Craftsman 695.65857 User manual

i,CRF FTSM, ,°J

QUICK CLAMPING WORK TABLE I J

BANCO DE TRABAJO DE FIJACION RAPIDA

Model No:

695.65857

Modeio N-°

695.65857

CAUTION:

Before using this

product, read this

manual and follow

all its Safety Rules

and Operating

Instructions.

• Safety

Instructions

• Assembly

• Operation

• Repair Parts

• Espa_ol

PRECAUCI6N:

Antes de usar este

producto, lea este

manual y siga todas

las instrucciones de

seguridad y de

manejo.

• instrucciones de

seguridad

•Montaje

• Manejo

• Repuestos

• Espa_ol

Sears, Roebuck and Co., Hoffman Estates, IL 60179 USA

WARRANTY.............................................................2

SAFETYINSTRUCTIONS.......................................2

PACKAGECONTENTS...........................................3

ASSEMBLY..............................................................4

HOWTO..................................................................5

SPECIFICATIONS...................................................6

REPAIRPARTS.......................................................6

ESPAI_OL................................................................7

Full One Year Warranty

If this CRAFTSMAN _' Workbench fails to give

complete satisfaction within one year from the

date of purchase, return it to (or contact) the

nearest Sears Service Center in the United

States, and Sears will repair it, free of charge.

This warranty gives you specific legal rights and you

may also have other rights which vary from state to

state.

Sears, Roebuck and Co.,

Dt817WA, Hoffman Estates, IL 60179

DO NOT attempt to assemble or operate your

CRAFTSMAN ®Workbench until you have read the

safety instructions in this section.

Safety items throughout this manual are labeled

with WARNING or CAUTION.

WARNING: Means that failure to follow this safety

statement may result in extensive product damage,

serious personal injury or death.

CAUTION: Means that failure to follow this safety

statement may result in minor or moderate personal

injury, property or equipment damage.

WARNING: DO NOT use this tool for scaffolding or

as a ladder. Make sure to insert pin and fully tighten

handles when in use. Maximum capacity 250 Ibs.

WARNING: Read all instructions.

DO NOT attempt to use your portable workbench

unless the jaw is securely locked in position.

DO NOT load tool stand with more than 250

pounds.

DO NOT apply an unbalanced load which could

result in the workbench tipping over.

DO NOT stand or climb on the workbench. It could

fall or tip over causing serious injury,

Be sure the workbench's leg set frame assembly

is in the fully opened position before using.

When operating a stationary power tool, such as a

miter saw, on your workbench, be sure the tool is

securely bolted to a separate piece of plywood

and the plywood is securely clamped to the

portable workbench. DO NOT clamp or mount

stationary power tools directly to table top. This

could cause serious bodily injury.

When operating a portable power tool such as a

drill, router, sander or planer: Always be sure that

the workpiece is securely clamped to your

workbench. This will avoid kickback which could

cause serious bodily injury.

When using a power tool with the workbench,

ALWAYS follow the safety instructions in the power

tool owner's manual.

ALWAYS wear safety glasses or eye shields when

operating power tools.

To prevent personal injury while opening or closing

your workbench, always avoid positioning hands

or fingers where they could get pinched.

Dress for safety. DO NOT wear loose clothing,

gloves, neckties or jewelry (rings, watches); they

can get caught and draw you into moving parts.

ALWAYS wear non-slip footwear; tie back long hair.

CAUTION: DO NOT store workbench

outdoors or in a damp location.

ALWAYS keep your work area clean, uncluttered

and well lit. DO NOT work on or place workbench

legs on floor surfaces that are slipper/from

sawdust, oil, water or wax.

Keep visitors and children a safe distance away

from the work area, especially when you're

operating a power tool. Visitors should wear the

same safety equipment as the operator.

*SAVE THESE INSTRUCTIONS.

Your CRAFTSMAN _ Workbench is shipped complete

in one carton,

Separate all parts from packing materials and check

each item with Figure 1 and "Table of Loose Parts".

Make sure all items are accounted for before

discarding any of the packing material.

ITEM DESCRIPTION TABLE OF LOOSE PARTS

QTY. ITEM DESCRIPTION QTY.

Leg assembly -left ............................ 1

Leg assembly - right .......................... 1

Foot step ............................................. 1

Screw- M6 x 40 ................................. 8

Washer- medium .... _.......................... 8

Nut - M6 ............................................ 10

Too[ storage rack ................................ 1

Screw- M6 x 12 ................................. 2

Washer - small ................................... 4

Cross bar ..................... 1

Foot pad ...................... 4

Support - table top .............. 4

Table top - front ................ 1

Screws - M8 x 55 ............... 4

Washer- large .......... ,....... 6

Table top - rear ................ t

Nut- M8 .................. ...2

Swivel peg .................... 4

Peg Support ................... 2

Assembling the Workbench

'Note: For correct assembly, the legs, [A] and [B],

must have hinges on the outside.

Refer to Figure 2 for steps 1 - 4

,Attach the foot step [C] to the leg assemblies [A &

B] with two screws, [D] (Me x 40), medium

washers [El and nuts IF] (Me) on each side.

Tighten securely.

.Attach the tool storage rack [G] to the leg

assemblies [A & B] with a screw [H] (Me x 12),

two small washers [t], and nut [F] (Me) on each

side. Tighten securely.

,Attach the rear cross bar [J] to the leg

assemblies. Use two screws [D] (Me x 40),

medium washers [E], and nuts [F'J (Me) on each

side. Tighten securely.

4. Install foot pads [K] onto ends of each leg.

Refer to Figure 3 for steps 5 - 8

5. Place the two top supports [L] on the front and top

Figure 2

of the leg assemblies [A & B] with the support's

round extrusions facing up and away from the front

of the table. The bottom round extrusion holes fit

over the threaded extrusions of each screw arm

assembly.

.Place the front table top [M] on the supports [L],

aligning the table top holes over the round

support moldings and press into place. Attach top

using two screws [N] (Me x 55) and two large

washers [O]. Tighten securely.

,Place two table top supports [L] on rear and top

of the leg assemblies [A & B] with the support's

round extrusions facing up and toward the front of

the table. The supports fit into the rectangular

cut-outs in the leg assemblies.

.Place the rear table top [P] on the supports ILl,

aligning the table top holes over the support

extrusions and press into place. Attach top using

two screws [N] (Me x 55) and two large washers

[O] on table top and two large washers [O] and

two nuts [Q] (Me) on table bottom. Tighten

securely.

Figure 3 P

Folding Your Workbench

1._Remove any hand tools or parts from table top and

storage rack.

2_ Carefully pull up on hinges, with fingers under

hinge flange, to unlock hinges.

3. qqtt Stand back slightly onto rear legs. (See Figure

4.)

4. Reach down and push front legs backward.

Figure 4

Figure 5

Opening the Workbench

1. Standing at rear of workbench, grasp front edge of

table top and underside of rear cross brace.

2, Pull rear cross brace towards you while

simultaneously pulling up on table top.

3. When fully open, secure in locked position by

pushing on hinges until completely down.

To Adjust Table Top Jaw

Turn the front table top jaw adjustment handles

counterclockwise to move front jaw toward you. Turn

adjustment handles clockwise to move front jaw

away. (See Figure 5.) The table top jaws open to

clamp amaximum 7-inch wide workpiece.

Adjusting Jaw to Angle

Workbench jaw adjusts to a maximum angle of 14

degree s for clamping irregular shaped workpieces.

To adjust jaw to angle, turn either the right or left

djustment handle until desired angle is reached.

Using Adjustable Swivel Pegs - Figure 6

"/our workbench is equipped with 4 swivel pegs. The

swivel pegs can be positioned intoany of the holes in

the front and rear oftop for gripping irregularshaped

workpieces, or to extend gripping and clamping when

the workpiece exceeds the jaw capacity.

CAUTION: Swivel pegs are to be used to grip

workpiece only in cases where the workpiece DOES

NOT extend beyond the surface of the jaw.

Figure 6

Work Table Area: 30" x 13-1/4".

Maximum Weight Support: 250 pounds.

Working.Heights: 31-!/2"

695.65857 Workbench

1" BB

x--_

NO.

PART NO.

119800362

119800363

116600047

116600048

116620265

117010212

117020161

117020172

117020176

117010213

117010214

117010215

1170102T6

117010217

117010218

117220185

116710002

116710029

116710118

DESCRIPTION QTY,

Table Top - Front......................... 1

Table Top -Rear .......................... 1

Handle ......................................... 2U

Handle Grip ................................. 2 V

Threaded Piece ........................... 2

Rail .............................................. 2 W

Tool Rack .................................... 1 X

Foot Step ..................................... 1 Y

Cross Bar .................................... 1 Z

L Bracket - Hinge - Rear ............. 2

L Bracket - Hinge - Front ............ 2 AA

LBracket - Left............................ 1 BB

L Bracket - Right ......................... 1 CC

LL - Right ....................................2 DD

Leg ..............................................4

Spindle Threaded ........................ 2 EE

Rivet ............................................2 FF

Screw Handle to Spindle

(M3.gx13) ....................................2 GG

Screw Grip to Handle HH

(M4.2x9.5) ...................................2II

KEY

NO. PART NO,

T 116700081

116750142

116710020

116700026

116630201

116610118

116750142

116720040

117710091

116700021

116700023

116720112

116720077

116600014

1!6610rt,2-"

116610723

DESCRIPTION QTY,

Screw - Legs and L Brackets

(M6x45) ....................................... 6

Screw -L Brackets (M6x40) .......4

Lock Nut -Legs and L

Brackets..; ................................. 10

Washer - L Brackets .................. 4

Foot Pad...................................... 4 ,I

Connector Table Top Supports...4

Screw for Foot Step and

Cross Brace (M6x40) .................. 8

Screw -Tool Rack (M6x12) ........ 2

Screw - Table Top (M8x55) ......... 4

Nut - Table Top - Rear (MS)....... :2

Nut - Tool Rack, Foot Step

and Cross Bar (M6) .................. 10

Washer - TableTops ................... 6

Washer - Foot Step and

Cross Bar ....................................8

Washer -ToolRack ....................4 =_

SwivelPeg ..................................4

Peg Support................................2

PART SET

_119900868

119900871

119900868

Table of contents

Other Craftsman Tools Storage manuals

Craftsman

Craftsman PREMIUM SERIES User manual

Craftsman

Craftsman PROFESSIONAL SERIES Instruction Manual

Craftsman

Craftsman PROFESSIONAL SERIES User manual

Craftsman

Craftsman GARAGE STORAGE SOLUTIONS User manual

Craftsman

Craftsman Professional Series Chests and Roller... User manual

Craftsman

Craftsman 31018 User manual

Craftsman

Craftsman 31016 User manual

Craftsman

Craftsman 706.599300 Guide

Craftsman

Craftsman Side Cabinet with SS Protect-it User manual

Craftsman

Craftsman HEAVY DUTY TOOL CHESTS User manual

Craftsman

Craftsman 706.139920 User manual

Craftsman

Craftsman 76633 Butcher Block User manual

Craftsman

Craftsman Accessory User manual

Craftsman

Craftsman 120.29685 User manual

Craftsman

Craftsman Workbench User manual

Craftsman

Craftsman 31011 User manual

Craftsman

Craftsman Homeowner's Series User manual

Craftsman

Craftsman 706.657840 User manual

Craftsman

Craftsman 76637 User manual

Craftsman

Craftsman 28180 - Fixed-Base Router/Table Combo User manual

Craftsman

Craftsman 706.591870 User manual

Craftsman

Craftsman HEAVY DUTY TOOL CHESTS User manual

Craftsman

Craftsman Workbench User manual

Craftsman

Craftsman Workbench User manual

Popular Tools Storage manuals by other brands

Ryobi

Ryobi RWB03 Original instructions

Husky

Husky H27CH5TR4BGK Use and care guide

Scheppach

Scheppach ts 2100 Translation from original manual

Cornwell Tools

Cornwell Tools CTB360AKBK Assembly instructions

DIVERSIFIED WOODCRAFTS

DIVERSIFIED WOODCRAFTS SHAIN GSB-6024 Assembly instruction

Cassese

Cassese CS200 CART user & parts manual

Kendall Howard

Kendall Howard ESDW-9630-1000 owner's manual

Lista

Lista Align Instructions for assembly

Workzone

Workzone 99609 Assembly instructions

Stanley

Stanley STST83800-1 instruction manual

Homak

Homak PROFESSIONAL Series Owner's manual & operating instructions

Perel

Perel ROLLER SHUTTER STORAGE CABINET Assembly instructions

Husky

Husky H5CH2R Use and care guide

BGS technic

BGS technic 4107 manual

Clarke

Clarke CWB1250 Instruction

Ryobi

Ryobi RWB02 Original instructions

Husky

Husky H52CH6HDV3WHT Use and care guide

Sealey

Sealey PTB66004 instructions
