Creality CR-100 Manual

CR-100 Guide Book

本说明书依据CR-1003D打印机编制而成

This guide book is for standard CR-100.

详细使用指南见TF卡

Detailed instructions for user are available on the TF card.

Screen

Button board

USB port

Power port

TF Slot

Extuder

Holder

Nozzle

Power Switch

Parameter

Model CR-100

MoldingTech.FDM

PrintingSize 100*100*80mm

PrintingSpeed ≤180mm/s，Normal 30-60MM/S

Precision ±0.1mm

LayerThickness 0.1-0.4mm

NozzleDiameter 0.4mm

Nozzle Temp. 200℃

PrintingMode TF card One-button Print，oﬄine printing, Remote printing

FileFormatstl，obj，amf

SliceSoftwareCreality Slicer/Cura/Simplify3D

PowerSupply Input:100-240V AC 1.2A 50/60Hz

Output:DC 12V 5.0A

Total Power60W

Filament φ1.75mm PLA

Function Description

Installation Holder

Filament

1. Insert the holder into the mounting hole then turn it to

the right to lock it.

2. Put the ﬁlament on the holder.

Start/Pause：

First Click ：Start to Printing after

heating to 200℃

Second Click：Stop printing

Third Click：Continue Printing

Home：Return to origin

Heat/Cool：

First Click：Heating to 200℃。

Second Click：Stop to heat,

Cooling to room

temperature

Remote Control Button Panel

Load Filament

Filament

Clip

Magnetic Platform

Platform

Place the magnetic platform on the printing

platform, and ﬁx it by clips.

1. Pressing to heat，waiting the tempreature of nozzle to arrive 200℃.

2. Pressing the extrusion clamp, pass the ﬁlament through the extruder and

PTFE tube into the nozzle, untill the ﬁlament overﬂow

*After heating, Press the extrusion clamp, pull out the ﬁlament to remove.

Load Filament

Install Platform

1. Insert the TF card into the TF slot of

the printer

2. Click to wait for the nozzle to

heat up to 200 ° C

3. Model will be printed after 2 minutes

* It only will print the ﬁrst model in

the TF card

Note

In case ofemergency, please turnoﬀthe power ofthe

3D printer directly.

Please use a3D printer in aspacious, level, and well

ventilated environment.

It is recommended that using printer in the temperature

of8℃-40℃and ahumidity of20%- 50%. outside this

range may result in poor printing results.

Do not disassemble the 3D printer without permission.

Ifyou have anyproblems, please contact：

cs@creality3d.cn

Run “User Guide” in the TF card for more usage

information.

One-button Print
