D-Link DWL-8600AP User manual

2 DWL-8600AP Install Guide

Minimum System Requirements:

• CD-ROMDrive

• ComputerswithWindows®,Macintosh®,orLinux-basedoperating

systems

• InstalledEthernetAdapter

• InternetExplorerversion6.0,Chrome2.0.Safari2.0,orFirefox3.0

andabove

System Requirements

Package Contents

Note: Usingapowersupplywithadifferentvoltagethantheoneincludedwiththe

DWL-8600APwillcausedamageandvoidthewarrantyforthisproduct.

If any of the above items are missing, please contact your reseller.

DWL-8600AP802.11n

AccessPoint

PowerAdapter

EthernetCablePoEBaseunit

CD-ROM

PowerCord

ConsoleCable

MountingPlate

DWL-8600AP Install Guide 3

Hardware Overview

LEDs

5 GHz-Whenlit,theaccesspointisoperatingat5GHz.

Thislightwillblinkwhenthereiswirelesstrafc.

2.4 GHz-Whenlit,theaccesspointisoperatingat2.4GHz.

Thislightwillblinkwhenthereiswirelesstrafc.

LAN-SolidlightwhentheEthernetportisconnectedtoa

workingport,suchasarouterorswitch.Thelightwillblink

whenthereistrafcthroughLANport.

POWER-Thelightwillblinkduringbootup.Oncesolid,the

accesspointisready.

4 DWL-8600AP Install Guide

Installing the Hardware

Power Receptor

LAN Port (PoE)

Console Port

Reset Button

* 2.4GHz antenna connectors are located on the bottom of the access point.

5GHz Antenna Connectors*

DWL-8600AP Install Guide 5

Topowertheaccesspoint,youcanuseoneofthefollowingmethods:

1.Usethesuppliedpoweradapter

2.ConnectoneendofyourEthernetcableintotheLAN(PoE)portonthe

DWL-8600APandtheotherendintooneportonaPoEswitch.

To setup and manage the DWL-8600AP from a computer, use one of the

followingmethods:

1. Connect a straight through Ethernet cable between the access point

andyourcomputer.

2. Connecttheaccesspointtoaswitchorrouteranduseacomputerfrom

acomputerthatisalsoconnectedtothatswitchorrouter.

6 DWL-8600AP Install Guide

Step 1:Inserttheprovidedwallanchorsinthewallwherethemountingplate

willbeattached.

Mounting Plate Assembly

Step 2:Usetheprovidedscrewstosecurethemountingplateonthewall.

DWL-8600AP Install Guide 7

Step 3:Attachtheremainingscrewssecurelytothebackofthe

DWL-8600AP.

Step 4:AttachtheDWL-8600APtothemountingplate.

8 DWL-8600AP Install Guide

Step 5:SlidetheDWL-8600APdownintothegroovesonthemountingplateto

secureittotheplate.

DWL-8600AP Install Guide 9

WhenyouhavecompletedthestepsinthisInstallationGuideandcongured

yourforyournetwork,yournetworkshouldlooksimilartothis:

Your Setup is Complete

*MaximumWirelesssignalratederivedfromIEEE802.11n(draft2.0)specications.Actualdata

throughputwillvary.Networkconditionsandenvironmentalfactors,includingvolumeofnetwork

trafc, building materials and construction, and network overhead lower actual data throughput

rate.

10 DWL-8600AP Install Guide

Notes
