Concord Camera Eye-Q 5330z User manual

Thank you for purchasing the Concord Eye-Q 5330Z.

Please take the time to read through this Quick Start Guide so you can enjoy all its

features.

This mark on your camera certifies that this camera meets the requirements of the

EU (European Union) concerning interference causing equipment regulations.

CE stands for Conformité Européenne (European Conformity).

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference recieved, including interference that may

cause undesired operation.

This Class B digital apparatus complies with Canadian ICES-003.

Do not remove the ferrite cores from the cables.

FOR HOME OR OFFICE USE

Digital Camera

Concord Eye-Q 5330Z

Tested To Comply

With FCC

Standards

BEFORE YOU BEGIN

Check the packing list before you begin. If some parts are missing, please contact your

camera dealer.

• Concord Eye-Q 5330z (x 1)

• AA-size Alkaline Batteries (x 4)

• Video Cable (x 1)

• Hand Strap (x 1)

• Camera Case (x 1)

• Mini-USB Cable (x 1)

• 32 MB CompactFlash Card (x 1)

• Software and Documentation on CD-ROM:

USB Driver Software for Windows ® 98/ 98 SE /Windows ® ME/ Windows ® 2000 / Windows ® XP

and Mac OS 9.0~10.1.3

Instruction Manual (PDF) Windows ® /Macintosh

Photo Impression, Video Impression

• Documentation (Printed)

Warranty Card (x 1)

NAMES OF PARTS

CAMERA BODY _FRONT VIEW

* Do not touch.

CAMERA BODY _REAR VIEW

INSIDE THE TERMINAL COVER

BOTTOM OF BODY

USB connector

Video-out terminal

DC terminal

Battery-chamber door

Tripod socket

* Refer to the number of recordable remaining frame as a guide.

The number changes depending on the scene or subject you record.

DATA PANEL

The following diagram shows all items displayed to aid the explanation.

Battery-condition indicator

Self-timer indicator

Number display of recordable remaining frame/

No-card indicator

Image-size indicator Flash-mode indicator

BASIC FUNCTIONS

Rotate the function dial to STILL IMAGE mode.

FLASH

Digital zoom :WIDE / TELE

Focusing distance Auto focus (No icon)

Close up

Specified (0.5m,1.0m,2.5m)

Landscape

Press ENTER to change DRIVE mode:

Continuous with AF

Continuous shot

Self-timer

Single shot

In general controlling (MENU), press key to select and press key to confirm the settings.

AUTO FLASH

FILL-FLASH

FLASH CANCEL

AUTOFLASH WITH RED-EYE

REDUCTION

NIGHT MODE

GET READY

11Insert the batteries .

22Insert the CF card .

Be sure that positive and negative battery terminals are oriented as illustrated

on bottom of the back cover.

• Be sure to fold the card-release lever down before closing the card slot door.

• Check the direction if the card is stopped halfway.

Note: We advised to use SanDisk ® or HITACHI ® CF card.

11Insert the smaller loop of the hand strap through the strap

eyelet.

22Insert the other end of the hand strap through the small

loop.

ATTACHING THE HAND STRAP

GETTING STARTED

TAKING PICTURES

11Rotate the function dial to STILL IMAGE mode.

22Slide the power switch to turn on the camera.

HOW TO TAKE A PICTURE

33Press button to turn on the LCD monitor,and determine

the image composition while looking into the LCD monitor

or viewfinder.

44Adjust the image range and size with the four-way key

( / ).

• When the T key is pressed, the image size becomes larger.

• When the W key is pressed, the image range becomes wider.
