Dacor DOP36M96GL Series User manual

User Manual

Modernist Pro Range

DOP36M96GL*

NX9900R_PRORANGE_DOP36M96GL_DG68-01105C-00_EN.indd 1 2019-02-06 2:30:19

English2

WARNING: Failure to follow the instructions in this manual exactly

may cause a fire or explosion, and, consequently, property damage,

personal injury, or death.

• DO NOT keep or use gasoline or other flammable products near

this appliance.

• IF YOU SMELL GAS:

- DO NOT light any appliances.

- DO NOT touch any electrical switches.

- DO NOT use any phone in your building.

- Immediately call your gas supplier from a neighbor’s phone,

and follow the supplier’s instructions. (If you cannot reach

your gas supplier, call the fire department.)

• Installation and service must be performed by a qualified

installer, service agency, or the gas supplier.

ANTI-TIP DEVICE

WARNING

To reduce the risk of tipping the range, the range must be secured

by a properly installed Anti-Tip device. AFTER THE RANGE HAS

BEEN INSTALLED, CONFIRM THAT THE ANTI-TIP DEVICE HAS BEEN

PROPERLY INSTALLED AND VERIFY THAT THE ANTI-TIP DEVICE

IS PROPERLY ENGAGED. Refer to the installation manual for

instructions.

a) If the anti-tip device is not installed, a child or adult can tip the

range and be killed.

b) Verify the anti-tip device has been properly installed and engaged

at the rear right (or rear left) of the range bottom.

NX9900R_PRORANGE_DOP36M96GL_DG68-01105C-00_EN.indd 2 2019-02-06 2:30:20

English 3

c) If you move the range and then move it back into place, ensure

the anti-tip device is re-engaged at the right or left rear of the

range bottom.

d) Do not operate the range without the anti-tip device in place and

engaged.

Failure to do so can result in death or serious burns to children or

adults.

WARNING

Do not step, lean, or sit on the oven door of the range. You can cause

the range to tip, resulting in burns or serious injuries.

Confirm that the Anti-Tip device is installed properly. Then, to verify

that the Anti-Tip device is engaged, grasp the top rear edge of the

range and carefully attempt to tilt it forward. The Anti-Tip device

should prevent the range from tilting forward more than a few

inches.

If you pull the range out from the wall for any reason, make sure the

anti-tip device is properly engaged when you push the range back

against the wall. If it is not, there is a risk of the range tipping over

and causing injury if you or a child stand, sit or lean on an open door.

Never completely remove the leveling legs. If you remove the

leveling legs, the range will not be secured to the anti-tip device

properly.

NX9900R_PRORANGE_DOP36M96GL_DG68-01105C-00_EN.indd 3 2019-02-06 2:30:20

Contents

English4

Contents

Before you begin 7

Important 7

Energy saving tips 7

Oven vent/cooling vent 8

Regulatory Notice 9

Important safety instructions 13

Overview 23

Layout 23

Display 24

What’s included 25

Using the cooktop 26

Burners 26

Ignition 28

Cookware 30

Grates 32

Wok grate 33

Using the oven 34

Basic settings – Clock, Date & Time, Language 34

Kitchen timer 35

Timed cooking 37

Delay start 39

Oven functions 40

Setting the mode 43

Setting the temperature 43

Basic baking and broiling instructions 44

Using the oven racks 46

Using the gliding rack 49

Using the special function feature 52

Using the healthy cook feature 55

Using the temperature probe 57

Using the clean feature 60

Using the Sabbath feature 64

Using the iQ Control feature 66

To start the oven remotely 67

Child Lock 68

Settings 69

NX9900R_PRORANGE_DOP36M96GL_DG68-01105C-00_EN.indd 4 2019-02-06 2:30:20

English 5

Contents

Care and maintenance - Cooktop 73

Cleaning the cooktop surface 73

Stainless steel surfaces 74

Control knobs 75

Burner grates and components 76

Burner caps and heads 77

Burner bases 77

Electrodes 78

Burner head and cap replacement 79

Care and maintenance - Oven 80

Care and cleaning of the oven 80

Removing the oven doors 88

Reinstalling the oven doors 90

Changing the oven light 92

Troubleshooting 93

Information codes 98

Warranty and Service 100

Warranty 100

Open-Source Announcement 103

NX9900R_PRORANGE_DOP36M96GL_DG68-01105C-00_EN.indd 5 2019-02-06 2:30:20

English6

To Our Valued Customer:

Congratulations on your purchase of the very latest in Dacor® products! Our unique

combination of features, style, and performance make us a great addition to your home.

To familiarize yourself with the controls, functions, and full potential of your new Dacor

range, read this manual thoroughly, starting with Before you begin (pg. 7).

Dacor appliances are designed and manufactured with quality and pride, while working

within the framework of our company values. Should you ever have an issue with your

range, first consult Troubleshooting (Pgs. 93 – 99), where you will find suggestions and

remedies that may pre-empt a service call.

Valuable customer input helps us continually improve our products and services, so feel

free to contact our Customer Assurance Team for assistance with all your product-support

needs.

Dacor Customer Assurance

14425 Clark Avenue

City of Industry, CA 91745

Telephone: 833-35-ELITE (833-353-5483) USA, Canada

Fax: (626) 403-3130

Hours of Operation: Mon – Fri, 5:00 a.m. to 5:00 p.m. Pacific Time

Website: www.dacor.com/customer-care/contact-us

Thanks for choosing Dacor for your home. We are a company built by families for families,

and we are dedicated to serving yours. We are confident that your new Dacor range will

deliver top-level performance and enjoyment for decades to come.

Sincerely,

NX9900R_PRORANGE_DOP36M96GL_DG68-01105C-00_EN.indd 6 2019-02-06 2:30:20

English 7

Before you begin

Important

• The overall design and/or accessories may

differ with the model.

Installer

• To promote safety and minimize

problems, read this manual thoroughly

before starting the installation. Leave

this manual with the user.

• Write the appliance’s model/serial

numbers in this manual for service/

maintenance reference.

User

• Keep this manual for personal reference

and for that of inspectors, service

personnel, etc.

Clean the oven thoroughly before using it for the first time. Then, remove the accessories,

set the oven to Bake, and then run the oven at 400 °F for 1 hour. There will be a

distinctive odor. This is normal.

Ensure your kitchen is well ventilated during this conditioning period.

Energy saving tips

• During cooking, the oven door should remain closed except when you turn food over.

Do not open the door frequently during cooking to maintain the oven temperature and

to save energy.

• If cooking time is more than 30 minutes, you can switch the oven off 5-10 minutes

before the end of the cooking time to save energy. The residual heat will complete the

cooking process.

• To save energy and reduce the time needed for re-heating the oven, plan oven use to

avoid turning the oven off between cooking one item and the next.

• Whenever possible, cook more than one item at a time.

NX9900R_PRORANGE_DOP36M96GL_DG68-01105C-00_EN.indd 7 2019-02-06 2:30:20

English8

Before you begin

Oven vent/cooling vent

Oven vent

Cooling vent

Oven vent

Both the oven vent and the cooling vent

are located at the back of the oven range.

Proper air circulation prevents combustion

problems and ensures good performance.

• Do not block the vent or its

surroundings with objects.

• Use caution when placing items near

the vent. Hot steam can cause them to

overheat or melt.

• Be careful when operating the oven

whatever the mode it is. The oven lets

very hot air out through the vent.

• Make sure that the oven vent cover

sits securely on the cooktop. You can

verify that the oven vent cover is in

the correct position by confirming that

the tabs on the bottom side of the oven

vent cover fit into the corresponding

slots on the cooktop.

NX9900R_PRORANGE_DOP36M96GL_DG68-01105C-00_EN.indd 8 2019-02-06 2:30:21

English 9

Regulatory Notice

1. FCC Notice

CAUTION

FCC CAUTION: Any changes or modifications not expressly approved

by the party responsible for compliance could void the user’s

authority to operate the equipment.

This device complies with Part 15 of FCC Rules. Operation is Subject

to following two conditions:

1) This device may not cause harmful interference, and

2) This device must accept any interference received including

interference that cause undesired operation.

For products available in the US/Canadian markets, only channels

1–11 are available. You cannot select any other channels.

FCC STATEMENT:

This equipment has been tested and found to comply within the

limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

• Reorienting or relocating the receiving antennas.

• Increasing the separation between the equipment and receiver.

NX9900R_PRORANGE_DOP36M96GL_DG68-01105C-00_EN.indd 9 2019-02-06 2:30:21

English10

Regulatory Notice

• Connecting the equipment to an outlet that is on a different circuit

than the radio or TV.

• Consulting the dealer or an experienced radio/TV technician for

help.

FCC RADIATION EXPOSURE STATEMENT:

This equipment complies with FCC radiation exposure limits set

forth for an uncontrolled environment. This equipment should be

installed and operated so there is at least 8 inches (20 cm) between

the radiator and your body. This device and its antenna(s) must not

be co-located or operated in conjunction with any other antenna or

transmitter.

2. IC Notice

The term “IC” before the radio certification number only signifies

that Industry Canada technical specifications were met. Operation

is subject to the following two conditions: (1) this device may not

cause interference, and (2) this device must accept any interference,

including interference that may cause undesired operation of the

device.

This Class B digital apparatus complies with Canadian ICES-003.

For products available in the US/Canadian markets, only channels

1–11 are available. You cannot select any other channels.

NX9900R_PRORANGE_DOP36M96GL_DG68-01105C-00_EN.indd 10 2019-02-06 2:30:21

Other manuals for DOP36M96GL Series

Table of contents

Other Dacor Range manuals

Dacor

Dacor Epicure ER36D User manual

Dacor

Dacor Modernist Pro Series User manual

Dacor

Dacor DOP36M96GLM User manual

Dacor

Dacor HGPR36S User manual

Dacor

Dacor Renaissance RNRP30G User manual

Dacor

Dacor Epicure EGR30 Technical manual

Dacor

Dacor HDPR36S User manual

Dacor

Dacor Heritage Pro HGPR30S Technical manual

Dacor

Dacor MillenniaTM User manual

Dacor

Dacor Epicure ER30G User manual

Dacor

Dacor Millennia MRES30S Technical manual

Dacor

Dacor DOP36M96GL Series User manual

Dacor

Dacor Renaissance RR30NFS User manual

Dacor

Dacor Renaissance RNRP36GSNGH User manual

Dacor

Dacor Epicure ER36D User manual

Dacor

Dacor ER30D User manual

Dacor

Dacor Epicure ERD30 User manual

Dacor

Dacor Millennia MRES30 User manual

Dacor

Dacor Millennia MRES30S User manual

Dacor

Dacor Renaissance RNRP30GS User manual

Dacor

Dacor DR30GIS User manual

Dacor

Dacor Millennia MRES30S Technical manual

Dacor

Dacor Millenia DR30D User manual

Dacor

Dacor Renaissance RNRP30GSNG User manual

Popular Range manuals by other brands

Samsung

Samsung FCQ321HTUW Service manual

Kenmore

Kenmore 790.45712 Use & care guide

Wolf

Wolf CHR CHSSR owner's manual

Smeg

Smeg Built-in Microwave Oven Instructions for the user

Zanussi

Zanussi ZCG054G user manual

Whirlpool

Whirlpool 8575985-W Warranty

Frigidaire

Frigidaire 316000635 owner's guide

GE JCSS630 quick start guide

Samsung

Samsung NX58M9960P series installation manual

Hotpoint

Hotpoint RB524R Use and care & installation instructions

Whirlpool

Whirlpool Roper FGP305KW3 Use & care guide

Amana

Amana ART6610 SERIES owner's manual

Maytag

Maytag MERH770WB Use & care guide

Fulgor Milano

Fulgor Milano SOFIA Use & care manual

Premier

Premier EF-4358GH instruction manual

Kenmore

Kenmore 790.9010 Series Use & care guide

KitchenAid

KitchenAid KESC300 Use and care guide

Frigidaire

Frigidaire FFEF3012LS Service data sheet
