D-Link DGE-528T User manual

1

Next, TURN OFF the computer and unplug

the power cord.

Quick Installation Guide

DGE-528T

Gigabit PCI Desktop Adapter

Check Your Package Contents

DGE-528T CD with Manual and Drivers

Installing the DGE-528T Drivers

A. Insert the driver CD, which is included with the DGE-528T, into the CD-ROM of your

computer.

B. Choose the preferred language and click on “Install Drivers”. When prompted “Finished”,

click OK. Or if prompted to reboot (under Windows ME and Windows 98 only), click Yes.

Installing the DGE-528T into the computer’s PCI slot

A. Power off your computer and disconnect the power cord.

B. Remove the back cover of your computer. (Refer to your computer’s manual if needed.)

C. Locate an available PCI slot. PCI slots are usually white or cream coloured.

D. Remove the back plate (the small piece of metal that covers the opening for the PCI card on

the back cover that you just removed.)

E. Insert the DGE-528T carefully and firmly into the PCI slot.

DO NOT insert the DGE-528T into the computer’s

PCI slot before installing the drivers.

Caution: To avoid damage caused by static electricity, make sure to properly

ground yourself by first touching a metal part of your computer to discharge any

static electricity before working with the DGE-528T Ethernet Adapter.

2

F. Secure the DGE-528T with the screw from the back plate.

G. Replace your computer’s cover.

Finishing the Installation

A. Reconnect the power cord and power on the computer.

B. Windows should automatically detect and install the adapter.

C. If prompted to restart (for Microsoft Windows 98/ME only), click “Yes”.

Troubleshooting

1. If I’ve lost my CD, what can I do?

The CD contains software drivers and manual which can be obtained from D-Link (see

Technical Support below). Windows 2000 or XP in most cases will automatically install the

correct drivers.

2. What do I do if the installed card does not

seem to function properly?

•Check that the card appears under

START>CONTROLPANEL>SYSTEM>HARDW

ARE>DEVICE MANAGER>NETWORK

ADAPTERS.

•If it does not appear, make sure you have

inserted the PCI card correctly or try inserting the

card into an alternative PCI slot.

•If it appears with an error “!” or “?”, remove or

uninstall the device by right clicking on the

device. Restart the computer, upon restart

Windows will redetect it. If error persists, try

removing the card and uninstalling the driver.

Repeat the installation process.

Technical Support

Thank you for choosing D-Link products. For further information, support and product manuals

please visit the D-Link website at www.dlink.eu.

www.dlink.co.uk

: 08456 12 0003
