Dakota Alert BBT-2500 User manual

www.bealert.co.nz www.bealert.com.au

NEW ZEALAND AUSTRALIA

BBT-2500

Break Beam Transmitter

User Guide

PRODUCT DESCRIPTION:

The BBT-2500 is used with the DCR-2500 receiver. The BBT-2500 uses Active Infrared to detect anything that

passes through the sensor pair and breaks both beams at the same time. When the beams are broken, the

unit sends a signal to the receiver. This will sound one of four different tones (Classical, Westminster Chime,

Ding Dong, or Whistle). The BBT-2500 can be used to monitor access into any area, from your backyard to

lumber yard and everything in between.

READ MANUAL THOROUGHLY BEFORE INSTALLATION. RETAIN MANUAL FOR

FUTURE REFERENCE. FAILURE TO FOLLOW DIRECTIONS PROPERLY MAY RESULT

IN DAMAGE.

ONLY use this product for the detection of moving objects such as people and vehicles.

DO NOT disassemble or attempt to repair the product.

DO NOT install this unit with any other infrared detector. It may cause false alarms.

DO clean and inspect the unit regularly for proper use. If any problem is found, contact Dakota Alert, Inc.

WARNINGS:

This device complies with Part 15 of the FCC rules, Operation of this device is subject to the following

conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference,

including interference that may cause undesired operation.

HARDWARE INSTALLATION:

Verify that all installation hardware Is included. Tools needed: Phillips screwdriver, adjustable wrench.

(4) Right Angle Brackets (4) Cross Brackets (4) ‘U’ Shaped Brackets

(8) M4 nuts (8) M5x27mm screws

(8) M5x18mm screws

(16) M5 nuts

(8) M4x12mm screws

PAIRING:

To make installation easier it is recommended to pair units ‘A’ and ‘B’ before mounting.

On a ﬂat surface push the power button (Figure 1-1) on ‘A’ then push the power button on ‘B’. Laying the

units ﬂat on counter or table, line up the infrared light holes (Figure 1-2). The units will then pair.

You will see lights ﬂashing during this process. Leave the units in place for one minute to make sure this

process is complete. Once paired, test them by completely blocking all 3 holes (2 infrared light holes and

indicator hole shown in Figure 1-3). Unit should send a signal to the DCR-2500 and sound an alert. Unit

will only alert if all 3 holes are completely blocked for at least 100ms. If an object passes through the beam

faster than that it will not be detected. ‘A’ unit contains the radio transmitter module.

The ‘A’ unit transmitter module is factory set to match the zone 2 setting of the DCR-2500. It is not

recommended to change the code setting unless it is needed to avoid interference or a different zone is

desired. Be careful when opening this unit to avoid damaging any internal components or wires.

‘B’ unit contains no user serviceable parts. It is not recommended to open this unit.

CIRCULAR POST MOUNTING:

1. Take the right angle bracket (Figure 3-1) and attach the

cross bracket using (2) M4 nuts and (2) M4x12mm

screws. Repeat for all brackets.

2. Using (2) M5 nuts and (2) M5x18mm screws attach right

angle bracket (Figure 3-2) to units ‘A’ and ‘B’.

3. Attach to post with ‘U’ shaped bracket (Figure 3-3).

Using (2) M5 nuts and (2) M5x27mm screws attach ‘U’

bracket around post. Tighten securely.

FLAT SURFACE MOUNTING:

1). Using (2) M5 nuts and (2) M5x18mm screws attach right angle

bracket (Figure 4) to units ‘A’ and ‘B’.

2). Use screws that are appropriate for your material and surface

(not included) and mount right angle bracket taking care to keep

units ‘A’ and ‘B’ level.

MOUNTING OUTSIDE:

Units ‘A’ and ‘B’ can be mounted up to 100 metres apart.

Determine height and location you would like to mount the unit.

Recommended height is 1 metre’. There must be line of sight

between ‘A’ and ‘B’. Units must be mounted level. Install the unit

on a stable surface. Do not install where trees or other objects can

block the beam. Mounting 1 metre will avoid false alerts by small animals

crossing under the beam, but still detect people and vehicles.

Mount unit ‘B’ ﬁrst and face the infrared holes toward where unit ‘A’ will be mounted. When mounting unit

‘A’, face the infrared holes towards unit ‘B’. When the units align the ‘A’ unit indicator light will begin to blink.

To make sure of proper alignment cover only the top two infrared holes. Unit should not alert. Then cover

only the bottom two holes, again unit should not alert. Cover all three holes and the unit should alert. If the

unit alerts with only the top two infrared holes covered, raise the unit about 25mm to correct misalignment.

If the unit alerts with only the bottom two infrared holes covered, lower the unit about 25mm. When properly

aligned, the unit will only alert when all three infrared holes are covered.

Detailed below are the two most common mounting options.

FOR ALL MOUNTING SITUATIONS:

For all mounting situations In all mounting situations it is very important that the ‘A’ unit only interact with one

‘B’ unit or the pair may not alert properly. Use the diagrams below for reference.

100 metres 100 metres 100 metres

STRAIGHT LINE MOUNTING 300 metres

PERIMETER MOUNTING

ONLY OPEN UNIT ‘A’ IF CHANGING THE ZONE/CHIME IS ABSOLUTELY NECESSARY.

It is not recommended to change any settings as the BBA-2500 is factory set to match.

DO NOT OPEN UNIT ‘B’.

Remove the 8 screws on the back

of unit ‘A’ (Figure 5-1). Gently

lift the solar panel to expose the

transmitter board (Figure 5-2).

Locate the 10 dip switches on

the red block. The ﬁrst eight dip

switches are for the frequency

setting (256 combinations). Set

switches 1-8 to match the eight

switches in the receiver. Switches

9 and 10 are for the zone/channel

settings on the transmitter.

The four zones are listed in the table below.

CODING THE DCR-2500 RECEIVER:

Open the receiver case by inserting a small

screwdriver into one of the pry notches on the side

of the case (refer to receiver manual). Gently lift off

the front cover. Locate the eight dip switches on the

DCR-2500 and make sure they are set identically to

dip switches 1-8 on the BBT-2500.

Note: If more than one transmitter is used with the

receiver, the ﬁrst eight dip switches of all transmitters

must match the eight dip switches of the receiver.

Note: Whenever a change is made to the time jumper or the dip switches, the receiver must be

turned OFF and then back ON to operate properly.

Switch 9 Switch 10 Channel Tune

On On 1 Classical

Off On 2 Westminster

On Off 3 Ding Dong

Off Off 4 Whistle

TROUBLESHOOTING:

If sensor pair alerts when originally paired, but will not alert when mounted...

1. Push power button on unit ‘A’

2. Look in center hole for the indicator light. If light is on, proceed to step 3. If light is not on, press power

button again. Indicator light should come on.

3. Repeat steps 1 and 2 for unit ‘B’. This will re-sync the units.

If experiencing false alerts...

• Check for obstruction (i.e. branch, frost)

• Extreme fog

• Extreme snow and rain

• If obstruction/weather are not involved, try changing the frequency of the DCR-2500 and unit ‘A’

• If unit is blocked continually a second signal will be generated after one hour

If no signal...

• Turn power off on all units for 60 seconds and then turn power back on

• Make sure units are still aligned

• Make sure all 8 dip switches in DCR-2500 match the ﬁrst 8 dip switches inside unit ‘A’

TECHNICAL SUPPORT:

If you encounter any difﬁculty in the operation of this product after reading the manual, please contact us.

We will be happy to answer your questions and help you in any way we can.

WARRANTY:

Dakota Alert warrants this product to be free of defects in material and workmanship for a period of one

year from the date of purchase. This warranty does not cover damage resulting from accident, abuse, act of

God or improper operation. If this product does become defective, simply return it to Target Technology Ltd.

Please include a note describing the troubles along with your name and return address as well as the original

sales receipt. If the product is covered under warranty it will be repaired or replaced at no charge. If it is not

covered by warranty, you will be notiﬁed of any charges before work is done.

Freephone New Zealand: 0508 242 333

Phone (64) 6 751 2969

Fax (64) 6 751 2717

PO Box 730, New Plymouth 4342

NEW ZEALAND

Freephone Australia: 1300 588 195

Fax (64) 6 751 2717

PO Box 7338, Toowoomba South 4350

Queensland

AUSTRALIA
