Danby DFF116B1WDBL User manual
*
*
Danby Products Limited, Guelph, Ontario, Canada N1H 6Z9
Danby Products Inc. Findlay, Ohio, U.S.A. 45840
www.Danby.com
Printed in China
Imprimé en Chine
Impreso en China
*Trademark of Danby Products
* Marque de commerce de Danby Products
* Marca comerciales de Danby Products
REFRIGERATOR
Owner’s Manual.............................1 - 12
RÉFRIGÉRATEUR
Manuel du propriétaire.................13 - 24
REFRIGERADOR
Manual del propietario.................25 - 36
MODEL * MODÈLE * MODELO
DFF116B1WDBL
DFF116B1WDBR
DFF116B2WDBL
DFF116B2WDBR
DFF116B2SSDBL
DFF116B2SSDBR
2022.11.24
Welcome to the Danby family.
We are proud of our quality products and we believe in dependable
service. We suggest that you read this owner’s manual before plugging
in your new appliance as it contains important operation information,
safety information, troubleshooting, and maintenance tips to ensure the
reliability and longevity of your appliance.
You are entitled to the warranty coverage as described in the owner’s
manual provided with your new appliance.
1. Please write down your appliance information below. You must
keep the original proof of purchase receipt to validate and receive
warranty services.
2. Register your product online and receive a FREE 2 MONTH
WARRANTY EXTENSION after filling out a product survey, at www.
danby.com/support/product-registration/
Need Help?
1. Read your Owner’s Manual for installation help, troubleshooting, and
maintenance assistance.
2. Visit www.Danby.com to access self-service tools, FAQs and much
more by searching your model number in the search bar.
3. For the Quickest Customer Service, please fill out the web form at
www.danby.com/support. Your submission will go directly to an
expert on your particular appliance. Our average response times are
between 20 minutes and 2 hours, during EST business hours.
4. Call 1-800-263-2629 - please note that during peak hours, hold
times can exceed one hour.
Model Number: _____________________________________________
Serial Number: _____________________________________________
Date of Purchase: ___________________________________________
1
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
DANGER: Risk of fire or explosion. Flammable refrigerant used. Do not
puncture refrigerant tubing.
• Ensure that servicing is done by factory authorized service personnel,
to minimize product damage or safety issues.
• Consult repair manual or owner’s guide before attempting to service
this product. All safety precautions must be followed.
• Dispose of properly in accordance with federal or local regulations.
• Follow handling instructions carefully.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
WARNING:
• Keep ventilation openings, in the appliance enclosure or in the built-
in structure, clear of obstruction.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type
recommended by the manufacturer.
CAUTION: Children should be supervised to ensure that they do not play
with the appliance.
DANGER: Risk of child entrapment. Before throwing away an old
appliance:
• Remove the door or lid.
• Leave shelves in place so that children may not easily climb inside.
This appliance is not intended for use by persons (including children)
whose physical, sensory or mental capabilities may be different or
reduced, or who lack experience or knowledge, unless such persons
receive supervision or training to operate the appliance by a person
responsible for their safety.
Important Safety Information
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
This appliance is intended to be used in household and similar
applications such as:
• Staff kitchen areas in shops, offices and other working environments;
• Farm houses and by clients in hotels, motels and other residential
type environments;
• Bed and breakfast type environments;
• Catering and similar non-retail applications.
GROUNDING INSTRUCTIONS
This appliance must be grounded. Grounding reduces the risk of
electrical shock by providing an escape wire for the electrical current.
This appliance has a cord that has a grounding wire with a 3-prong
plug. The power cord must be plugged into an outlet that is properly
grounded. If the outlet is a 2-prong wall outlet, it must be replaced with a
properly grounded 3-prong wall outlet. The serial rating plate indicates
the voltage and frequency the appliance is designed for.
WARNING - Improper use of the grounding plug can result in a risk
of electric shock. Consult a qualified electrician or service agent if the
grounding instructions are not completely understood, or if doubt exists
as to whether the appliance is properly grounded.
Do not connect your appliance to extension cords or together with
another appliance in the same wall outlet. Do not splice the power
cord. Do not under any circumstances cut or remove the third ground
prong from the power cord. Do not use extension cords or ungrounded
(two prongs) adapters.
If the power supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similar qualified person in order to
avoid hazard.
4
LOCATION
• Two people should work together to move the refrigerator. Place it on
a floor that is strong enough to support it when it is fully loaded that
is not in direct sunlight or close to sources of heat. Do not use near
water, such as in a wet basement or near a sink.
• Remove interior and exterior packaging. Wipe the outside with a
soft, dry cloth and the inside with a lukewarm wet cloth.
• Before connecting the refrigerator to a power source, let it stand
upright for approximately 6 hours. This will reduce the possibility
of a malfunction in the cooling system from handling during
transportation.
• This refrigerator is 59.5 cm (23.4 inches) wide by 151.2 cm (59.5
inches) high by 73.3 cm (28.9 inches) deep.
• Allow 5 cm (2 inches) of space between the back, sides and top of
the refrigerator and all adjacent walls.
• This refrigerator is intended for free-standing installation only and
is not intended to be built into a cabinet or counter. Building in this
refrigerator can cause it to malfunction.
IMPORTANT
This refrigerator is intended for household use
only. It is not designed for outside installation,
including anywhere that is not temperature
controlled, e.g., garages, porches, vehicles, etc.
OPERATING INSTRUCTIONS
5
OPERATING INSTRUCTIONS
FEATURES
1. Magnetic Gasket: Tight fitting
door seal keeps all the cooling
power locked inside.
2. Freezer Compartment
3. Freezer Shelf
4. Freezer Temperature Control
5. Refrigerator Compartment
6. Refrigerator Temperature
Control
7. Refrigerator Shelves
8. CANSTOR™ Door Liner: Holds
355 ml cans of pop, juice, or
beer.
9. Crisper
10.Leveling Legs: Adjust so the unit
is level.
1
2
3
4
56
7
8
9
10
IMPORTANT
Ensure that the door is fully
closed when the appliance is in
operation. Failure to fully close
the door can lead to excessive
condensation and potential water
damage to flooring under the
appliance. Danby will not be
responsible for damages from
misuse.
OPERATING INSTRUCTIONS
6
REFRIGERATOR TEMPERATURE SELECTION
The refrigerator control panel is located on the inner ceiling of the
refrigerator compartment.
Press the arrow button to set the temperature of the appliance. The single
snowflake is the warmest setting and the three snowflakes indicate the
coldest setting. The indicator light will illuminate to show which level is
currently selected.
Press and hold the arrow button for 3 seconds to turn off the compressor.
While the compressor is off, the power light will illuminate and the
cooling function will not operate. This allows the door of the refrigerator
to be left open while adding large amounts of food without using energy.
To resume the cooling function, press the arrow button once and the
refrigerator will return to normal functioning.
Internal temperature of the refrigerator can vary based on ambient
temperature, the quantity of items stored and how frequently the door is
opened.
7
OPERATING INSTRUCTIONS
FREEZER TEMPERATURE SELECTION
The freezer control is located on the back wall of the freezer
compartment. The single snowflake is the warmest setting and the three
snowflakes indicate the coldest setting. Turn the dial to set the freezer to
the desired temperature.
HUMIDITY CONTROL
There is a humidity control gauge on the crisper that can be used to
control the level of humidity inside the crisper. The single water drop
indicates less humid conditions. The three water drops indicate more
humid conditions.
LEVELING INSTRUCTIONS
There is an adjustable leg on the bottom of the refrigerator that can be
turned up or down to ensure that the appliance is level.
1. Turn the leveling leg counter-clockwise as far as it will go, until the
top of the foot is touching the bottom of the cabinet.
2. Slowly turn the leveling leg clockwise until the refrigerator is level.
8
OPERATING INSTRUCTIONS
DOOR REVERSAL INSTRUCTIONS
If the refrigerator is placed on its back or side during this process it must
be allowed to stand upright for 6 hours before plugging in to avoid
damage to internal components.
1. Remove the screw hole cover from the top left side of the cabinet.
Remove the upper hinge cover and the upper hinge from the top right
side of the cabinet. Remove the freezer door from the cabinet.
2. Remove the hinge pin from the upper hinge. Flip the upper hinge
over. Reinstall the hinge pin on the opposite side of the hinge.
3. Remove the center hinge from the cabinet. Remove the refrigerator
door from the cabinet.
4. Move the hinge hole sleeve from the top right side of the refrigerator
door to the top left side of the refrigerator door. Move the hinge hole
cover from the top left side of the refrigerator door to the top right
side of the refrigerator door.
5. Move the screw hole covers from the center left side of the cabinet to
the center right side of the cabinet.
6. Remove both adjustable feel from the bottom of the cabinet.
7. Remove the lower hinge from the bottom right side of the cabinet.
8. Move the screw hole covers from the bottom left side of the cabinet to
the bottom right side of the cabinet.
9. Remove the hinge pin from the lower hinge. Flip the lower hinge over
and install the hinge pin on the other side. Install the lower hinge on
the lower left side of the cabinet.
10.Install both of the adjustable feet on the bottom of the cabinet.
11.Install the refrigerator door on the cabinet. Flip the center hinge and
install it on the center left side of the cabinet.
12.Install the freezer door on the cabinet. Install the upper hinge and the
upper hinge cover on the top left side of the cabinet. Install the screw
hole cover on the top right side of the cabinet.
9
1
2
3
4
5
7
6
8
9
10
11
12
OPERATING INSTRUCTIONS
Other manuals for DFF116B1WDBL
2
This manual suits for next models
5
Table of contents
Languages:
Other Danby Refrigerator manuals
Danby
Danby Contemporary Classic DAR033A6WDB User manual
Danby
Danby DPF073C3WDB User manual
Danby
Danby Designer DAR1102W User manual
Danby
Danby DAR044A1WDD Assembly instructions
Danby
Danby DAR044KA1MDB User manual
Danby
Danby DCR045B1BSLDB User manual
Danby
Danby DCR016C1WDB User manual
Danby
Danby DPF073C1BSLDD User manual
Danby
Danby DCRM31WDD Use and Assembly instructions
Danby
Danby DAR044A4WDD Assembly instructions
Danby
Danby Silhouette DFF1044BLS User manual
Danby
Danby DCR88BLDD User manual
Danby
Danby DAR044A4WDD-3 User manual
Danby
Danby DBMR02624WD43 User manual
Danby
Danby DCR031B1WDD User manual
Danby
Danby DAG016A1BDB User manual
Danby
Danby DFF143V1SSDB User manual
Danby
Danby DFF101E1WDB User manual
Danby
Danby DAR044A1SSO-6 User manual
Danby
Danby DCR032A2WBUD1 Assembly instructions
