Comica CVM-WM100 User manual
UHF Wireless Microphone
CVM-WM100
USER MANUAL
Specification
Lavalier Transmitter TX
48
520.000MHz~534.100MHz
15dBm
Channels
Wireless Frequency
Transmitting Power
Receiver RX
48
520.000MHz~534.100MHz
Channels
Wireless Frequency
Hand-held Transmitter HTX
Channels
Wireless Frequency
Transmitting Power
48
520.000MHz ~ 534.100MHz
15dBm
Foreword
Main Features
Thanks for purchasing the COMICA WM100 UHF wireless microphone.
WM100 utilizes UHF wireless technology and LCD lattice screen, it comes with
16-levels adjustable volume, built-in with ‘Adjustable RF Strength’, ‘Local Audio
Testing’, ‘Real-time Audio Monitor’ functions,etc., which takes you more
professional and convenient recording;
To ensure the security of the product, please carefully read the user
manual ,correctly install and operate the item.
. Multiple Channels for Serveral Devices Work Together;
. Working Distance Up to 100m; (100m in Open Area, 60m in Barrier Area)
. Local Audio Test in Transmitter End;
. Real-time Audio Status Monitor in Receiver End;
. Real-time Audio Monitor;
. 16-levels Adjustable Volume;
. RF Signal Strength Adjusted in Transmitter End;
. Muting Mode;
. Lattice LCD Display, High Resolution;
Muting Mode16-levels Adjustable
Audio Volume
100m Working
Distance
Lattice LCDReal-time
Monitor
Wireless Audio
Monitor
Local Audio
Testing
1
Notice
The antenna will affect working distance, be sure to protect it and avoid any
man-made damage;
Working distance will be affected by surround environment, make sure the
background is open with no interference, and turn off the device’s WIFI during
usage;
RF strength is advised to set to ‘Low’ for short working-distance request, which
can help decrease power consumption and increase power duration;
While working with smartphone, one must purchase the TRS-TRRS audio cable
adapter separately;
Take notice of the batteries’ ‘positive and negative poles’ to avoid reverse,
otherwise the product maybe damaged;
Keep the product in dry environment;
Don’t expose the product or work with it in Rain to avoid short-circuit;
2
Main Body
Accessories
In Packing List
Lavalier TransmitterHand-held Transmitter
3.5mm Audio Mic
3.5mm-3.5mm Audio Output Cable
3.5mm-XLR Audio Output Cable
Waist Belt Clip x 2pcs
Camera Mount
Receiver
1
1
1
6
6
2
7
3
8
4
9
5
2
3
4
5
Wind Muff
Portable Case
User Manual
Warranty Card
6
7
8
9
WM100=Lavalier Transmitter+Receiver
WM100H=Handheld Transmitter+Receiver
Item is included only in WM100
3
Components and Instruction
Components
Hand-held Transmitter
Microphone
LCD Display
Power/CH Setting Button
IR Screen
Low cut/Normal Audio Switch
Channel Sequence Switch
AA Battery Holder
1
2
3
4
5
6
7
2
1
3
4
7
65
4
Lavalier Transmitter
Antenna
LINE IN Input
MIC Input
Power/Muting Button
Working Indication Light
Function Selection Button -
Function Setting Button
Function Selection Button +
AA Battery Holder
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
9
9
8
5
Receiver
Antenna
3.5mm Audio Output
3.5mm Audio Monitor Output
Power Button
Working Indication Light
Function Selection Button -
Function Setting Button
Function Selection Button +
AA Battery Holder
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
6
Screen Display Instruction
8 8
Normal recording mode Power Indication
Channel
Hand-held Transmitter HTX:
Lavalier Transmitter TX :
RF Transmitting Strength High Icon：
RF Transmitting Strength Low Icon：
Channel Channel
Frequency
Locking/Unlocking Icon Audio Status Indication Bar
Normal Audio Mode Icon:
Muting Mode Icon：Power Indication
CH
AF
MHz
00
520. 000
H
7
Indication Light Instruction
Work Normally
Muting Mode
Low-power
Channels Not Match
Green Light Keeps On
Green Light Flicker
Red Light Keeps On
Red Light Flicker
（Only for Receiver）
Receiver RX:
Channel Channel
Frequency
Locking/Unlocking Icon Audio Status Indication Bar
Volume IndicationRF Receiving Strength Power Indication
CH
AF
MHz
00
520. 000
VOL 15
8
