D-Link DSL-2642B User manual

QUICK

INSTALLATION

GUIDE

ALL-IN-ONE WIRELESS G ADSL2+ MODEM ROUTER

DSL-2642B

ENGLISH

CONTENTS OF

PACKAGING

CONTENTS

INSTALLATION CD

INCLUDES SET-UP WIZARD & TECHNICAL MANUALS

POWER ADAPTER

ADAPTER

ETHERNET CABLE (RJ-45 CABLE)

CONNECT THE ROUTER TO YOUR PC DURING SET-UP

If any of these items are missing from your packaging contact

your reseller

ALL-IN-ONE WIRELESS G ADSL2+ MODEM ROUTER

DSL-2642B

RJ-11 PHONE CABLE

DSL-2642B 3

ENGLISH

PRODUCT

SETUP

CD SETUP WIZARD

SET-UP WIZARD CD

The CD contains all of the instructions required to set-up DSL-2642B

INSERT CD

Insert the CD into the CD drive of your computer. The set-up

wizard should start automatically. Make sure that your internet

connection is active. (Do not plug in DSL-2642B yet)

SET-UP WIZARD

Select your language from the list of options and follow the

steps within the wizard to complete the set-up of DSL-2642B

ADVANCED SET-UP (ACCESS VIA IP ADDRESS)

To congure DSL-2642B manually (without the set-up CD) connect your computer to the DSL-2642B

using the ethernet cable provided. Then connect the power cable on the DSL-2642B. The power light

will display as solid green.

Then simply open a browser window and enter the IP address in the browser address eld:

IP ADDRESS: http://192.168.1.1

USERNAME: admin

PASSWORD: admin

DSL-2642B

ENGLISH

TROUBLESHOOTING

SET-UP AND CONFIGURATION PROBLEMS

1. HOW DO I CONFIGURE MY DSL-2642B ROUTER WITHOUT THE CD, OR CHECK MY

WIRELESS NETWORK NAME (SSID) AND WIRELESS ENCRYPTION KEY?

- Connect your PC to the router using an Ethernet cable.

- Open a web browser and enter the address http://192.168.1.1

- The default username is “admin”. The default password is “admin”.

- If you have changed the password and can not remember it, you will need to reset the router to

set the password back to “admin”.

2. HOW DO I RESET MY DSL-2642B ROUTER TO FACTORY DEFAULT SETTINGS?

- Ensure the router is powered on.

- Press and hold the reset button on the rear of the device for 10 seconds.

Note: Resetting the router to factory default will erase the current conguration settings. To re-

congure your settings, log into the router as outlined in question 1, then run the Setup Wizard.

3. HOW DO I ADD A NEW WIRELESS CLIENT OR PC IF I HAVE FORGOTTEN MY

WIRELESS NETWORK NAME (SSID) OR WIRELESS ENCRYPTION KEY?

- Every PC that needs to connect to the router wirelessly, you will need to ensure you use the

correct Wireless Network Name (SSID) and encryption key.

- Use the web based user interface (as described in question 1 above) to check or choose your

wireless settings.

- Make sure you write down these settings so that you can enter them into each wirelessly

connected PC. You will nd a dedicated area on the back of this document, this important

information for future use.

4. WHY CAN I NOT GET AN INTERNET CONNECTION?

- For ADSL users please contact your ISP to make sure the service has been enabled/connected

by your ISP and that your ISP username and password is correct.

DSL-2642B 5

ENGLISH

TECHNICAL SUPPORT

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Australia:

Tel: 1300-766-868

24/7 Technical Support

Web: http://www.dlink.com.au

E-mail: [email protected]

India:

Tel: 1800-233-0000 (MTNL & BSNL Toll Free)

+91-832-2885700 (GSM, CDMS & Others)

Web: www.dlink.co.in

E-Mail: [email protected]

[email protected]

Indonesia, Malaysia, Singapore and Thailand:

Tel: +62-21-5731610 (Indonesia)

Tel: 1800-882-880 (Malaysia)

Tel: +65 6501 4200 (Singapore)

Tel: +66-2-719-8978/9 (Thailand)

24/7, for English Support only

Web: http://www.dlink.com.sg/support/

E-mail: [email protected]

Korea:

Tel: +82-2-2028-1815

Monday to Friday 9:00am to 6:00pm

Web: http://www.d-link.co.kr

E-mail: [email protected]

New Zealand:

Tel: 0800-900-900

24/7 Technical Support

Web: http://www.dlink.co.nz

E-mail: [email protected]

Egypt:

Tel: +202-2919035

+202-2919047

Sunday to Thursday 9:00am to 5:00pm

Web: http://support.dlink-me.com

E-mail: [email protected]

Iran:

Tel: +98-21-88880918,19

Saturday to Thursday 9:00am to 5:00pm

Web: http://support.dlink-me.com

E-mail: [email protected]

[email protected]

DSL-2642B

ENGLISH

TECHNICAL SUPPORT

You can nd software updates and user documentation on the D-Link website.

Tech Support for customers in

Israel:

Magshimim 20, Petach Tikva 49348

Main Tel: 972-3-9215173

Customer Support Tel: 972-3-9212886

Web: www.dlink.co.il

Pakistan:

Tel: +92-21-4548158

+92-21-4548310

Monday to Friday 10:00am to 6:00pm

Web: http://support.dlink-me.com

E-mail: [email protected]

South Africa and Sub Sahara Region:

Tel: +27-12-665-2165

08600 DLINK (for South Africa only)

Monday to Friday 8:30am to 9:00pm South Africa Time

Web: http://www.d-link.co.za

E-mail: [email protected]

Turkey:

Tel: +90-212-2895659

Monday to Friday 9:00am to 6:00pm

Web: http://www.dlink.com.tr

E-mail: [email protected]

U.A.E and North Africa:

Tel: +971-4-4278127 (U.A.E)

Sunday to Thursday 9.00AM to 6.00PM GMT+4

Web: http://www.dlink-me.com

E-mail: [email protected]

Saudi ARABIA (KSA):

Tel: +971-4-4278127 (U.A.E)

Sunday to Thursday 9.00AM to 6.00PM GMT+4

Web: http://www.dlink-me.com

E-mail: [email protected]

NOTES

Ver. 1.00(AU) 2010/02/23 6

WIRELESS NETWORK REMINDER

Wireless Network Name (SSID)

Wireless Network Password
