dallmeier DDZ5200HD Series User manual
008316 | REV. 1.0.0 | 2021-04-13
COMMISSIONING
DDZ5200HD Outdoor Series
Copyright © 2021 Dallmeier electronic GmbH & Co.KG
The reproduction, distribution and utilization of this document as well as the
communication of its contents to others without express authorization is prohibited.
Oenders will be held liable for the payment of damages.
All rights reserved in the event of the grant of a patent, utility model or design.
The manufacturer accepts no liability for damage to property or pecuniary damages
arising due to minor defects of the product or documentation, e.g. print or spelling errors,
and for those not caused by intention or gross negligence of the manufacturer.
Figures in this document may dier from the actual product.
Specications subject to change without notice. Errors and misprints excepted.
All trademarks identied by ® are registered trademarks of Dallmeier.
All trademarks identied by * are trademarks or registered trademarks of the following owners:
Google and Google Chrome of Google Inc. headquartered in Mountain View, California, USA;
JavaScript of Oracle Corporation (and/or its aliates) headquartered in Redwood Shores, California, USA;
Microsoft, Internet Explorer, Microsoft Edge and Windows of Microsoft Corporation headquartered in Redmond,
Washington, USA;
Mozilla and Firefox of Mozilla Foundation headquartered in Mountain View, California, USA.
Third-party trademarks are named for information purposes only.
Dallmeier respects the intellectual property of third parties and always attempts to ensure the complete identication of
third-party trademarks and indication of the respective holder of rights.
In case that protected rights are not indicated separately, this circumstance is no reason to assume that the respective
trademark is unprotected.
This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (https://www.openssl.org)
3
COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier
5
COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier
Contents
1 Validity 6
2 Documents 6
This Document 7
Other Applicable Documents 7
3 Typographical Conventions 8
4 Approvals/Certications 10
5 Safety Instructions 11
6 General Notes 14
Warranty 14
Scope of Delivery 14
Transportation and Packaging 15
Appropriate Use 15
Operation 16
Formation of Condensation 18
7 Requirements 20
Operating Mode and Ambient Conditions 20
Earthing/Grounding 21
Power Supply 22
8 Maintenance, Inspection and Cleaning 24
9 Mounting, Connection and Commissioning 26
10 Connections and Pin Assignment 66
Alarm/Audio 67
Power In 68
11 Conguration 70
System Requirements 70
Establishing the Connection 71
First-Time Access 72
Login 73
12 Technical Product Specication (Basic Data) 74
13 Dimensions 76
6COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier
1 Validity
This document applies to the following devices:
• DDZ5220HD Outdoor
• DDZ5232HD Outdoor
For reasons of simplication, the term “device” or “camera” is used in the
following.
Figures in this document may dier from the actual product.
2 Documents
The product documentation for the device consists of various documents
which are provided in printed and/or digital form, as for example via the
website www.dallmeier.com.
Read the complete product documentation for the device carefully and
thoroughly before using the device. Always observe and follow the con-
tained instructions, notes and warnings as well as the technical data in the
currently valid product specication.
Keep all printed documents relating to your device in a legible condition and
in a suitable location for future reference.
Save digital documents relating to your device (e.g. the technical product
specication) on a suitable data storage device.
Regularly check the website www.dallmeier.com for the latest product
documentation updates.
7
COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier
This Document
Commissioning
The document entitled “Commissioning” (this document) contains detailed
information concerning the installation, connection and commissioning of
the device as well as safety instructions and general notes.
The target audience of this document is trained system integrators (installa-
tion contractors of video security/surveillance systems).
Other Applicable Documents
Product Specication
The product specication contains detailed technical data, features and
characteristics of the device.
The target audience of the document is trained system integrators (installa-
tion contractors of video security/surveillance systems).
Conguration
The document entitled “Conguration” contains detailed information con-
cerning the conguration of the device.
The target audience of the document is trained system integrators (installa-
tion contractors of video security/surveillance systems).
8COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier
3 Typographical Conventions
This document may contain various warning words and symbols that indi-
cate potential sources of danger:
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE
NOTICE addresses practices not related to physical injury and indicates
measures to prevent device and/or property damage due to improper
installation, assembly, wiring, operation, conguration or maintenance of
the device.
9
COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier
For reasons of clarity and readability, various text formatting elements and
types of emphasis are used in this documentation:
Instructions are indicated by arrows (➡).
➡Always carry out instructions one after the other in the sequence de-
scribed.
“Expressions” in quotation marks usually refer to individual components of
the device (housing parts, mounting elements, connections/interfaces, etc.)
or to control elements of the device’s web-based graphical user interface
(menu items, buttons, etc.).
Paragraphs in italics provide information on basic principles, special
features and ecient procedure as well as general recommendations.
10 COMMISSIONING – DDZ5200HD Outdoor Series | REV. 1.0.0 | © 2021 Dallmeier
4 Approvals/Certications
The following approvals/certications were valid for the device at the time
of this document’s compilation:
• CE (tested according to DIN EN 50130-4:2011, EN 55032:2015)
• FCC
• RCM
Visit www.dallmeier.com for possible updates.
Information for Users in the United States of America (USA)
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energ
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interfer-
ence at his own expense.
