Cooper & Hunter CH-HP07MNK Operating instructions

Thank you for choosing Cooper&Hunter air-to-water heat pump, please read this installation & owner`s

manual carefully before operation and retain it for future reference.

Installation & Owner`s manual

Air-to-water heat pump

AIR-TO-WATER HEAT PUMP

Models:

CH-HP07MNK

CONTENT

1. Preface . .......................................................................

2. Safety Precautions ...................................................

2.1 Mark notes . ............................................................

2.2 Icon notes ...............................................................

2.3 Warning . .................................................................

2.4 Attention . ................................................................

3. Overall information of the heat pump . .................

3.1 Device description . ...............................................

3.2 Features of the air heat pump . .......................

3.3 Heat pump dimension and view ...........................

3.4 Specification data ...................................................

4. Installation . ................................................................

4.1 Installation Schematic . .........................................

4.2 Transit .....................................................................

4.3 Installation occasions . .........................................

4.4 Water loop connection . .........................................

4.5 Installation space ...................................................

4.6 Water tank selection . ..............................................

4.7 Power supply connection . ....................................

4.8 Cable and switch . ....................................................

4.9 Trial running . ..........................................................

5.Controlling and Operation . ....................................

5.1 Function of wire controller . ...................................

5.2 Usage of wire controller ........................................

5.3

. ...................................

6.Troubleshooting and extra information ...............

6.1Parameter list and breakdown table . .................

7. The main controller terminals . ..............................

7.1 Wire control interface diagram and definition . ....

7.2 Controller interface diagram and definition . ..........

7.3 T .............................................

8. Appendix .....................................................................

8.1 Caution & Warning . ................................................

8.2 Cable specification . ...............................................

Color Display Calibration

he extended module

Preface

Positioning, installation and

commissioning must be

carried out by trained

personnel working in

accordance with these

operating and installation

instructions.

Where children or persons with limited

physical, sensory or mental capabilities

are to be allowed to control this equip-

ment ensure that this will only happen

under supervision or after appropriate

instructions by a person responsible for

their safety. Children should be super-

vised to ensure that they do not play with

the equipment.

Carefully read these operating and

installation instructions and keep them

safe. Should the equipment change

hands, pass these instructions to the

subsequent owner. Pass them to the

trained contractors for servicing

purposes.

Protection

Qualified only

The pictures and drawings in

this manual is for your infor-

mation only.

The manufacture has the

right to chance or improve

the product when it is needed,

without prior notification to the

users of this device.

For information

Necessary reading

When the product is delivered to the users, please check whether there is

any damage on the unit during transportation; If there is any please talk

with the forwarder or the contractor.

If the heat pump unit just can be installed a while latter, please keep it free

from damage, rust or abrasion by following methods.

1, all the access like the water connections must be sealed correctly;

2, the unit must be free from sunshine, and placed under 45℃;

3, the unit must be free from heavy dust to avoid dirty on the evaporator;

4, the unit must be placed free from chaos to avoid accident.

5, please check the unit during stock

Quality check at first receipt of this product

Welcome to air source water heat pump. Your decision to purchase heat

pump will reward you for many years.

This is your assurance that you have purchased quality heat pump system

available,one that is manufactured in a state-of-the-art facility and go with

innovation.

Mark Notes

Mark Meaning

A wrong operation may lead to death or heavy injury on people.

A wrong operation may lead to harm on people or loss of material.

WARNING

ATTENTION

Icon Notes

Icon Meaning

Prohibition. What is prohibited will be nearby this icon

Compulsory implement. The listed action need to be taken.

ATTENTION (include WARNING)

Please pay attention to what is indicated.

To prevent the users and others from the harm of this unit, and avoid damage on the unit or other

property, and use the heat pump properly, please read this manual carefully and understand the following

information correctly.

The piping connection and wiring should be installed according to the local legal laws and regulations as

well as the profession standard.

Safety Precautions

安装前注意事项

The heat pump must be installed by qualified personals,

to avoid improper installation which can lead to water

leakage, electrical shock or fire.

Please make sure that the unit and power connection

have good earthing, otherwise may cause electrical shock.

Installation

Professional installer

is required.

Earthing is required

Warning

Meaning

Operation Meaning

PROHIBITION

Shut off the power

DO NOT put fingers or others into the fans and evaporator

of the unit, otherwise harm may be occurred.

When there is something wrong or strange smell, the power

supply need to be shut off to stop the unit. Continue to run

may cause electrical short or fire.

Move and repair

Entrust

Prohibit

Entrust

When the heat pump need to be moved or installed again,

please entrust dealer or qualified person to carry it out.

Improper installation will lead to water leakage, electrical

shock, injury or fire.

It is prohibited to repair the unit by the user himself, otherwise

electrical shock or fire may be occur.

When the heat pump need to be repaired, please entrust

dealer or qualified person to carry it out. Improper movement

or repair on the unit will lead to water leakage, electrical

shock, injury or fire.

Meaning

Safety Precautions

Meaning

Switch off

the power

Prohibition

Please switch off the power for clean or maintenance.

It is prohibited to use copper or iron as fuse. The right fuse

must be fixed by electrician for the heat pump.

It is prohibited to spray the flammable gas to the heat pump,

as it may cause fire.

Installation

Operation

Prohibition

安装前注意事项

Attention

Check the

installation basement

Please check the installation basement in a period (one month),

to avoid any decline or damage on the basement, which may

hurt people or damage the unit

Fix the unit

Installation Place

Need

circuit breaker

The unit CANNOT be installed near the flammable gas.

Once there is any leakage of the gas, fire can be occur.

Make sure that the basement of the heat pump is strong

enough, to avoid any decline or fall down of the unit

Make sure that there is circuit breaker for the unit, lack of

circuit breaker can lead to electrical shock or fire.

Safety Precautions

Overall information of the heat pump

The air source heat pump extracts heat from ambient air and transfer it to water. By

circulating the water, the energy is used to warm the house efficiently. Through the usage of

floor heating, the heat pump COP can be as high as 4.5

Compared with oil boiler, gas boiler and electrical heater, heat pump is the best solution with

high efficiency, safety and environment protect.

This air source heat pump use advanced heating tech-nology and intelligent control system,

to produce hot water at more than 55℃. So it can work with the floor heating pipe, the fan coil

or the radiator,and replace the boiler directly.

3.2.Features of the AIR HEAT PUMP

1, Save our planet---earth, by green technology

Heat pump transfer heat from air to the space for heating, so that there is no burning,

no waste, no dirty gas, thus maintain good environment for human and save earth from waste.

2, Serve people by high efficiency and money saving

The heat pump is driven by electricity, and annually average efficiency can be higher than 4.

By timer function, users can make use of the electric power at the low point of a day, thus save

money for every family.

3, Good for life with safe running

To use heat pump for heating can avoid electrical shot and burning, thus keep people free from

explosion or poisoning.

4, Easy operation

Heat pump is controlled and protected by micro-computor based contro-ller, the desired water

temperature is set according to real requirement.System protection program will guarantee the

unit to be running at hard environment.

In reverse, cooling is also available when it is needed.

3.1.Device description

In addition, the air heat pump can be used to provide hot water for sanitary use, like kitchen,

shower, etc.

Overall information of the heat pump

3.3.Heat pump dimension and view

Unit Model：CH-HP07MNK

4-φ14

382

445

630

1048

605

Wire controller

High pressure gage

Water outlet

DN25

water inlet

DN25

335

122

Overall information of the heat pump

3.4.Specification data

kcal/h

RPM

dB(A)

inch

m/h

kPa

(Subject to drawings of the heat pump)

(Subject to data on the package)

(Subject to data on the nameplate)

(Subject to data on the package)

CH-HP07MNK

9.5

8168

6.3

5589

7.4

6363

5.9

5073

2.5

2.1

1.8

2.3

230V～/50Hz

Rotary

830

1.55

10.3/9.2/8.1/10.2

Model

Packing Size (L/W/H)

Net Weight

Gross Weight

*Heating Capacity

Water Pressure Drop

Unit Dimension (L/W/H)

**Heating Capacity

***Heating Capacity

Cooling Capacity

*Power Input for Heating

Power Input for Cooling

Power Supply

Compressor Quantity

Compressor Type

Fan Quantity

Fan Power Input

Fan Rotate Speed

Noise

Water Connection

Water Flow Rate

**Power Input for Heating

***Power Input for Heating

Running Current

(*Heating/**Heating/***Heating/C )ooling

o o o o

1.*Hot Water：outdoor temperature DB/WB20 C/15 C ，outlet water circulation from 15 C to 55 C ;

o o o o

2.**Heating：outdoor temperature DB/WB7 C/6 C ，outlet water 55 C，inlet water (return) 50 C;

o o o o

3.***Heating：outdoor temperature DB/WB7 C/6 C ，outlet water 35 C，inlet water (return) 30 C;

o o o o

4.Cooling：outdoor temperature DB/WB35 C/24 C ，outlet water 7 C，inlet water (return)12 C .

Overall information of the heat pump

Heating Perfomance curve

Other Cooper & Hunter Heat Pump manuals

Cooper & Hunter

Cooper & Hunter Supreme CH-S09FTXAM2S User manual

Cooper & Hunter

Cooper & Hunter GEN12AA-D3DNA1C/I User manual

Cooper & Hunter

Cooper & Hunter CH-HP08UIMPRM User manual

Cooper & Hunter

Cooper & Hunter CH-S09FTXTB-W User manual

Cooper & Hunter

Cooper & Hunter GRS-C3.8/NbA-K User manual

Cooper & Hunter

Cooper & Hunter GRS-Cm18/A-M User manual

Cooper & Hunter

Cooper & Hunter CH-HP30MFNM User manual

Cooper & Hunter

Cooper & Hunter GRS-C3.5/A1-K User manual

Cooper & Hunter

Cooper & Hunter GEN12AA-D3DNA1C/I User manual

Cooper & Hunter

Cooper & Hunter UNITHERM3 R32 User manual

Cooper & Hunter

Cooper & Hunter CH-HP08UIMPRK User manual

Cooper & Hunter

Cooper & Hunter CH-06MCT1W-230VI Repair manual

Cooper & Hunter

Cooper & Hunter Supreme CH-S18FTXAM2S User manual

Cooper & Hunter

Cooper & Hunter CH-HP07UMPNK Operating instructions

Popular Heat Pump manuals by other brands

MICROWELL

MICROWELL HP 1000 GREEN Installation and user manual

Sanyo

Sanyo SAP120FCH Service manual

Daikin

Daikin EHYHBH05AA Operation manual

Panasonic

Panasonic WH-SDF03E3E5 Design handbook

Bryant

Bryant 544B Specifications

Airxcel

Airxcel 45000 Series Installation, operation and maintenance instructions

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Service manual

Dimplex

Dimplex LI 16I-TUR Installation and operating instruction

Carrier

Carrier WSHP Open v3 Integration guide

TGM

TGM CTV14CN018A Technical manual

Carrier

Carrier 38MGQ Series installation instructions

Kokido

Kokido K2O K880BX/EU Owner's manual & installation guide

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Installation and service instructions

Carrier

Carrier 48EZN installation instructions

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Installation and service instructions for contractors

Ariston

Ariston NIMBUS user manual

Weishaupt

Weishaupt WWP L 7 Installation and operating instruction

GE Zoneline AZ85H09EAC datasheet
