Cornelius IDC Pro Programming manual

Cornelius IDC PRO

Cleaning Instructions

& Trouble Shooting

NOZZLES AND DIFFUSERS - DAILY CLEANING

Remove the nozzles from the dispenser by turning each

nozzle to the left and pulling down.

Remove the inner diffusers by pulling down; separate the

clear gasket from the diffuser.

Note orientation of gasket for reinstallation (shown on

page 4)

NOZZLES AND DIFFUSERS - DAILY CLEANING

Clean the diffusers, nozzles and gaskets thoroughly

with the nylon bristle brush and soapy water. Rinse

them with water.

Put the nozzles, gaskets and the diffusers in

sanitizer solution for one minute. Don’t over soak

or they will dry out.

Remove the nozzles, gaskets and diffusers from the

solution and allow them to air dry.

NOZZLES AND DIFFUSERS –DAILY CLEANING

Install the gasket into the diffuser. Line

up the two notches on the inner circle

of both the gasket and diffuser.

Push the silicone gasket into the

diffuser.

Make sure that the raised side of the

clear gasket is face-up when re-

inserting the diffuser.

Note: If the clear gasket is upside

down, the notches will not line up

right.

NOZZLES AND DIFFUSERS - DAILY CLEANING

Brush the diffuser area under the machine

thoroughly with a nylon bristled brush.

Wipe under side of valves with sanitizer

cloth.

Allow to air dry.

NOZZLES AND DIFFUSERS –DAILY CLEANING

Re-install the inner Diffuser and Gasket into nozzle

base by rotating slightly while pushing up.

Re-install outer nozzle and twist to lock in place

NOTE: Ensure the outer nozzle is on STRAIGHT when

locking.

Make sure nozzle locks. Purge valve to remove any

remnant sanitizer by running a water cycle for 10-15

seconds.

CLEANING ICE CHUTE

Clean the interior of the ice chute using the

brush provided with the unit.

Use warm soapy water, rinse with clear (not

soapy), water using brush, then do a final rinse

using the brush with sanitizer water.

Let air dry.

CLEANING THE SCREEN, MACHINE &

DRAIN

Clean the screen using a sanitized towel, then

wipe face with dry towel. Refer to page 11 on

how to lock screen during cleaning.

Clean the remainder of the machine using a

sanitized towel. Clean drip tray grate in sink.

Clean the drain WEEKLY using a bucket filled

with 1-2 gallons of warm water and a capful

of bleach.

ACCESSING THE MENU’S

Display the keypad screen by tapping

each corner of the video screen

starting in the upper right corner and

continuing to tap each corner in a

counter clockwise direction, in the

form of a “C”.

This will display the Key pad screen.

Once each corner is tapped, type in the

password “1111” then press Enter to access the

Operator menu.

SCREEN CLEANING LOCKOUT

The screen cleaning lockout screen allows you to clean the digital merchandiser

without dispensing product.

Touch inside the circle to activate the 20 second lockout.

Select Screen Cleaning Lockout Screen Cleaning 20sec Lockout Screen
