Daewoo FRN-T30H3GP User manual
FRN-T30H3GP
( FRT-803ZG..)
FRN-T30H3TB
( FRT-803HB..)
FRN-T30H3PW
( FRT-813HP..)
FRN-T30H2MW
( FRT-822HW..)
May. 2013.
Specification
1. Information
374.2
530.0
780.2
330.7
449.5
FRN-T30H3PW
( Preuve White )
FRT-813HP..
904.2
374.2
530.0
817.9
FRN-T30H3TB
( Stella Black )
FRT-803HB..
904.2
FRT-803ZG..
904.2
330.7
487.2
Factory No.
Refrigerator
907.5
374.2
533.3
Buyer No.
Gross Vol.
(IEC 62552)
Total
447.9
330.7
FRN-T30H3GP
( Glitzen Pearl )
Total
Freezer
822.7
330.5
Refrigerator
Freezer
492.2
FRN-T30H2MW
( Mone White )
Storage Vol.
(IEC 62552)
FRT-822HW..
778.6
530.0
374.2
150W
893
1790
141 kg
893
954
149 kg
DREP 9020 LR
893
954
Compulsory Convection Type
954
R-600a
70g
Fin Type
149 kg 140 kg
210W
954
Diemension
DC 12V
AC 250V, 10A, 77C
DREP 9020 LR
DRCP 9020 LC
DC 12V
Electronic Part
Refrigerator Lamp LED
Condenser Fan Motor
Freezer Lamp LED
Refrigerator Fan Motor
Cooling Cycle
Evaporator Type
Refrigerant Type
Refrigerant Charge
Heater Ref) Defrost Heater
Condenser Type
Fuse Temp. (Defrost)
Freezer Fan Motor
Molecular Sieve xH-9
ID0.7 x T0.55 x L2,200
Dryer
Capillary Tube
Frz) Defrost Heater
H/Bar Heater 10W
1790
Width (mm)
Depth (mm)
1790
Weight (kg)
1790Height (mm)
893
1
Specification
2. Outside Diemension
2
Specification
3. Interior Parts
1) T30H3GP / T30H3TB
1. Door storage compartment 7. Egg case
2. Ice maker / Ice storage bin 8. Door storage compartment
3. Freezer shelf 9. Can pocket
4. Freezer compartment drawer 10. Multi crisper
5. Takeout case 11. Vegetable / fruit drawer
6. Refrigerator shelf 12. EZ Home bar
3
Specification
2) T30H3PW / T30H2MW
1. Door storage compartment 6. Egg case
2. Ice maker / Ice storage bin 7. Door storage compartment
3. Freezer shelf 8. Can pocket
4. Freezer compartment drawer 9. EZ Home bar
5. Refrigerator shelf 10. Vegetable / fruit drawer
* The real features are model dependent.
4
Refrigerant Cycle
5
Air Flow [ Side View ]
[ Freezer Compartmnet ]
[ Refrigerator Compartmnet ]
* The illustration is 'FRN-T30H3GP / FRN-T30H3TB' model.
6
1. Display
a Multi Crisper ( Option ) button
; To select Fish - Meat - Vegetable - Speed mode.
( Speed mode works for 60 minutes.)
b Frz. Set button
1) Initial plug in : Medium ( -20C )
2) Every time you press the Frz. Set button, the setting temperature
changes below order.
Functions
a
b
c Ref. Set button
1) Initial plug in : Medium ( 2C )
2) Every time you press the Ref. Set button, the setting temperature
changes below order.
d Lock button ( Childproof lock )
1) After 2 minutes when no dial setting, this mode is active automatically.
Except Lock icon, all Led is Off.
2) After another 30 seconds, Lock icon is also off except Eco led.
3) Manually, you can enter this mode by touching Lock button for 1 second.
After 2 min 30 sec all led is off except Eco led.
Power Save
; After 2 min 30 sec when no dial setting or no door opening, all led is off except Eco led.
T30H3PW/MWT30H3GP/TB
c
d
7
ECO Mode
; Eco Mode is automatically lights up when energy-saving mode is driving.
1) Green : Power saving mode
2) Blue : Normal control mode
3) Pink : Acceleration mode ( Refrigerator is driving continually to lower temperature of inside of refrigerator when
there is a big difference between inside and outside. )
2. Freezer Compartment Control
1) Adjust by the pushing the FRZ.SET button.
2) Compressor & Freezer Fan controlled by each mode ON/OFF point.
3) Freezer Compartment ON/OFF Difference : 4.5C
- MEDIUM OFF point : -20.8C
4) Control Temperature Point in Each Mode
Functions
Plug in 1st Press 2nd Press 3rd Press 4th Press 5th Press 6th Press 7th Press 8th Press
Division
5) Quick Freezer Mode
; In this mode, Compressor & Freezer Fan motor is on unconditionally for 150 minutes.
- After Quick mode, the dial is to Medium mode. ( After 150 minutes or sensor temperature is below -25.8C.
- Quick freezer mode is free of Refrigerator sensor.
- In this mode defrosting is not active. Defrosting is priority to Quick mode.
Temp.
Freezer
Fan On/Off
QUICK FREEZER Start NORMAL MODE
150 minutes
On -16.3 -17.4 -18.3 -19.3 -21.3 -12.1 -13.1 -14.1 -15.2
Off -20.8 -21.9 -22.8 -23.8 -25.8 -16.6 -17.6 -18.6 -19.7
-19-18
Sensor
Mode Medium
-23 -23 * -16 -17
Max Quick Min Min - MediumMedium - Max
Display -20 -21 -22
8
2. Refrigerator Compartment Control
1) Adjust by the pushing the REF.SET button.
2) Refrigerator Compartment ON/OFF Difference
- Dial 5C / 4C / 3C : 2.0C
- Dial 2C : 2.1C
- Dial 1C : 2.6C
- Dial 0C : 3.5C
* Medium OFF point : 3.5C
3) Quick Refrigerator Mode : This mode runs for 40 minutes.
Functions
Plug in 1st Press 2nd Press 3rd Press 4th Press 5th Press 6th Press
On 5.6 4.6 4.5 1.5 9.6 8.6 6.6
Off 3.5 2.0 1.0 -2.0 7.6 6.6 4.6
Medium
Max Max Quick
Sensor
Min - MediumMin
100*543
Division
Display 2
Mode Medium
- This mode runs for 40 min until the sensor reach -2.0 C and free of Freezer sensor.
- After this mode, the dial setting is to Medium.
- In this mode defrosting is not active. Defrosting is priority to Quick mode.
Refrigerator
Sensor
Refrigeration
OFF point
Normal
Control
NORMAL MODE
QUICK MODE (40MIN )
9
