Model HV02T
Dell DJ™
User’s Guide
Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you
make better use of your device.
NOTICE: A NOTICE indicates either potential damage to
hardware or loss of data and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property
damage, personal injury, or death.
Abbreviations and Acronyms
For a complete list of abbreviations and acronyms, see
"Glossary" on page 51.
____________________
Information in this document is subject to change without notice.
© 2004 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell
Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, Dell DJ and Dell Pocket DJ
are trademarks of Dell Inc.; Microsoft and Windows are registered trademarks
of Microsoft Corporation; Musicmatch is a registered trademark of Musicmatch
Inc.
Othertrademarksandtradenamesmaybeusedinthisdocumenttorefertoeither
the entities claiming the marks and names or their products. Dell Inc. disclaims
any proprietary interest in trademarks and trade names other than its own.
Model HV02T
November 2004
Contents 3
Contents
Finding Information
1About Your Device
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Front and Top Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Bottom View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Wired Remote (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Installing Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting to a Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Using the Cradle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Using the USB Synchronization Cable. . . . . . . . . . . . . . . . . . 15
Performing a Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2Using Your Dell DJ
Playing Digital Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Playing Tracks Using Music Library . . . . . . . . . . . . . . . . . . . . 17
Transferring Music to the Dell DJ. . . . . . . . . . . . . . . . . . . . . . . . . . 20
Transferring Music Tracks Using Musicmatch®to
Your Dell DJ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Contents 4
Transferring Music Tracks from Musicmatch Library. . . . . 20
Transferring Music Tracks Using Dell DJ Explorer . . . . . . . 21
Recording Voice and FM Radio Using the Dell DJ
(Available with Inline FM Tuner only) . . . . . . . . . . . . . . . . . . . . . . 24
Storing Data Files on the Dell DJ . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Managing Files from the Main Menu. . . . . . . . . . . . . . . . . . . . . . . 26
Music Library . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Now Playing and the Selected Music List. . . . . . . . . . . . . . . 30
Play Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Date and Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
3Frequently Asked Questions
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Error Indications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Troubleshooting in Rescue Mode . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4Appendix
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Finding Information 5
www.dell.com | support.dell.com
Finding Information
What are you looking for? Find it here:
How to set up my device and
information on the connectors and
buttons on my device.
Getting Started Guide
and the Dell
DJ
™
User’s Guide
Information on using my device. Dell
DJ
™
User’s Guide
Information on using Musicmatch
with my device.
Musicmatch
®
online help
Click
Start
→
Programs
→
Musicmatch
→
Musicmatch Jukebox
.
Click
Help
in Musicmatch.
Information on using Dell DJ
Explorer with my device.
Click
Start
→
Programs
→
Dell
→
Dell
DJ Explorer
→
Dell DJ Explorer Help
Connecting to and synchronizing
with a computer.
Dell
DJ
™
User’s Guide
and Musicmatch
online help
Up-to-date information on your
device including the latest software
downloads, latest versions of the
User’s Guide,
Getting Started Guide
,
and answers to the most Frequently
Asked Questions.
support.dell.com
My Service Tag Located on the back of the device.
About Your Device
Introduction
Congratulations on purchasing the Dell DJ™! In this document, you can
find instructions on how to use the key features of your new Dell DJ with the
accompanying software.
You can also find more sources of useful information in "Finding
Information" on page 5.
Your Dell DJ comes with a
Dell DJ™/Dell Pocket DJ™ Product Software
CD
that you can use to install software onto your computer. The software
includes the Dell DJ drivers, Dell DJ Explorer, and Musicmatch
®
.
You can use the software to manage your music library and to transfer audio
tracks and data files between your Dell DJ and your computer. In order to
transfer these files, your Dell DJ must be connected to your computer using
the USB synchronization cable or cradle included with your Dell DJ. See
"Installing Software" on page 12 to get started.
After installing the software on your computer, you can use your Dell DJ in a
number of ways:
• As a digital music player
• As a data storage device
For details about using these features and getting the most out of your Dell
DJ, see "Using Your Dell DJ" on page 17.
NOTICE: Dell's Limited Warranty does not cover data loss resulting from the
unlikely failure of the hard disk drive in the device.
NOTICE: While your device is robust, do not subject it to excessive force or
impact. This may damage the hard disk drive in your device.
About Your Device 7
www.dell.com | support.dell.com
Front and Top Views
VOLUME BUTTONS —Press and hold the volume buttons to increase or decrease
the volume.
POWER BUTTON —Press and hold the power button for 2 seconds to turn the
device on or off.
LOCK SWITCH —Move this to lock or unlock the buttons on your device. Lock the
buttons when you want to prevent them from being pressed accidentally.
NOTE: When your device is locked, you cannot turn your device on or off.
HEADPHONE CONNECTOR —Attach the earphones, headphones, or optional wired
remote. See "Wired Remote (Optional)" on page 9 for information.
BACK BUTTON —Press the back button to return to the previous view, or to move
back one character.
REWIND/SKIP BACK BUTTON —Press the rewind/skip back button to move to the
start of the current track, or to go to the previous track. Press and hold the
rewind/skip back button to move back within a track.
power
button
volume
buttons
rewind/skip
back button
Home
button
lock
switch
back
button
headphone
connector
scroll
dial
fast forward / skip
forward button
play/pause button
About Your Device 8
www.dell.com | support.dell.com
PLAY/PAUSE BUTTON —Press the play/pause button to start or pause a track or
recording.
SCROLL DIAL
• Press the scroll dial to perform actions similar to pressing <Enter> on
a keyboard.
• Rotate the scroll dial up or down to perform actions similar to using
the up- and down-arrow keys on a keyboard.
NOTE: In other parts of this User’s Guide, scroll-select means to rotate and
then press the scroll dial. You can scroll-select menu options and tracks.
FAST FORWARD/SKIP FORWARD BUTTON —Press the fast forward/skip forward
button to go to the next track, or to move ahead within a track.
HOME BUTTON —Press the Home button to access other functions in the device.
See "Using Your Dell DJ" on page 17 for information.
Bottom View
DOCK CONNECTOR—Connect your device to your AC adapter or computer. See
"Charging the Battery" on page 10 and "Connecting to a Computer" on page 13 for
information.
RESET BUTTON —See "Performing a Reset" on page 16 for information on using
the reset button.
reset
button
dock
connector
About Your Device 9
www.dell.com | support.dell.com
Wired Remote (Optional)
REWIND/SKIP BACK BUTTON —Press the rewind/skip back button to move to the
start of the current track, or to go to the previous track. Press and hold the
rewind/skip back button to move back within a track.
PLAY/PAUSE BUTTON —Press the play/pause button to start or pause a track or
recording. Press and hold the play/pause button for 2 seconds to turn the device on
or off.
VOLUME BUTTONS —
Press and hold
the volume buttons
to increase or decrease the
volume.
HEADPHONE CONNECTOR —
Attach earphones or headphones.
LOCK SWITCH —
Move this to lock or unlock the buttons on your wired remote. Lock
the buttons when you want to prevent them from being pressed accidentally.
NOTE: When your device is locked, you cannot turn your device on or off.
FAST FORWARD/SKIP FORWARD BUTTON —Press the fast forward/skip forward
button to go to the next track, or to move ahead within a track
.
rewind/skip
back button
play/pause
button
fast forward/skip
forward button
headphone
connector
volume
buttons
lock
switch
About Your Device 10
www.dell.com | support.dell.com
Charging the Battery
NOTE: Do not use your device until you have charged the battery for at least 2.5
hours.
Your device has an integrated, rechargeable, lithium-ion battery. Before you
use your device for the first time, you must charge the battery.
Use the battery icon on your device’s screen to monitor the battery
charge.
NOTICE: Do not attempt to replace or remove the integrated battery from your
device. You may damage the device permanently. Any attempt to open your
device voids the warranty.
1
Connect the power cable to your travel charger connector, and connect
the travel charger connector to your Dell DJ as shown.
2
Connect the other end of the power cable into a wall outlet.
Your device displays the Charging Battery icon on the top left
corner of the screen.
NOTE: You can still use your device when the battery is charging from the
AC adapter.
3
To check if the battery is fully charged after 2.5 hours, disconnect the
travel charger connector from your device. If the battery is fully
charged, your device displays the Full Battery icon .
