Craftsman CMXGBAM1054540 Guide

A. Loosely attach the wing knob

and rope guide (opening facing the

rear) to the upper handle.

B. Pull the starter rope handle and route

the starter rope through the rope

guide.Tighten the wing knob.

Remove the screws from the chute base.

Position the chute assembly on the chute

base and secure with the screws just removed.

778-15058

A. Remove the wing knobs and carriage bolts

from the upper portion of the lower handle.

B. Pivot the upper handle upward.

C. Reattach the wing knobs to secure

the handle.

Place the chute handle on the lower chute

aligned in the channel and snapped into place

Channel

Tab

Lower Handle

Upper Handle

Chute Assembly

Starter Rope Handle

Wing Knobs

READ AND UNDERSTAND ALL INSTRUCTION, WARNING, AND DANGER LABELS.

PARA INSTRUCCIONES EN ESPAÑOL, REFIÉRASE AL MANUAL DEL OPERADOR.

IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY

AND FOLLOW THE IMPORTANT SAFE OPERATION PRACTICES BEFORE OPERATING.

Need Help?

www.CRAFTSMAN.com or Call 1-888-331-4569

Fast Start Guide - Assembly

778-15058

A. Connect an extension cord

to the electric starter outlet.

B. Plug the other end of the

extension cord into a three-

prong 120-volt, grounded,

AC receptacle.

Push primer

three times.

Fill fuel tank with clean,

fresh gasoline. Do not fill

above the base of fuel

tank neck.

Pour the entire contents

of the oil bottle

(included in carton) into

the oil fill.

B. When engine starts,

slowly move choke

control into the Run

position.

C. Disconnect cord from

power receptacle first

and then from snow

thrower’s outlet.

A. To start engine,

push down

on starter button.

Insert the key into the key switch until the key

snaps into place. Do not turn the key!

Move the choke control

into the Choke position.

Electric Starter Outlet

Key

Choke Control

Electric Starter

Button

Primer

Oil Fill

Fuel Fill

READ AND UNDERSTAND ALL INSTRUCTION, WARNING, AND DANGER LABELS.

PARA INSTRUCCIONES EN ESPAÑOL, REFIÉRASE AL MANUAL DEL OPERADOR.

IMPORTANT: READ OPERATOR'S MANUAL AND ENGINE MANUAL THOROUGHLY

AND FOLLOW THE IMPORTANT SAFE OPERATION PRACTICES BEFORE OPERATING.

Need Help?

www.CRAFTSMAN.com or Call 1-888-331-4569

Fast Start Guide - Engine Start
