Cuisinart PG-26692 User manual

PG-26692

Quick Reference SETUP Guide

Keeping it CLEAN

Push the channel cover away

from you and lift up to access

the coffee chute.

To Clear Chute: With Coffee

Scoop/Cleaning Brush, brush

ground coffee toward front of

unit.

Open grind chute lever to allow

grounds into filter basket.

Be sure the filter basket is in

place to catch the grounds.

2.1.

Fully immerse the ﬁlter in cold tap water

and soak for 15 minutes (see complete

instructions in your Instruction Booklet).

Insert the charcoal water ﬁlter into

the water ﬁlter holder. Open the water

reservoir and insert it into the unit.

Pour your desired amount of water into

the water reservoir. A water level indicator

is located on the side of the unit.

Helpful Hint: “Preheat” your carafe by rinsing

it out with hot water before brewing.

Open the ﬁlter basket door by pressing

the Release button and insert a paper ﬁlter

or permanent ﬁlter into the ﬁlter basket

holder. Replace the cover, line up arrows,

and close door.

Remove hopper lid, ﬁll with beans,

and replace the lid.

To start grinding & brewing, press the On/Off

button. Once the coffee has ﬁnished brewing,

the unit will immediately shut off and alert

you with a beep.

Select the amount of beans you wish to grind

with the Grind Control knob. Select your

desired coffee strength with the Strength

Control button. Your selected coffee strength

will be indicated on the LCD display.

IMPORTANT

Do not throw away. Read before operating your new

Brewing System. Keep for future reference.

These helpful hints are intended to be a supplement to the Instruction Booklet. In order to ensure

safe operation and optimum performance, please read the entire Instruction Booklet.

Grind Chute Cleaning Methods:

For best results, clean the grind chute every 7 to 10 uses

depending on the type of beans you are using.

Fully Automatic Burr Grind & Brew Thermal™Coffeemaker

Permanent filter, filter basket, filter basket cover,

carafe and lid.

Wash in warm soapy water and rinse thoroughly

or clean in the upper rack of the dishwasher.

Dry all parts after every use.

Remove hopper lid, turn hopper release knob to unlocked position

to remove hopper. Set aside unused coffee beans.

Wash hopper and lid with warm, soapy water,

rinse thoroughly. Or place hopper and lid on

upper rack of dishwasher.

NOTE: DRY ALL PARTS THOROUGHLY.

DO NOT ADD WATER TO UNIT ONCE

THE HOPPER IS REMOVED AS WATER

CAN DAMAGE THE GRINDER MOTOR.

Remove any excess ground coffee

from the grinder area before placing

hopper and lid back on.

Hopper Cleaning Methods:

To set the Time: Press and hold the Hour or Minute button until the clock begins ﬂashing. Hold down the Hour

or Minute button to quickly scroll through the numbers. When desired time approaches, release the button and

press repeatedly to advance one digit at a time. To ﬁnish, wait for the numbers to stop ﬂashing.

To program the Auto-On: Press and hold the Program button until the clock begins ﬂashing. Set the time you

want coffee to begin brewing (follow “set the time” instructions). Once complete, press the Program button

again. The green indicator light will come on to remind you that the programming function is in use.

3. At the programmed time, the red On/Off

indicator light will come on, indicating that

the brew cycle is starting. 4. To start the brew cycle at the same time

on another day, simply press the Program

button and release. The green Auto-On

will illuminate.

Quick Reference PROGRAMMING Guide Keeping it CLEAN
