Dell P20T User manual
Views
Specifications
Modes
Copyright © 2015 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and
intellectual property laws. Dell and the Dell logo are trademarks of Dell Inc. in the United States and/or other
jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies.
2015-04 Rev. A00
Regulatory model: P20T | Type: P20T003
Computer model: Inspiron 11-3152
NOTE: The images in this document may differ from your computer
depending on the configuration you ordered.
3000 Series
Inspiron 11
1
1 Power/Battery status light
Indicates the power state and battery state of the
computer.
Solid white — Power adapter is connected to the
computer and the battery is being charged.
Solid yellow — Battery charge is low or critical.
Off — Power adapter is connected to the computer
and battery is fully charged or power adapter is not
connected to the computer.
Views
Specifications
Front
Left
Right
Base
Display
Front
1 Power-adapter port
Connect a power adapter to provide power to your
computer and charge the battery.
2 HDMI port
Connect a TV or another HDMI-in enabled device.
Provides video and audio output.
3 USB 3.0 port with PowerShare
Connect peripherals such as storage devices, printers,
and so on. Provides data transfer speeds up to 5 Gbps.
PowerShare allows you to charge your USB devices even
when your computer is turned off.
NOTE: If your computer is turned off or in Hibernate
state, you must connect the power adapter to
charge your devices using the PowerShare port. You
must enable this feature in the BIOS setup program.
NOTE: Certain USB devices may not charge when
the computer is turned off or in the Sleep state. In
such cases, turn on the computer to charge the
device.
4 USB 3.0 port
Connect peripherals such as storage devices, printers,
and so on. Provides data transfer speeds up to 5 Gbps.
5 Headset port
Connect a headphone, a microphone, or a headphone
and microphone combo (headset).
541 2 3
Views
Specifications
Front
Left
Right
Base
Display
Left
1 Power button
Press to turn on the computer if it is turned off or in
Sleep state.
Press to put the computer in Sleep state if it is turned on.
Press and hold for 4 seconds to force shut-down
the computer.
NOTE: You can customize the power-button
behavior in Power Options. For more information,
see Me and My Dell at dell.com/support/manuals.
2 Volume-control buttons (2)
Press to increase or decrease the volume..
3 USB 2.0 port
Connect peripherals such as storage devices, printers,
and so on. Provides data transfer speeds up to
480Mbps.
4 Media-card reader
Reads from and writes to media cards.
5 Security-cable slot
Connect a Noble security-cable to prevent unauthorized
movement of your computer.
541 2
3
Views
Specifications
Front
Left
Right
Base
Display
Right
1 Left microphone
Provides high-quality digital sound input for audio
recording, voice calls, and so on.
2 Ambient-light sensor
Detects the ambient light and automatically adjusts the
display brightness.
3 Camera
Allows you to video chat, capture photos, and
record videos.
4 Camera-status light
Turns on when the camera is in use.
5 Right microphone
Provides high-quality digital sound input for audio
recording, voice calls, and so on.
6 Windows button
Press to go to the Start screen.
2
13 4 5
6
Views
Specifications
Front
Left
Right
Base
Display
Display
Specifications
Views
System
information Memory Ports and
connectors
Dimensions and
weight
Computer
environment
Storage
Touch pad Power adapterCamera
Communications
Battery
Video Audio
Display
Media-card
reader Keyboard
Dimensions and weight
Height 19 mm (0.75 in)
Width 300 mm (11.81 in)
Depth 201 mm (7.91 in)
Weight 1.41 kg (3.11 lb)
NOTE: The weight of your laptop varies depending on the configuration ordered
and the manufacturing variability.
w
Specifications
Views
System
information Memory Ports and
connectors
Dimensions and
weight
Computer
environment
Storage
Touch pad Power adapterCamera
Communications
Battery
Video Audio
Display
Media-card
reader Keyboard
System information
Computer model Inspiron 11-3152
Processor Intel Pentium Quad Core
Chipset Integrated in processor
