PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200 SERIES WELCOME TO THE MAINTENANCE & SERVICE GUIDE (MSG) 1

Welcome to the Maintenance & Service Guide (MSG)

Welcome to the Maintenance and Service Guide (MSG) for Compaq Presario 1200XL Series Portable

Notebooks. This online guide is designed to serve the needs of technicians whose job is to repair

Compaq products.

For copyright and trademark information, refer to the Notice section of this MSG. To locate your

unit’s serial number, to see symbol conventions, or to view technician’s notes, see the Preface. This

MSG is updated periodically online as needed.

For comments or questions about the contents of this MSG, contact Compaq.

To report a technical problem, contact your Regional Support Center or IM Help Center.

For help on navigating in this guide, refer to Using this Guide.

Product

Description

Before You

Begin Specifications

Assignments

Battery & Power

Management Troubleshooting

Removal

Sequence

Parts

Catalog MSG Index

PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200 SERIES WELCOME TO THE MAINTENANCE & SERVICE GUIDE (MSG) 2

Presario 1200 Series

Model XL2, XL201, XL202, XL203, XL204, XL205, XL212, XL220, XL222, XL223,

XL3, XL301, XL302, XL303, XL304, XL305, XL307, XL310, XL311,

XL312, XL314, XL320, XL323, XL325, XL326, XL327, XL330

Using this Guide

To effectively use this guide, refer to the list of bookmarks at the left of the screen. These

bookmarks help you navigate through the document quickly and easily. They are accessible from

anywhere in the Maintenance and Service Guide (MSG).

Viewing a Chapter

Click one of the bookmarks or one of the color-coded bubbles on the Welcome page to view a

chapter of this MSG.

Expanding & Hiding Topics

Click the +to expand or show the contents of a section, or click the –to hide the contents.

Opening another Chapter

Return to the Welcome page by clicking the bookmark, 1200 Series Maintenance and Service

Guide, and then click the bookmark or color-coded bubble for another chapter.

Printing the MSG

For portable copies of this MSG, you can print single pages, multiple pages, or the entire guide. In

the Acrobat Reader, click File, and then Print... for printing options.

PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200 SERIES BEFORE YOU BEGIN 1

Presario 1200 Series

Model XL2, XL201, XL202, XL203, XL204, XL205, XL212, XL220, XL222, XL223,

XL3, XL301, XL302, XL303, XL304, XL305, XL307, XL310, XL311,

XL312, XL314, XL320, XL323, XL325, XL326, XL327, XL330

Before You Begin

Notice

The information in this guide is subject to change without notice.

COMPAQ COMPUTER CORPORATION SHALL NOT BE LIABLE FOR TECHNICAL OR EDITORIAL ERRORS

OR OMISSIONS CONTAINED HEREIN, NOR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES

RESULTING FROM THE FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL.

This guide contains information protected by copyright. No part of this guide may be photocopied or

reproduced in any form without prior written consent from Compaq Computer Corporation.

Compaq, Presario 1200 Series Registered U. S. Patent and Trademark Office.

Microsoft, MS-DOS, and Windows are registered trademarks of Microsoft Corporation.

Windows 98 and Windows 2000 are trademarks of Microsoft

Corporation.

The software described in this guide is furnished under a license agreement or nondisclosure

agreement. The software may be used or copied only in accordance with the terms of the

agreement.

Product names mentioned herein may be trademarks and/or

registered trademarks of their respective companies.

Maintenance and Service Guide

Compaq Presario 1200 Series Notebook Computer

First Edition (July 2000) Compaq Computer Corporation

2 BEFORE YOU BEGIN PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200 SERIES

Presario 1200 Series

Model XL2, XL201, XL202, XL203, XL204, XL205, XL212, XL220, XL222, XL223,

XL3, XL301, XL302, XL303, XL304, XL305, XL307, XL310, XL311,

XL312, XL314, XL320, XL323, XL325, XL326, XL327, XL330

Preface

This Maintenance and Service Guide is a troubleshooting guide that is used as a reference guide

when servicing the Compaq Presario 1200 Series Notebook Computers.

Compaq Computer Corporation reserves the right to make changes to the Compaq Presario 1200

Series Notebooks without notice.

Symbols

The following words and symbols mark special messages throughout this guide.

ÅWARNING: Text set off in this manner indicates that a failure to follow directions

in the warning could result in bodily harm or loss of life.

ÄÄ

CAUTION:

Text set off in this manner indicates that a failure to follow directions

could result in damage to equipment or loss of data.

Important: Text set off in this manner preseats clarifying information or specific

instructions.

Note: Text set off in this manner presents commentary, sidelights, or interesting

points of information.

Technician Notes

ÅWARNING: Only authorized technicians trained by Compaq should repair this

equipment. All troubleshooting and repair procedures are detailed to allow only

subassembly/module level repair. Because of the complexity of the individual

boards and subassemblies, the user should not attempt to make repaires at the

component level or to make modifications to any printed circuit board. Improper

repairs can create a safety hazard. Any indications of component replacement or

printed circuit board modifications may void any warranty.

Serial Number

When requesting information or ordering spare parts, you should provide the Notebook serial

number to Compaq. The serial number location is underneath the Notebook.

PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200 SERIES BEFORE YOU BEGIN 3

Presario 1200 Series

Model XL2, XL201, XL202, XL203, XL204, XL205, XL212, XL220, XL222, XL223,

XL3, XL301, XL302, XL303, XL304, XL305, XL307, XL310, XL311,

XL312, XL314, XL320, XL323, XL325, XL326, XL327, XL330

Locating Additional Information

The following documentation is available to support this product:

•Compaq Presario 1200XL Series Notebook Computer documentation set

•Introducing Windows 98 Guide

•Introducing Windows 2000 Guide

•Service Training Guides

•Compaq Service Advisories and Bulletins

•Compaq QuickFind

•Compaq Service Quick Reference Guide

PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200 SERIES PRODUCT DESCRIPTION 1

Presario 1200 Series

Model XL2, XL201, XL202, XL203, XL204, XL205, XL212, XL220, XL222, XL223,

XL3, XL301, XL302, XL303, XL304, XL305, XL307, XL310, XL311,

XL312, XL314, XL320, XL323, XL325, XL326, XL327, XL330

Product Description

Models and Features

XL2, XL201-205

*See Modem Legend

Additional Models on Next Page

Compaq Presario 1200 Series Portable Notebook Computer Models

Feature XL2 XL201 XL202

Display 12.1-in HPA 12.1-in HPA 12.1-in HPA

Processor Cel/566(128)

FCPGA

Cel/566(128)

FCPGA

Cel/566(128)

FCPGA

Hard Drive 5.0 GB 5.0 GB 5.0 GB

CD or DVD 24X CD-Rom 24X CD-Rom 24X CD-Rom

Diskette

Drive

1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette

Modem 56K Mini PCI

d/f 1, Bear*

56K Mini PCI

d/f 1, Bear*

56K Mini PCI d/f 2,

Seminole*

Battery 3.8 NiMH 3.8 NiMH 3.8 NiMH

System

Memory

32 MB 32 MB 64 MB

Feature XL203 XL204 XL205

Display 12.1-in HPA 13.0-in HPA 12.1-in HPA

Processor Cel/566(128)

FCPGA

Cel/566(128)

FCPGA

Cel/566(128)

FCPGA

Hard Drive 5.0 GB 5.0 GB 5.0 GB

CD or DVD 24X CD-Rom 24X CD-Rom 24X CD-Rom

Diskette

Drive

1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette

Modem 56K Mini PCI d/f 2

Seminole*

56K Mini PCI

d/f 1, Bear*

56K Mini PCI

d/f 2&3*

Battery 3.8 NiMH 3.8 NiMH 3.8 NiMH

System

Memory

32 MB 32 MB 64 MB

2 PRODUCT DESCRIPTION PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200 SERIES

Presario 1200 Series

Model XL2, XL201, XL202, XL203, XL204, XL205, XL212, XL220, XL222, XL223,

XL3, XL301, XL302, XL303, XL304, XL305, XL307, XL310, XL311,

XL312, XL314, XL320, XL323, XL325, XL326, XL327, XL330

XL212-223

* Modem Legend

1) 56K Mini PCI d/f 1 = Bear/Grizzly Modem/NIC Combo = NA, CKK, LA

2) 56K Mini PCI d/f 2 = Seminole = EMEA/APD

3) 56K Mini PCI d/f 3 = Seminole 2 = All AUS/NZ

Additional Models on Next Page

Compaq Presario 1200 Series Portable Notebook Computer Models

Feature XL212 XL220 XL222 XL223

Display 13.3-in TFT 13.0-in HPA 12.1-in TFT 13.3-in TFT

Processor PIII/650(256)

FCPGA

Cel/600(128)

FCPGA

Cel/566(128)

FCPGA

Cel/600(128)

FCPGA

Hard Drive 5.0 GB 6.0 GB 5.0 GB 6.0 GB

CD or DVD 24X CD-Rom 24X CD-Rom 24X CD-Rom DVD

Diskette

Drive

1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette

Modem 56K Mini PCI

d/f 2&3*

56K Mini PCI d/f 1* 56K Mini PCI d/f 2,

Seminole*

56K Mini PCI d/f 1*

Battery 3.2 Li-ion 3.2 Li-ion 3.2 Li-ion 3.2 Li-ion

System

Memory

64 MB 64 MB 64 MB 64 MB

PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200 SERIES PRODUCT DESCRIPTION 3

Presario 1200 Series

Model XL2, XL201, XL202, XL203, XL204, XL205, XL212, XL220, XL222, XL223,

XL3, XL301, XL302, XL303, XL304, XL305, XL307, XL310, XL311,

XL312, XL314, XL320, XL323, XL325, XL326, XL327, XL330

XL3, XL301-310

*See Modem Legend

Additional Models on Next Page

Compaq Presario 1200 Series Portable Notebook Computer Models

Feature XL3 XL301 XL302 XL303

Display 12.1-in HPA 12.1-in HPA 12.1-in HPA 12.1-in TFT

Processor Cel/566(128)

FCPGA

Cel/600(128)

FCPGA

Cel/600(128)

FCPGA

Cel/600(128)

FCPGA

Hard Drive 5.0 GB 5.0 GB 5.0 GB 6.0 GB or 10.0 GB

CD or DVD 24X CD-Rom 24X CD-Rom 24X CD-Rom 24X CD-Rom

Diskette

Drive

1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette

Modem 56K Mini PCI

d/f 1, Bear*

56K Mini PCI

d/f 1*

56K Mini PCI d/f 2,

Seminole*

56K Mini PCI d/f 2*

Battery 3.8 NiMH 3.8 NiMH 3.8 NiMH 3.2 Li-ion or

3.8 NiMH

System

Memory

32 MB 64 MB 64 MB 64 MB

Feature XL304 XL305 XL307 XL310

Display 13.0-in HPA 12.1-in TFT 13.3-in TFT 12.1-in TFT

Processor Cel/600(128)

FCPGA

Cel/600(128)

FCPGA

Cel/600(128)

FCPGA

Cel/600(128)

FCPGA

Hard Drive 6.0 GB 6.0 GB 6.0 GB or 10.0 GB 6.0 GB

CD or DVD 24X CD-Rom 24X CD-Rom 8X DVD 8X DVD

Diskette

Drive

1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette

Modem 56K Mini PCI

d/f 1, Bear*

56K Mini PCI

d/f 1&3*

56K Mini PCI d/f 2* 56K Mini PCI d/f 1*

Battery 3.8 NiMH 3.8 NiMH 3.2 Li-ion 3.2 Li-ion

System

Memory

64 MB 64 MB 64 MB 64 MB

4 PRODUCT DESCRIPTION PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200 SERIES

Presario 1200 Series

Model XL2, XL201, XL202, XL203, XL204, XL205, XL212, XL220, XL222, XL223,

XL3, XL301, XL302, XL303, XL304, XL305, XL307, XL310, XL311,

XL312, XL314, XL320, XL323, XL325, XL326, XL327, XL330

XL311-325

* Modem Legend

1) 56K Mini PCI d/f 1 = Bear/Grizzly Modem/NIC Combo = NA, CKK, LA

2) 56K Mini PCI d/f 2 = Seminole = EMEA/APD

3) 56K Mini PCI d/f 3 = Seminole 2 = All AUS/NZ

Additional Models on Next Page

Compaq Presario 1200 Series Portable Notebook Computer Models

Feature XL311 XL312 XL314

Display 13.3-in TFT 12.1-in TFT 13.3-in TFT

Processor Cel/700(256) FCPGA PIII/700(256) FCPGA PIII/700(256) FCPGA

Hard Drive 10.0 GB 6.0 GB 6.0 GB

CD or DVD 8X DVD 24X CD-Rom 24X CD-Rom

Diskette

Drive

1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette

Modem 56K Mini PCI d/f 1* 56K Mini PCI d/f 1&3* 56K Mini PCI d/f 1&3*

Battery 3.2 Li-ion 3.2 Li-ion 3.2 Li-ion

System

Memory

64 MB 64 MB 64 MB

Feature XL320 XL323 XL325

Display 12.1-in TFT 13.3-in TFT 13.3-in TFT

Processor Cel/633(128) FCPGA Cel/633(128) FCPGA PIII/650(256) FCPGA

Hard Drive 6.0 GB 10.0 GB 6.0 GB

CD or DVD 24X CD-Rom 8X DVD 8X DVD

Diskette

Drive

1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette

Modem 56K Mini PCI d/f 1* 56K Mini PCI d/f 1* 56K Mini PCI d/f 1*

Battery 3.2 Li-ion 3.8 NiMH 3.2 Li-ion

System

Memory

64 MB 64 MB 64 MB

PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200 SERIES PRODUCT DESCRIPTION 5

Presario 1200 Series

Model XL2, XL201, XL202, XL203, XL204, XL205, XL212, XL220, XL222, XL223,

XL3, XL301, XL302, XL303, XL304, XL305, XL307, XL310, XL311,

XL312, XL314, XL320, XL323, XL325, XL326, XL327, XL330

XL326-330

* Modem Legend

1) 56K Mini PCI d/f 1 = Bear/Grizzly Modem/NIC Combo = NA, CKK, LA

2) 56K Mini PCI d/f 2 = Seminole = EMEA/APD

3) 56K Mini PCI d/f 3 = Seminole 2 = All AUS/NZ

Compaq Presario 1200 Series Portable Notebook Computer Models

Feature XL326 XL327 XL330

Display 13.0-in HPA 13.0-in HPA 12.1-in TFT

Processor Cel/600(128)

FCPGA

Cel/633(128)

FCPGA

PIII/650(256)

FCPGA

Hard Drive 6.0 GB 6.0 GB 6.0 GB

CD or DVD 24X CD-Rom 24X CD-Rom 24X CD-Rom

Diskette

Drive

1.44 Std. Diskette 1.44 Std. Diskette 1.44 Std. Diskette

Modem 56K Mini PCI

d/f 1*

56K Mini PCI

d/f 1*

56K Mini PCI d/f 1*

Battery 3.2 Li-ion 3.2 Li-ion 3.2 Li-ion

System

Memory

128 MB 64 MB 64 MB

Other manuals for Compaq Presario

This manual suits for next models

Table of contents

Other Compaq Laptop manuals

Compaq

Compaq 1600R - ProLiant - 128 MB RAM Manual

Compaq

Compaq Armada e500s - Notebook PC User manual

Compaq

Compaq Presario X1000 - Notebook PC User manual

Compaq

Compaq PRESARIO 5BW284 User manual

Compaq

Compaq Evo n150 PC Manual

Compaq

Compaq AirLife 100 User manual

Compaq

Compaq Compaq Notebook Series User manual

Compaq

Compaq 6720t - Mobile Thin Client User instructions

Compaq

Compaq Presario 700 Series User manual

Compaq

Compaq nx7300 - Notebook PC User manual

Compaq

Compaq TC1000 - Tablet PC - Crusoe TM5800 1 GHz Parts list manual

Compaq

Compaq 2230s - Notebook PC Installation instructions

Compaq

Compaq nc6140 - Notebook PC User manual

Compaq

Compaq 6530b - Notebook PC Manual

Compaq

Compaq Compaq 311245-001 User manual

Compaq

Compaq 7400 - Armada - PII 366 MHz User manual

Compaq

Compaq Armada M300 Series Manual

Compaq

Compaq EVO NOTEBOOK N410C Installation instructions

Compaq

Compaq EVO NOTEBOOK N410C User manual

Compaq

Compaq Presario 1700 Series Product information sheet

Compaq

Compaq Presario,Presario 1650 User manual

Compaq

Compaq Presario X1000 - Notebook PC Instruction Manual

Compaq

Compaq N115 Manual

Compaq

Compaq Presario R3000 - Notebook PC User manual

Popular Laptop manuals by other brands

HP ze2401xt - Pavilion Notebook PC datasheet

Velocity

Velocity NoteMagix M10 quick start guide

Dell

Dell Alienware 17 R2 Service manual

Toshiba

Toshiba A105-S2236 Specifications

HP ENVY 17 Maintenance and service guide

Winbook

Winbook LM user guide

Dell

Dell Inspiron 1464 Setup guide

Dell

Dell Inspiron 15R 5537 quick start guide

HP PROBOOK 4520S Maintenance and service guide

Dell

Dell Latitude ATG D620 Service manual

Sony

Sony VAIO PCG-FX270 Specifications

Dell

Dell Latitude 7310 Service manual

Dell

Dell Precision GU806 Quick reference guide

Sony

Sony VAIO PCG-R505JLK user guide

Lenovo

Lenovo THINKPAD X32 Setup guide

HP Compaq tc4200 Software guide

Toshiba

Toshiba mini NB300 specification

Lenovo

Lenovo ThinkPad X201 Tablet Manual
