Crye Precision JUMPABLE PLATE CARRIER User manual
EQUIPMENT INFORMATION
INTRODUCTION
COMPONENT DESCRIPTIONS
OPERATOR INSTRUCTIONS
INSTALLING + ADJUSTING SKELETAL™ CUMMERBUND
INSTALLING + ADJUSTING SINGLE STRAPS
INSTALLING BALLISTIC PROTECTION
DONNING + DOFFING
ADJUSTING RIDE HEIGHT (SHOULDER STRAPS)
OPTIONAL ACCESSORIES
6x6” SIDE POUCH (SKELETAL™ ATTACHMENT)
6x6” SIDE POUCH (FRONT CARRIER ATTACHMENT)
6x12” FLANK POUCH
MBITR/MAG POUCH
01
02
05
06
07
08
09
11
12
13
14
EQUIPMENT INFORMATION
EQUIPMENT INFORMATION 1
INTRODUCTION
The Jumpable Plate Carrier™ (JPC) is a lightweight and minimal armor vest designed for maximum mobility, weight
savings, and packability. At less than one pound for the entire carrier, the JPC™ offers a variety of configuration
options to suit an operator’s needs in terms of protection and comfort. It features our Skeletal™ cummerbund system
with our patent-pending Integrated Attachment System that allows pouches to be mounted on both the inside and
outside of the cummerbund, shedding unnecessary weight and bulk while improving ventilation.
FEATURES
�
Integrated triple mag pouch on front of carrier
�
Built-in admin pouch in upper portion of front carrier (holds pistol mags, chem lights, maps)
�
High performance stretch material that allows for different thickness of plates
�
Padded ventilation on interior panels of vest for added comfort
�
Quick-attach side loops for add-on coverage
�
Durable anti-slip shoulder straps
�
Groin protection attachment point
�
Low-profile cummerbund attachment that provides maximum adjustability and allows for chest expansion
�
Single strap side closure option for ultra-lightweight configurations
2JUMPABLE PLATE CARRIERTM (JPC)
COMPONENT DESCRIPTIONS
1. FRONT CARRIER
Supports low-vis protection up to Level
IV standalone plates. MOLLE webbing
on outer surface. Holds three magazines.
Easy-access top admin pouch for storage.
Shoulder slip-on covers with integrated
cord management. Padded ventilation
panel on inner surface for comfort.
2. REAR CARRIER
Supports low-vis protection up to Level
IV standalone plates. MOLLE webbing on
outer surface. Padded ventilation panel on
inner surface for comfort.
FRONT
FRONT
BACK
BACK
Vest shown disassembled to depict separate components. Not shown to scale.
EQUIPMENT INFORMATION 3
3. 3-BAND CUMMERBUND
Our Skeletal™ cummerbund that enhances
performance by cutting weight without
sacrificing functionality. Allows pouches
to be mounted on the inside or outside of
cummerbund. Comes with elastic cords to
install and secure to the vest (not pictured).
4. SINGLE STRAPS
Simplest side closure and adjustment
configuration. This option can be used in
place of Skeletal™ cummerbund if desired.
OPERATOR INSTRUCTIONS
OPERATOR INSTRUCTIONS 5
INSTALLING + ADJUSTING SKELETAL™ CUMMERBUND
1. Lay rear carrier flat as shown. Insert cummerbund ends through three
openings near the side edges of the carrier. Ensure that loop panels of
cummerbund are facing up. Repeat for other side.
3A. Tie a knot in the elastic cord to secure the weave. The extra slack of
the elastic cord can be tightened or loosened to accommodate personal
preference. Pull cummerbunds apart to ensure the weave and knot are
secure.
2. Using included elastic cord, weave together the ends of the Skeletal™
cummerbunds from the top to the bottom in a zigzag pattern.
3B. If additional cummerbund size accommodation is required, the
cummerbund ends can be tied to the MOLLE panel as pictured in a
similar zigzag weaving pattern. A second elastic cord is included for this
configuration.
6JUMPABLE PLATE CARRIERTM (JPC)
1. Lay rear carrier flat as shown. Locate strap buckles near side edges of
carrier. Ensure that loop panels of strap are facing up. Insert non hook-
and-loop end of single strap up and through buckle as illustrated.
2. After installing ballistic protection (see next page), don JPC by placing
over the head onto the shoulders. Open the front panel flap of the carrier
and attach hook panels of strap to loop panel of carrier and close the flap.
3. To adjust the tightness of the single straps, grab the extra slack in the
strap and pull forward to achieve desired setting. Use the rear buckles to
release strap tension.
INSTALLING + ADJUSTING SINGLE STRAPS
