Dell PowerVault MD3200 Series User manual

Dell PowerVault

Modular Disk Storage Arrays

SMI-S Provider

Installation Guide

book.book Page 1 Friday, July 9, 2010 2:13 PM

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

____________________

Information in this publication is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.

is strictly forbidden.

Trademarks used in this text: Dell™, the DELL logo, and PowerVault™ are trademarks of Dell Inc.

Microsoft®, Windows®, and Windows Server®are either trademarks or registered trademarks of

Microsoft Corporation in the United States and/or other countries. SUSE® is a registered trademark

of Novell Inc. in the United States and other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

July 2010 Rev. A00

book.book Page 2 Friday, July 9, 2010 2:13 PM

Contents 3

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . 5

Version Information . . . . . . . . . . . . . . . . . . . . 6

Supported Profiles and Sub-Profiles . . . . . . . . . . . 6

2 Installing and Uninstalling the

SMI-S Provider . . . . . . . . . . . . . . . . . . . . . 7

System Requirements . . . . . . . . . . . . . . . . . . . 7

Installing SMI-S Provider . . . . . . . . . . . . . . . . . 7

For Windows . . . . . . . . . . . . . . . . . . . . . 7

For Linux . . . . . . . . . . . . . . . . . . . . . . . 8

Configuring CIM Server . . . . . . . . . . . . . . . . . . 8

Uninstalling SMI-S Provider. . . . . . . . . . . . . . . 10

For Windows . . . . . . . . . . . . . . . . . . . . 10

For Linux . . . . . . . . . . . . . . . . . . . . . . 11

3 Managing SMI-S Provider. . . . . . . . . . . . 13

Starting and Stopping the OpenPegasus

CIM Server . . . . . . . . . . . . . . . . . . . . . . . . 13

For Windows . . . . . . . . . . . . . . . . . . . . 13

For Linux . . . . . . . . . . . . . . . . . . . . . . 13

book.book Page 3 Friday, July 9, 2010 2:13 PM

4Contents

Adding or Removing a Storage Array From

SMI-S Provider . . . . . . . . . . . . . . . . . . . . . . 13

Changing the Debug Tracing Option. . . . . . . . . . . 14

4 Troubleshooting the SMI-S Provider . . . 15

book.book Page 4 Friday, July 9, 2010 2:13 PM

Introduction 5

Introduction

The Dell PowerVault Modular Disk (MD) storage arrays provide an industry

standard application programming interface (API) called the Storage

Management Initiative Specification (SMI-S). This interface enables third

party SMI-S client applications to manage MD storage arrays in a multi-

vendor Storage Area Network (SAN) environment.

SMI-enabled management applications are known as CIM clients. To allow

clients to manage a storage device, an SMI-S Provider (also referred as SMI-S

Agent or CIM Agent) is required. SMI-S Providers can be implemented as:

• A proxy interface that translates the existing API of a device to an SMI-S

compliant interface.

• A native feature of the storage device API. This implementation is

sometimes referred to as an

embedded agent

Dell MD SMI-S Provider is implemented as a proxy interface.

This

implementation is the quickest path to SMI-S compliance, but it requires that

the proxy provider and a Common Information Model Object Manager

(CIMOM) are installed on a server. A CIMOM is a CIM/WBEM infrastructure

that receives, validates, and authenticates CIM requests from the client

application. The CIMOM directs the requests to the appropriate device

provider.

The Dell SMI-S Provider, referred to as SMI-S Provider, must run on a server

on the storage network. OpenPegasus CIMOM is installed during the

installation of this SMI-S Provider.

The SMI-S Provider provides the SMI-S interface to the Dell PowerVault

Modular Disk storage array family. The provider uses the proxy CIM Agent

model and is supported on Windows and Linux platforms only. For the actual

versions of the platforms, see the support matrix for the MD storage arrays at

support.dell.com/manuals.

book.book Page 5 Friday, July 9, 2010 2:13 PM

6Introduction

Version Information

Table 1-1 lists the version details of the components.

Supported Profiles and Sub-Profiles

SMI-S Provider version 10.10 supports the following profiles and sub-profiles:

• Physical package

• Profile registration

• Device credentials

• Proxy server system management

• Multiple computer system

•Blockservices

•Diskdrivelite

•Copyservices

•Jobcontrol

• Extent composition

• Disk sparing

• Initiator port (SAS and SATA)

• Target port (SAS)

•iSCSItargetport

•Accesspoints

• Indications

• Masking and mapping

•Location

• Software inventory

• Software update

• Block server performance

Table 1-1. Version Information

Component Version

SMI-S 1.4

SMI-S Provider 10.10

OpenPegasus CIMOM 2.9.1

book.book Page 6 Friday, July 9, 2010 2:13 PM

Installing and Uninstalling the SMI-S Provider 7

Installing and Uninstalling the SMI-S

Provider

System Requirements

The system requirements to install and run the SMI-S Provider include:

• Memory requirements—1 GB minimum (2 GB preferred).

• Connectivity requirements—Ethernet with 100BASE-T minimum

(Gigabit Ethernet preferred), TCP/IP.

• Port requirements—TCP port 5988 or TCP port 5989, or any other

available port if these ports are not available.

• Storage array password—The device credentials profile requires the storage

array password (SharedSecret) to modify operations. The SMI-S Provider

persistently tracks an instance of the SharedSecret per storage array.

Installing SMI-S Provider

For Windows

The SMI-S Provider is packaged as an installation executable file. To install

the SMI-S Provider:

Move the SMI-S Provider installation executable file on the server where

you want to install the SMI-S Provider and double-click the installation

executable icon and follow the instructions on the screen.

During installation,

ArrayHosts.txt

file opens.

Enter the

HostName

(s)

IP Address

(s)

of the MD storage array(s) to be

managed by the host in ArrayHosts.txt, save and close the file.

CAUTION: Enter only one of the two management ports' IP addresses of each

array in this file. Do not enter the IP addresses of both management ports.

Click

Finish

The SMI-S Provider is installed on your system. After installation, you can

delete the installation executable file.

book.book Page 7 Friday, July 9, 2010 2:13 PM

8Installing and Uninstalling the SMI-S Provider

For Linux

The SMI-S Provider is packaged as an archive file.

To install the SMI-S Provider:

Move the SMI-S Provider RPM package file into the file system on the

server where you want to install SMI-S Provider.

Run the following command:

rpm -ivh <rpm package name>.rpm

NOTE: On SUSE Linux Enterprise Server platform, ensure that you set the

environment variables PEGASUS_HOME and LD_LIBRARY_PATH before

running any CLI from pegasus/bin directory (like cimcli or cimserver). Set the

environment variables to the following (assuming the /opt/dell as the default

install path)

export PEGASUS_HOME /opt/dell/pegasus

export LD_LIBRARY_PATH /opt/dell/pegasus/lib

To change the OpenPegasus CIMOM configuration, see "Configuring CIM

Server" on page 8.

Configuring CIM Server

Use the following commands to perform basic CIM server configuration

operations.

NOTE: You must restart the OpenPegasus server after executing any of the

following commands.

• To set an http port:

# cimconfig -s httpPort=<port> -p

• To set an https port:

# cimconfig -s httpsPort=<port> -p

• To enable or disable the http connection:

# cimconfig -s enableHttpConnection={true | false}

-p

• To enable or disable the https connection:

# cimconfig -s enableHttpsConnection={true |

false} -p

book.book Page 8 Friday, July 9, 2010 2:13 PM

Installing and Uninstalling the SMI-S Provider 9

• To enable or disable authentication:

# cimconfig -s enableAuthentication={false | true}

–p

• To add a user for defining the credentials for CIM client to authenticate

with the CIM server:

# cimuser -a -u username -w password

• To remove a user:

# cimuser -r -u username -w password

• To enable or disable service location protocol (SLP):

# cimconfig -s slp={true | false} -p

If SLP is enabled, see Table 2-1 for additional settings information.

Commands are of the format

cimconfig -s <propertyName>={true|false} -p

where <propertyName> is a column heading in Table 2-1.

Table 2-1. Additional Setting Information if SLP is Enabled

propertyName Behavior

runinternal

PegasusSLP

registerExternal

PegasusSLP

registerExternal

OpenSLP

Multiple

SLP

true false false false Internal Pegasus SLP is

started when CIM server

starts.

false true false false External Pegasus SLP

registration is run in

cimserver with a default

registration timeout set to

3 hours (same as the SLP

default timeout).

false false true false External OpenSLP

registration is run in CIM

server.

book.book Page 9 Friday, July 9, 2010 2:13 PM

10 Installing and Uninstalling the SMI-S Provider

NOTE: All other combinations of the SLP property values have undefined behavior.

For more information, see the documentation available in the source release

archive at openpegasus.org.

Uninstalling SMI-S Provider

For Windows

Select

Add or Remove Programs

(or

Programs and Features

for Microsoft

Windows Server 2008) in the

Control Panel

Double-click

Dell SMI-S Provider

to uninstall it.

The un-installation procedure may leave files (such as trace files, repository

files, and other administrative files) that were created by SMI-S Provider after

the installation was complete. Manually delete these files to completely

remove SMI-S Provider.

NOTE: The default install directory for SMI-S Provider is <%Program

Files%>/Dell/pegasus/provider/array

false false true true External OpenSLP

registration is attempted

and falls back to external

Pegasus SLP registration if

it fails (default setting).

false true false true External Pegasus SLP

registration is attempted

and falls back to external

OpenSLP registration if it

fails.

Table 2-1. Additional Setting Information if SLP is Enabled

(continued)

propertyName Behavior

runinternal

PegasusSLP

registerExternal

PegasusSLP

registerExternal

OpenSLP

Multiple

SLP

book.book Page 10 Friday, July 9, 2010 2:13 PM

Other manuals for PowerVault MD3200 Series

This manual suits for next models

Table of contents

Other Dell Software manuals

Dell

Dell PowerVault MD3000i User manual

Dell

Dell PowerConnect W-Airwave User manual

Dell

Dell OpenManage Network Manager User manual

Dell

Dell PowerConnect W-Airwave Use and care manual

Dell

Dell A920 - Personal All-in-One Printer Color... User manual

Dell

Dell P1913 User manual

Dell

Dell PS4110 User manual

Dell

Dell PowerConnect W-Airwave User manual

Dell

Dell DX6000 Instruction Manual

Dell

Dell PowerConnect W-Airwave Use and care manual

Dell

Dell DX6000 Operation and maintenance manual

Dell

Dell External OEMR 2800 Quick reference guide

Dell

Dell Color Laser Printer 2130cn How to use

Dell

Dell PowerEdge 180AS User manual

Dell

Dell DX6000 User manual

Dell

Dell PowerConnect W-Airwave User manual

Dell

Dell PowerEdge UPS 500T User manual

Dell

Dell External OEMR 1435 User manual

Dell

Dell PowerConnect W-Airwave User manual

Dell

Dell DX6000 User guide

Dell

Dell OPENVIEW NNM SE 1.2 User manual

Dell

Dell PowerVault 770N User manual

Dell

Dell PowerVault ML6000 User manual

Dell

Dell PowerConnect W-Airwave User manual

Popular Software manuals by other brands

COMPRO

COMPRO COMPROFM manual

Muratec

Muratec OFFICEBRIDGE ONLINE user guide

Oracle

Oracle Contact Center Anywhere 8.1 installation guide

Adobe

Adobe 65007312 - Photoshop Lightroom Programmer's guide

Avaya

Avaya NULL One-X for RIM Blackberry user guide

HP ProLiant BL420c user guide

PS Audio

PS Audio PowerPlay Programming manual

Brady

Brady LOCKOUT PRO 3.0 Administrator's guide

Avaya

Avaya Interaction Center user guide

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Guide book

Novell

Novell GROUPWISE 8 - INTERNET AGENT manual

Oracle

Oracle Application 9i Configuration guide

Acer

Acer RDM user guide

Canon

Canon Vixia HF21 instruction manual

Canon

Canon ZR950 instruction manual

Samsung

Samsung Auto Backup user manual

Polycom

Polycom Vortex EF2201 Application note

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c user manual
