CURTIS GOLD CUP BREWER

TROUBLESHOOTING GUIDE

Model: CGC

Service & Sales

1-800-421-6150 www.wilburcurtis.com

Service & Sales

1-800-421-6150 www.wilburcurtis.com

PART # DESCRIPTION

1. WC-1809 FAUCET, HOT WATER

2. WC-817 VALVE, DUMP RIGHT 120V 12W

3. WC-889 VALVE, DUMP LEFT 120V 12W

4. WC-2962-101K KIT, FITTING SPRAYHEAD KYNAR

5. WC-29025 SPRAYHEAD, PURPLE

6. WC-826L VALVE, INLET

7. WC-43062

GASKET, LID

8. WC-5527K KIT, PROBE WATER LEVEL O-RING NUT

9. WC-5310 TUBE, 5/16 SILICONE

WATER RELATED HEAT RELATED

PART # DESCRIPTION

MASTER CONTROL

BREWER PARTS IDENTIFICATION

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

10. WC-589-101 TRANSFORMER, 120/230VAC

11. WC-6193-0 HEATSINK AND TRIAC

12. WC-14045-101 CURRENT SENSOR ASSY G4

13. WC-522 THERMOSTAT, HI LIMIT HEATER

14. WC-1438-101 SENSOR, TEMPERATURE TANK

15. WC-917-04 ELEMENT, HEATING W/ JAM NUT WASHER

16. WC-10000

CONTROL MODULE, G4

17. WC-10001

UNIVERSAL POWER MODULE, G4 (UPM)

18. WC-103 SWITCH, TOGGLE DPST 25A 125/25OVAC

MAIN VIEW

TOP VIEW

TANK VIEW

Service & Sales

1-800-421-6150 www.wilburcurtis.com

WC-1809

FAUCET, HOT WATER

WC-889

VALVE, DUMP LEFT

1234

PARTS IMAGES

WC-817

VALVE, DUMP RIGHT

WC-2962-101K

KIT, FITTING SPRAYHEAD

WC-29025

SPRAYHEAD, PURPLE

WC-43062

GASKET, TANK LID

5678

WC-826L

VALVE, INLET

WC-5527K

KIT, PROBE WATER LEVEL O-RING

WC-5310

TUBE, SILICONE

WC-6193-0

HEATSINK AND TRIAC

910 11 12

WC-589-101

TRANSFORMER

WC-14045-101

CURRENT SENSOR ASSY G4

WC-522

THERMOSTAT, HI LIMIT

WC-917-04

ELEMENT, HEATING

13 14 15 16

WC-1438-101

SENSOR, TEMPERATURE TANK

WC-10000

CONTROL MODULE, G4

WC-10001

UNIVERSAL POWER MODULE

17 18

WC-103

SWITCH, TOGGLE

Service & Sales

1-800-421-6150 www.wilburcurtis.com

Verify 120 volts between Blu14 & WHT14

on the heating element. If yes, replace

heating element. If no, proceed to #2.

With the toggle switch turned off, remove

WHT/GRY from triac gate, and connect to

Red meter lead. Turn on toggle switch, and

place Black meter lead to Neutral and/or L1

on power block. Verify 120 volts. If yes, re-

place triac. If no, replace U.P.M.

1

2

3

HEATING ISSUES

Not heating (120 volt):

LCD reads “Heating”

4

TROUBLESHOOTING INSTRUCTIONS

Verify that the tank temperature is pro-

grammed for 200 degrees. If yes, proceed

to #2. If no, adjust accordingly.

Turn off toggle switch, and unplug the tem-

perature sensor from wiring harness. Set

dvm to read 200k ohm, and connect meter

leads to sensor connector. Sensor should

read over 100k ohm if the tank is cold, and

under 10k ohm if the tank is hot.

If the sensor is not within this range, replace

the sensor. If the sensor is within this range,

replace the UPM.

1

2

Not heating (120/220 volt):

LCD reads “Ready”

Verify 220 volts between L1-L2 on the

power block. If yes, proceed to #2. If no,

verify that the unit is plugged in correctly,

and that the panel breaker is turned on.

Verify 220 volts between #2 & #4 on the

manual reset thermostat. If yes, proceed to

#3, if no, reset or replace the manual reset

thermostat.

Verify 220 volts across the toggle switch. If

yes, proceed to #4. If no, replace the toggle

switch.

Verify 220 volts across the heating ele-

ments. If yes, proceed to #5. If no, verify

120 vac on the triac gate. If yes, replace the

triac. If no, replace the UPM.

Verify 9 ohm across each active heating

element, and replace any heating element

that reads “OPEN” or is “GROUNDED”

1

2

Not heating (220 volt):

LCD reads “Heating”

3

Verify that the resistance on the tempera-

ture sensor is less than 10k ohms with a

hot tank (200+ degrees) If no, verify correct

mounting and that the walls of the tank are

free of mineral deposits.

If yes, bypass the sensor using a jumper

with a 5k ohm resistor. If the LCD reads

“ready” and the unit stops heating, replace

the temperature sensor, if not, replace the

UPM.

1

2

Overheating (120/220 volt):

LCD reads “Heating”

Check across A-1 & A-2 of triac for continuity

.

If continuity is present, replace triac, if no

continuity, replace UPM.

1

Overheating (120/220 volt):

LCD reads “Ready”

Service & Sales

1-800-421-6150 www.wilburcurtis.com

BREWING ISSUES

TANK FILLING ISSUES

Verify 120 volts at the inlet valve coil

Replace inlet valve

Remove orange wire from the water

Level probe. Does the tank ll?

Replace the water level probe

Replace the UPM

Turn OFF toggle switch.

Does the tank continue to ll?

Overlling: Not lling:

Yes:

No:

Yes:

No:

iEnsure correct alignment of the sprayhead

tting and that the tubing is routed properly to

allow for maximum water ow.

Ensure that the sprayhead is free of mineral

deposits, and properly connected.

LCD does not read “Brewing”:

If the LCD reads “Ready to Brew” and no

response when Brew Button is pressed, replace

the UPM

LCD reads “Brewing”:

Does water ow from the hot water faucet? If yes,

verify 120 volts at the dump valve coil. If voltage

is present at the dump valve coil, replace the

dump valve.

If okay, replace the UPM. (Verify the resistance

on the dump valve coil to be open in one direc-

tion, and under 2k ohm in the other direction

before replacing the UPM).

If water does not ow from the hot water faucet,

replace the water level probe.

Brewing Short Pots:

Verify that the dump valve outlet tting on the

tank, the tubing between the tank outlet and the

sprayhead tting, the sprayhead, and dump valve

are clear of obstructions.

Ensure correct alignment of the sprayhead tting

and that the tubing is routed properly to allow for

maximum water ow.

Verify that the hot water tank is lling correctly. If

not, replace the water level probe.

If all the above are okay, replace the dump

valve.

Overowing the Pot:

Ensure that the sprayhead has not been

removed. Replace as needed.

Ensure that the hot water tank is not overowing

(See Tank Filling Issues).

Ensure cold brew lock is set to 5 degrees.

Ensure that lime/debis are not a factor. If all the

above are okay, replace the dump valve.

www.wilburcurtis.com

TROUBLESHOOTING INSTRUCTIONS

Replace water inlet valve

Remove the orange wire from the

water level probe and connect it to

ground. Does the tank stop lling?

Replace the water level probe

Replace the UPM

Yes:

No:

Yes:

No:

Service & Sales

1-800-421-6150 www.wilburcurtis.com

NOTES

__________________________________________________________________________________________

APR/2015 M118_TS_WC_CGC_revNC

Wilbur Curs Co., Inc.

6913 Acco Street, Montebello CA 90640

Customer Service: 800.421.6150 | 323.837.2300

csrassistance@wilburcurs.com

Tech Support: 800.995.0417

www.wilburcurs.com
