHINE
& GET MORE OUT OF YOUR ESPRESSO EXPERIENCE
Register your Fully Automatic Espresso Machine and become De’Longhi Club
Member. Join the De’Longhi Club to get more out of your coffee experience.
RECEIVE 1
ADDITIONAL YEAR
OF WARRANTY
FOR REGISTERING
PRODUCT
De’Longhi Club Member discount: Only members of the Club will receive
special offers on coffee accessories.
ECAM37095TI
IN THE BOX
3
A1. Beans container lid
A2. Pre-ground coffee funnel lid
A3. Bean container
A4. Pre-ground
coffee funnel
A5. Grinding
adjustment dial
A8. Hot water and steam
connection nozzle
A9. Coffee spouts
(adjustable height)
A10. Condensate tray
A11. Coffee grounds
container
A15. Drip tray
A17. Water tank
A20. Infuser
A22. Main switch
B-C. Display Panel
D2. Pre-ground coffee
measuring scoop
D3. Milk container
D6. Hot water spout
Get Started &
Owner’s Instructions
Booklets
This short guide is not intended to explain
all the functions of the appliance.
Please read all the owner’s
instruction booklet before use.
A2 A4
A1
A5
D6
A22
A20
A9
A8
A10
B-C
A11
D3
A15 A17
A3
D2
4
B1. Bluetooth active symbol
B2. Energy Saving active symbol
B3. Selected strength
B4. Directly selected beverages
B5. Scroll arrow
B6. Quantity selected
B7. Descale required alarm
B8. Milk container needs cleaning alarm
B9. Filter needs replacing alarm
C1. Beverage quantity selection
C2. Profile selection
C3. Settings menu
C4. Exit from the selected function
and go back to the main menu
C5. My beverages selection menu.
Unless previously programmed from
the settings menu as described in
chapter “12. Customizing the
beverages“, the beverage is
programmed directly the first time
you use the appliance
C6. Beverage strength selection
B 9.
B8.
B 7.
B6.
B4.
B4.
B5.
C1.
C2.
C3.
B2.
B3.
B4.
B4.
B5.
B1.
C6.
C5.
C4.
ECAM37095TI
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
SELECT LANGUAGE
GET READY
5
Download the
De’Longhi Coffee
Link App. Connect
via Bluetooth to
your machine to
access many
functions and
settings remotely.
Remove all stickers
and clean all
accessories with
warm water and
mild detergent and
dry them. Follow
the instructions on
the display of the
machine. Priming
the machine is only
required the first
time out of the box.
4
5
1
3
The machine
will deliver hot
water and will shut off
automatically once
rinsing is complete.
6
WATER CIRCUIT EMPTY
PRESS OK TO START
6
2
6
5
34
The first time using
the machine, brew
and dump the first
3-4 espressos.
If you haven’t been
using the machine
for 3-4 days,
perform a rinsing
cycle ( setting
menu
––
>
rinsing)
before brewing.
2
1
BREW ESPRESSO
To brew the
perfect espresso
set your grinder
following the “Extraction
Guidelines” on page 9.
2
Select one of the
recipes on the
touch screen. Preparation
will start with default
strength and quantity,
which can be changed
by customizing your
recipes.
5
ECAM37095TI
MILK RECIPIES
1 2
3
To make a Milk
recipe, use the
provided milk
container. Use cold
cow milk or your
preferred milk
alternative. Whole
milk or oat milk will
give the best results.
Select a milk
based recipe.
Once finished,
twist the selector
to “clean” position to
perform a rinsing of
the milk container lid.
If you prepare multiple
milk recipes, you should
do this only after you
finished your last recipe.
Store the remaning
milk in the container
in the fridge.
6
Open the lid and
make sure the milk
intake tube is correctly
inserted in the bottom of
the milk container lid.
1
4
6
5
Use the selector to
choose between
flatter or dryer foam. On
the screen, the machine
will suggest what to
select based on your
chosen recipe.
5
COW
MILK ALMOND
MILK
OAT
MILK SOY
MILK
7
4
8
CUSTOMIZE RECIPES
Pre-ground:
To use pre-ground
coffee, press the
strength selector until
the icon shows
on the screen and
add one measuring
scoop of pre-ground
coffee in the
dedicated funnel.
Temporary
Personalization:
Temporarily
personalize the
volume and
stength
of recipes.
Temporary Personalization
Advanced
Personalization:
Save and access up
to 3 different profiles
and personalize
and save recipes with
the
function.
Advanced Personalization
Pre-ground
ECAM37095TI
9
EXTRACTION GUIDELINES
Depending on your choice of beans, you might need to adjust the grinder
setting to a finer or more coarse choice.
• Flow like warm honey
• Nut-brown Crema
• Well balanced and
lingering taste
• Flowing fast like water
• Light and pale Crema
To make it perfect:
• Adjust grinding setting
to a finer setting
• Select a higher strength
• Flowing in drips or
not at all
• Crema very dark and
not uniform
To make it perfect:
• Adjust grinding setting
to a coarser setting
• Select a lower strength
Perfect espresso Under extracted Over extracted
1 2
3
Keeping your
machine clean will
improve quality of
the beverage and
life span of the
machine.
10
CLEANING
DESCALING
Empty drip tray
daily and empty
coffee ground container
when lights come up.
Remove and clean
each part of the
milk container lid.
Follow User Manual
section 14.10.
3
Once a month,
clean the inside
of the machine. Follow
User Manual detailed
instruction section 14.9.
2
1
Promptly descale
when indication
light comes on. Follow
user Manual section 15.
4
4
