ALARM AND WARNINGS
OVERLOAD WARNING: When the UPS is overloaded, the unit will automatically shut off the output
after 15 seconds. During an overload, the MESSAGE-BATTERY indicator lights up constantly and
emits an audible warning.
OUTPUT SHORT CIRCUIT WARNING: The output is automatically disconnected in the event of a
short circuit that can occur at the motor outputs. LINE-MASSAGE-BATTERY Indicators blink and
beep sound warring.
BATTERY NOT CHARGING WARNING: If the BATTERY indicator flashes while the mains is on, the
battery is being charged. If the battery is not charging, the BATTERY indicator will turn on with a
warning sound for 8 seconds every 5 minutes.
NO MAINS WARNING: LINE indicator is flashing. Will be an audible buzzer warning every 15
minutes.
WARNING ON OPERATION IN INVERTER: The "BATTERY" indicator is constantly light and a buzzer
sound every 3 seconds.
INSTALLATION VIEW. 1. MOTOR 2. MOTOR
Attention: the blinds must be actuated sequentially. When you run two flaps at the same time, your device
may give an overload warning. In this case, the “LINE-BATTERY-MESSAGE” indicators will flash
simultaneously. Switch the device off and on again with the ON-OFF button.
INSTALLING THE REMOTE CONTROLLER
Use the "ON-OFF" switch on the UPS to the "ON" position. Press thE loading button on the UPS for 2
seconds. The MESSAGE - BATTERY indicator will light up with the beep, if these two lights are on together,
the control teaching mode has been activated. When you press the loading button again without taking
your hand while the remote identification mode is active, the MESSAGE - BATTERY lights will blink one by
one, press the number one button of your remote control. At this point, each remote you introduce will
control the MOTOR OUTPUT.
When you take your hand off the loading button, this time the LINE - MESSAGE light will turn on together.
When you press the loading button again without taking your hand, the LINE - MESSAGE lights will flash
sequentially, Perform the identification process by pressing the number two button of your
remote. At this stage, every remote you introduce will control MOTOR OUTPUT 2.
Wait 15 seconds to exit this mode or turn your device off and on from the On / 0ff button.
DELETING THE REMOTE CONTROL FROM THE MEMORY
Turn the "ON-OFF I switch" on the UPS to the OFF position. Hold down the LOAD button
and at the same time turn the "ON-OFF" switch to the "ON" position. As soon as you take
your hand off the button, the deletion will be completed.
Attention: When the deletion is done, all the controls that have been entered into the
memory will be deleted from the memory.
CHARGING
If there is utility power input, even if the UPS is turned off, the UPS will start charging
automatically. Make your shutter run from the batteries by disconnecting the mains
electricity coming to the UPS every 2 months. In this way, you will ensure that the batteries
are discharged and recharged later, and you will extend the working life of the batteries.
SAFETY WARNINGS
1. This manual contains important safety instructions. Please follow all instructions in the
installation phase. Please read this manual carefully before starting to commission the
device..
To avoid the risk of fire and electrical shock, install the device and control the temperature
and humidity indoors.
Electric shock risk! Even if the mains is not connected inside the UPS, live points may be
energized and dangerous due to the battery power supply.
2 This UPS is designed only for automatic shutter systems and cannot be used for other
purposes.
FAILURE STATUS
If the UPS does not work during power failure, the batteries of the UPS may be
defective, the charging unit may be defective. Contact your dealer.
UPS control distance is short. Your remote's battery may be dead, there may be
intensive electrical cables passing near the UPS antenna, there may be intensity (noise)
in the 433 Mhz band. Contact your dealer.
If the shutter works in one direction, the motor output ends may be connected
incorrectly.
Correct the wiring, as a result of incorrect connection the UPS may have failed. Contact
your dealer.
If the shutter does not work during power failure, the shutter may be stuck, the batteries
may be empty. Contact your dealer.
If the line led is not lit, there may be no power to the UPS. The fuse may have blown.
