DeDietrich DOP8785X User manual

OVEN

EN USER GUIDE

DEAR CUSTOMER,

CUSTOMER,

Discovering a De Dietrich product means experiencing the range of unique

emotions. The attraction is immediate, from the moment you set eyes on

the product. The sheer quality of the design shines through,

thanks to the timeless style and outstanding nishes which make each

component an elegant and rened masterpiece in its own right,

each one in perfect harmony with the others.

Next, comes the irresistible urge to touch it.

De Dietrich design makes extensive use of robust and prestigious

materials, where the accent is placed rmly upon authenticity.

By combining state-of-the-art technology with top quality materials,

De Dietrich produces beautifully crafted products to help you get the most

from the culinary arts, a passion shared by all lovers of cooking and ne

food. We hope that you enjoy using this new appliance.

Thank you for choosing a De Dietrich product.

BVCert.6011825

The label "Origine France Garantie" assures the consumer the

traceability of a product by giving a clear and objective indication

of the source. The DE DIETRICH brand is proud to afx this

label on products from our French factories based in Orléans

and Vendôme.

www.dedietrich-electromenager.com

CONTENTS

1 / Description of the oven.................................................................4

The controls and display.......................................................................5

The accessories ...................................................................................6

Initial settings - using the oven for the rst time ...................................8

2 / The cooking modes.......................................................................9

«Expert» mode .....................................................................................9

ºCooking functions..........................................................................10

ºDrying............................................................................................13

º Favourites (saved cooking)...........................................................14

«Recipes» mode.................................................................................14

«Chef» mode......................................................................................16

«Low temperature» mode...................................................................19

«Pastry» mode ...................................................................................24

3 / Settings ........................................................................................25

Time ..............................................................................................25

Language ......................................................................................25

Sound............................................................................................25

Demo mode ..................................................................................25

Lamp management .......................................................................25

Locking the controls............................................................................26

4 / Minute Minder ..............................................................................26

5 / Cleaning and Maintenance .........................................................27

External surface..................................................................................27

Removing the shelf runners................................................................27

Cleaning the inner glass.....................................................................27

Disassembly and reassembly of the «Sensor» plate..........................28

Cleaning function (pyrolysis) ..............................................................29

Replacing the light bulb ......................................................................30

6 / Anomalies and solutions............................................................31

7 / After-Sales Service......................................................................32

•1DESCRIPTION OF THE OVEN

DESCRIPTION OF THE OVEN

Control panel

Lamp

Shelf runners (6 heights available)

Oven off touch control

(press and hold)

Go back touch control

(active in programming

search, not cooking)

MENU access touch control

(cooking, settings, minute

minder, cleaning)

Displays

Rotating knob with central button

(cannot be removed):

- Choose programmes, increase or

reduce values by turning it.

- Validate each action by pressing

the centre.

•1DESCRIPTION OF THE OVEN

THE CONTROLS AND DISPLAY

Start a cooking programme

Stop a cooking programme

Temperature degrees

Cooking time

Cooking end time

(delayed start function)

Saved cooking

programmes

Keypad locked indicator

Door locked

indicator during pyrolysis

DISPLAY SYMBOLS

Recommended shelf height indicator for placing dishes

•1DESCRIPTION OF THE OVEN

ACCESSORIES (depending on model)

- Anti-tip safety rack

The rack can be used to support all

dishes and moulds containing food for

cooking or browning. It can be used for

grilling (placed directly on top).

Position the anti-tip stop towards the back

of the oven.

Multi-purpose tray, drip tray45 mm

When inserted in the shelf runners under

the grill with the handle towards the oven

door, it collects juice and fat from grilling,

and can be used half-lled with water as

a double-boiler.

- 20 mm pastry dish

Insert in the shelf runners with the handle

towards the oven door. Ideal for baking

cookies, shortbread and cupcakes. The

tilted surface makes it easier for you to

put your preparations in a dish. Can also

be inserted into the shelf runners under

the grill to collect juice and fat from grilling.

- «Flavour» grills

These half «flavour» grills are used

separately, but only when placed in one

of the dishes or drip tray with the anti-tip

handle towards the back of the oven.

By using just one grill, it is easy to

moisten your food with the cooking juices

collected in the dish.

•1DESCRIPTION OF THE OVEN

- Sliding rail system

The new sliding rail system makes food

more practical and easier to handle as the

trays can be effortlessly pulled for simpler

handling. The trays can be completely

removed, providing full access.

Their stability ensures that food can be

handled safely, reducing the risk of burns.

This means that you can take food out of

the oven far more easily.

INSTALLING AND REMOVING THE

SLIDING RAILS

After removing the 2 shelf runners,

choose the height (2 to 5) at which you

want to t your rails. Snap the left rail

against the left shelf runner by applying

enough pressure to the front and back

of the rail so that the 2 tabs on the side

of the rail slot into the shelf runner. Do

the same for the right-hand rail.

NOTE: the telescopic sliding part of the

rail must unfold towards the front of the

oven, with the buffer Aopposite you.

Insert your 2 shelf runners and then put

your tray on the 2 rails. The system is

now ready to use.

To remove the rails, remove the shelf

runners again.

Slightly prise apart the bottom of the

tabs xed on each rail to release the

shelf runner. Pull the rail towards you.

Tip

To avoid fumes when cooking fatty

meats, we recommend you add a small

amount of water or oil to the bottom of

the drip pan.

The accessories may warp with

the effect of heat, but this will not alter

their function. They will return to their

original shape once cooled.

INITIAL SETTINGS -

USING THE OVEN FOR THE FIRST

TIME

- Starting - General menu

Press the MENU key key to access

the general menu when the oven only

displays the time.

You will access the rst cooking mode:

Expert mode.

Turn the knob to scroll through the

different programmes :

Before using your oven for the

first time, heat it at maximum

temperature while empty for

approximately 30 minutes. Make sure

that the room is sufciently ventilated.

•1DESCRIPTION OF THE OVEN

- Select the language

The rst time you use your oven or after

a power cut, turn the knob to select your

language and press to conrm your

choice.

- Set the time

The displays ashes 12:00.

Adjust the hours and minutes by turning

the knob, then press to conrm.

Your oven displays the time.

Note: To modify the time again, refer to

the «Settings» chapter.

To enter the selected mode, validate

by pressing the knob.

To go back (except during cooking),

press the back key and to stop the

oven, press the stop key for a few

seconds.

Minute Minder

Settings

Expert

Recipes

Low

temperature

Pastry

Cleaning

Chef

Select one of the following modes

according to your experience in cooking

your recipe:

Select “EXPERT” mode for

a recipe for which you will

select the type of cooking, the

temperature and the cooking

time yourself.

Select «RECIPES» mode for

a recipe for which you need

assistance from the oven.

Simply select the type of food

proposed and its weight and the oven

will select the most suitable parameters.

Select “CHEF” mode for a

recipe managed automatically

by the oven. Select the dish

you want to cook from a list of

the most common dishes.

Select “LOW

TEMPERATURE” mode for

a recipe managed completely

by the oven using a specic

electronic programme (slow cooking).

Select “PASTRY” mode

to produce perfect French

culinary specialities with

assistance from the oven.

THE COOKING MODES

•2COOKING

This mode lets you set the cooking

parameters yourself: temperature,

cooking type, cooking time.

When the oven is only displaying the

time, press the MENU key to access

the general menu then conrm «Expert»

mode.

- Turn the control knob until you get to

the cooking function of your choose,

then conrm:

Fan cooking

Combined heat

Traditional

Eco cooking

Grill ventilated

Bottom heat ventilated

Variable grill

Keep warm

Defrost

Bread

Drying

Shabbat (special function,

depending on model)

***********************************

Favourites (enables 3

cooking programmes to be saved)

«EXPERT» MODE

•2COOKING

COOKING FUNCTIONS (depending on model)

Grill

ventilated

Roasts and poultry are juicy and crisp all

over.

Slide the drip tray on to the bottom shelf

support.

Recommended for all spit-roasted poultry

or meat, for sealing and thoroughly

cooking a leg or a rib of beef. To retain

the moist texture of sh steaks.

200°C

100°C - 250°C

ECO*

This setting saves energy while

maintaining the quality of the cooking. In

this setting, pre-heating is not required.

200°C

35°C - 275°C

Traditional Recommended for meat, sh, vegetables,

preferably in an earthenware dish.

200°C

35°C - 275°C

Fan

cooking*

Recommended for keeping white meat,

sh and vegetables moist. For cooking

multiple items on up to three levels.

180°C

35°C - 250°C

Combined

heat

Recommended for meat, sh, vegetables,

preferably in an earthenware dish.

205°C

35°C - 230°C

Position Use

T°C recommended

mini - maxi

Pre-heat your oven empty before cooking.

Ventilated

oor

Recommended for meat, sh, vegetables,

preferably in an earthenware dish.

180°C

75°C - 250°C

*Cooking mode as per standard EN 60350-1: 2016 to demonstrate compliance with requirements

of the energy label of European regulation UE/65/2014.

Never place tin foil directly in contact with the oven floor as the build

up of heat may damage the enamel.

This manual suits for next models

Table of contents

Other DeDietrich Oven manuals

DeDietrich

DeDietrich DOP 750 User manual

DeDietrich

DeDietrich DOP350 Series User manual

DeDietrich

DeDietrich DOP8574X User manual

DeDietrich

DeDietrich DOP1199X User manual

DeDietrich

DeDietrich DOP7785X User manual

DeDietrich

DeDietrich DME388 Series User manual

DeDietrich

DeDietrich DOD1278B Instruction Manual

DeDietrich

DeDietrich Oven User manual

DeDietrich

DeDietrich doc710 series User manual

DeDietrich

DeDietrich DOE3910 Instruction Manual

DeDietrich

DeDietrich DOE5910 User manual

DeDietrich

DeDietrich DOV399 Series User manual

DeDietrich

DeDietrich Oven User manual

DeDietrich

DeDietrich Oven User manual

DeDietrich

DeDietrich DOP1190 User manual

DeDietrich

DeDietrich DOP499 Series User manual

DeDietrich

DeDietrich DME1188X User manual

DeDietrich

DeDietrich DKR7580X User manual

DeDietrich

DeDietrich DME 1135B User manual

DeDietrich

DeDietrich 99643991 Four Oven User manual

DeDietrich

DeDietrich DOP740X User manual

DeDietrich

DeDietrich DOP450 Series User manual

DeDietrich

DeDietrich UMP 40 User manual

DeDietrich

DeDietrich DOP760XS User manual

Popular Oven manuals by other brands

Bosch

Bosch HVA531NS0 instruction manual

Electrolux

Electrolux EOF6P46X user manual

NEFF

NEFF B44S32 5GB Series instruction manual

Combi

Combi BLODGETT BC142GDS Specifications

AEG

AEG COMPETENCE 311704300 Installation and operating instructions

Falcon

Falcon DOMINATOR PLUS G3106 Series Servicing instructions

Rational

Rational SCC WE 61G installation manual

Smeg

Smeg DOSPA38X User manuals

Electrolux

Electrolux air-o-convect 20 GN 2/1 user manual

Miele

Miele HR 1954-2 operating instructions

KHIND

KHIND OT50 instruction manual

Henny Penny

Henny Penny Smoker Box installation manual

Lang

Lang ECOD-AP Installation and operation instructions

AEG

AEG BEK455310M user manual

Frigidaire

Frigidaire FNGE90JGR user manual

Hotpoint

Hotpoint FE9 S831 JSH IX user manual

GE Advantium SCB2000 owner's manual

AEG

AEG DE401301DM user manual
