Consilium CFD5000 FDS User manual
Fire Detection System - CFD5000 T / CM2.2
User Manual
Consilium Marine & Safety AB
Fire & Gas Marine Division
+46 31 710 77 00
For service or spares contact your local Consilium office. Contact
information can be found at:
www.consiliumsafety.com
The contents of this document are subject to revision without notice
due to continued progress in methodology, design and manufacturing.
Consilium assumes no legal responsibility for any error or damage
resulting from the usage of this document.
June 2023
File name 5100606_CFD5000 T - CM2.2_User Manual_T_EN_2023_E
Document no. 5100606
© Copyright 2023, Consilium Marine & Safety AB
Table of contents
1 Introduction....................................................................................... 1
1.1 About this manual............................................................................. 1
1.2 References ......................................................................................... 1
1.3 Symbols used in the manual ............................................................. 1
1.4 Standards and certifications ............................................................. 2
2 Safety considerations ........................................................................ 3
2.1 If a fire or fault alarm is flashing on the control panel .................. 3
2.1.1 In case of a fire alarm..................................................................... 3
2.1.2 In case of a fault alarm................................................................... 3
2.1.3 Further instructions ........................................................................ 3
2.2 Precautionary measures ................................................................... 4
3 Fire Detection System ....................................................................... 5
3.1 System Description............................................................................ 5
3.1.1 Introduction.................................................................................... 5
3.1.2 Systems and Interfaces................................................................... 5
3.1.2.1 CCP Fire ....................................................................... 5
3.1.2.2 CFD5000 FDS - an extension of CCP Fire................... 6
3.1.2.3 CFD5000 FDS Subsystem ............................................ 7
3.1.3 CFD5000 Modules......................................................................... 9
3.1.4 Modules Overview......................................................................... 10
4 Quick Guide for Control Panel M 2.2.............................................. 11
5 User Instructions for Control Panel M 2.2 ...................................... 13
5.1 Control Panel M 2.2.......................................................................... 13
5.1.1 Description of Keys and Indicators................................................ 13
5.1.2 Guide to the Menu System............................................................. 15
5.1.2.1 Navigating the Menus................................................... 15
5.1.2.2 Menu Alternatives......................................................... 16
5.2 Access Levels ..................................................................................... 21
5.3 Setting Time and Date....................................................................... 22
5.4 Fire Alarm......................................................................................... 23
5.4.1 Information Displayed when “Fire” is Flashing ............................ 23
5.4.2 Reset a Fire Alarm ......................................................................... 23
5.4.3 Reset All Fire Alarms .................................................................... 23
Table of contents
5.5 Fault Alarm....................................................................................... 24
5.5.1 Information Displayed when “Fault” is Flashing .......................... 24
5.5.2 Reset a Fault................................................................................... 25
5.5.3 Reset a Fault from the Fault List.................................................... 25
5.5.4 Reset All Faults.............................................................................. 25
5.5.5 Warnings ........................................................................................ 25
5.6 Disablements ..................................................................................... 26
5.6.1 About Disablements....................................................................... 26
5.6.2 Available Disablements ................................................................. 26
5.6.3 Acknowledgement of a New Disablement .................................... 26
5.6.4 Disabling Zones ............................................................................. 27
5.6.5 Disabling Addressable Detectors & Manual Call Points............... 27
5.7 Reconnecting..................................................................................... 27
5.7.1 Reconnecting Disabled Items ........................................................ 27
5.7.2 Remove All Disablements ............................................................. 28
5.8 Service Menu..................................................................................... 28
5.8.1 About the Service Menu ................................................................ 28
5.8.2 Save the System Log to a USB Memory Stick .............................. 28
5.8.3 Save the BIST Log to a USB Memory Stick ................................. 29
5.8.4 How to report a fault ...................................................................... 29
6 User instructions for Repeater M 4.3 ............................................... 31
6.1 General .............................................................................................. 31
6.2 Description of keys and indicators ................................................... 31
7 Fault codes ........................................................................................ 33
7.1 Fault codes for CFD5000 ................................................................. 33
8 Appendix A ........................................................................................ 47
8.1 Definitions and abbreviations........................................................... 48
9 Appendix B ........................................................................................ 55
9.1 System description............................................................................. 55
10 Appendix C ........................................................................................ 57
10.1 The Consist ID .................................................................................. 57
11 Appendix D........................................................................................ 61
Table of contents
User Manual 1Introduction
5100606_CFD5000 T - CM2.2_User Manual_T_EN_2023_E 1
1 Introduction
1.1 About this manual
This manual is intended for trained personnel using the CFD5000T fire detection
system and provides basic understanding how to operate the system.
NOTE!
This manual is valid for SW-version 2.2.10
Chapters User Instructions for Control Panel M 2.2, and describes how to operate
the fire detection system in case of a fire or fault alarm. Login and explanation for
all menu alternatives can be found here.
For brief instructions, see the Quick Guide for Control Panel M 2.2, page 11 and .
Lists of fault codes generated by loop units and system modules can be found in
chapter Fault codes.
For testing, please refer to the the Installation & Commissioning manual, 5100601.
1.2 References
The following technical product manuals are available for the CFD5000T fire
detection system:
5100606 CFD5000 T / CM2.2 User Manual
5100607 CFD5000 T / CM2.2 Installation & Commissioning Manual
5100608 CFD5000 T / CM2.2 Service & Maintenance Manual
5100609 CFD5000 T / CM2.2 Quick Guide
5100610 CFD5000 T / Application & Programming Manual
6302935 CFD5000 Safety Manual
6303933 CCP SIL - Safety Measures Checklist
1.3 Symbols used in the manual
DANGER!
Risk of serious or fatal injury to the user, and/or severe damage to the product, if the
instructions are not followed.
WARNING!
Risk of personal injury and/or damage to the product if the instructions are not
followed.
CAUTION!
Risk of minor or moderate personal injury. Risk of equipment damage, loss of data,
extra work, or unexpected results, if the instructions are not followed.
1Introduction User Manual
25100606_CFD5000 T - CM2.2_User Manual_T_EN_2023_E
NOTE!
Note symbols alert you to important facts and conditions.
Hint!
Hint symbols direct you to specific instructions, such as where to find additional
information and tell you how to perform a certain operation in an easier way.
1.4 Standards and certifications
The Fire Detection System CFD5000 T is designed to comply
with the standards for the industrial, maritime, offshore and
rolling stock markets up to Safety Integrity Level 2 (SIL 2).
The Fire Detection System CFD5000 T complies with many
more standards, directives etc. which can vary depending on
the final application. Please contact one of our sales
representatives for more information.
The Fire Detection System CFD5000 is designed to comply
with the standards for the industrial, maritime, offshore and
rolling stock markets up to Safety Integrity Level 2 (SIL 2).
User Manual 2Safety considerations
5100606_CFD5000 T - CM2.2_User Manual_T_EN_2023_E 3
2 Safety considerations
2.1 If a fire or fault alarm is flashing on the
control panel
2.1.1 In case of a fire alarm
DANGER!
In case of a fire alarm use the information viewed on the display to verify the alarm
and take the appropriate actions based on local safety procedures.
2.1.2 In case of a fault alarm
WARNING!
In case of a fault alarm use the information viewed on the display to verify and reset
the fault.
Use the list of fault codes in the manual for more information about cause and
remedy.
If the problem remains take the appropriate actions to restore the functionality of the
fire detection system.
WARNING!
If an internal hardware or software fault has occurred it has to be restored as
promptly as possible in order to secure the functionality of the complete fire
detection system.
The detection of a dangerous fault shall result in either:
•a specified action to achieve or maintain a safe state; or
•the repair of the faulty system within the mean repair time (MRT). During this
time the continuing safety shall be ensured by additional measures and
constraints. The safety integrity provided by these measures and constraints
shall be at least equal to the safety integrity provided by the fire detection
system in the absence of any faults.
2.1.3 Further instructions
•For comprehensive test procedures refer to the Installation & Commissioning
manual.
•For troubleshooting please refer to the Service & Maintenance manual.
2Safety considerations User Manual
45100606_CFD5000 T - CM2.2_User Manual_T_EN_2023_E
2.2 Precautionary measures
CAUTION!
The fire detection system contains devices sensitive to electrostatic discharge (ESD).
For installation and service work involving central components, always wear an
antistatic wrist strap or ground bracelet to avoid any electrostatic discharge.
Considerations to improve safety
In order to reduce risks and maintain a high safety level of the fire detection
system, consider the following precautionary measures.
•The user shall monitor fault alarms and take appropriate action based on
remedy for the specified fault code.
•The user shall monitor and act on warning messages according to the presented
information about the state of the system. (Warnings are not as serious as faults
and only of informative nature.)
•To secure the functionality of the fire detection system only authorised persons
should be given access to disablement or test mode privileges in the system.
•Check for contaminated detectors. Use the Control panel menu system to study
a list showing in which condition the detectors are.
•Perform visual inspection of all fire detectors as often as needed to find
detectors which has deliberately been covered (vandalised). A covered detector
can’t detect a fire (by means of smoke, heat or flames) and the fire detection
system can't detect if a detector has been covered and report this as a fault.
•If a loop unit is removed it has to be replaced as soon as possible in order to
secure the functionality of the fire detection system. During repair time the
continuing safety shall be ensured by additional measures and constraints (fire
watch, restrict access to the affected area, etc.).
