Coleman 5435D User manual

Propane Stoves

INSTRUCTIONS FOR USE

IMPORTANT

Read this manual care-

fully before assembling,

using or servicing

these stoves. Keep this

manual for future refer-

ence.If you have ques-

tions about assembly,

operation, servicing or

repair of these stoves,

please call Coleman at

1-800-835-3278 or

TDD: 316-832-8707. In

Canada call 1-800-

387-6161.

5435D

Electronic Ignition

5430C

Standard Ignition

ANSI Z21.72b - CSA 11.2b (2002) Camp Stove

CERTIFIED

www.coleman.com

®®

Contents

General Safety Information

To Set Up

To Light

To Tu r n O ff

To Store

To Clean

Things You Should Know

Parts List

Warranty

This manual contains important information about the assembly, opera-

tion and maintenance of these propane stoves. General safety information

is presented in these first few pages and is also located throughout the

manual. Particular attention should be paid to information accompanied by

the safety alert symbol “ DANGER”, “ WARNING”, “ CAUTION”.

Keep this manual for future reference and to educate new users of this

product.This manual should be read in conjunction with the labeling on

the product.

Safety precautions are essential when any mechanical or propane fueled

equipment is involved.These precautions are necessary when using, stor-

ing, and servicing. Using this equipment with the respect and caution

demanded will reduce the possibilities of personal injury or property

damage.

The following symbols shown below are used extensively throughout this

manual. Always heed these precautions, as they are essential when using

any mechanical or propane fueled equipment.

General Safety Information

DANGER

• CARBON MONOXIDE HAZARD

• This appliance can produce carbon monoxide

which has no odor.

• Using it in an enclosed space can kill you.

• Never use this appliance in an enclosed space

such as a camper, tent, car or home.

If you smell gas:

1. Do not attempt to light appliance.

2. Extinguish any open flame.

3. Disconnect from fuel supply.

FOR YOUR SAFETY

Do not store or use gasoline or other liquids with

flammable vapors in the vicinity of this or any other

appliance.

FOR YOUR SAFETY

General Safety Information

cont.

• EXPLOSION - FIRE HAZARD

• Never store propane near high heat, open flames, pilot lights, direct

sunlight, other ignition sources or where temperatures exceed 120

degrees F (49°C).

• Propane is heavier than air and can accumulate in low places. If you

smell gas, leave the area immediately.

• Never install or remove propane tank while outdoor stove is lighted,

near flame, pilot lights, other ignition sources or while outdoor stove is

hot to touch.

• During operation, this product can be a source of ignition. Never use

the stove in spaces that contain or may contain volatile or airborne com-

bustibles, or products such as gasoline, solvents, paint thinner, dust parti-

cles or unknown chemicals. Minimum clearances from combustible mate-

rials: 12 inches from the sides & 48 inches from the top.

• Provide adequate clearances around air openings into the combustion

chamber.

Not for home or recreational vehicle use.

WARNING

We cannot foresee every use which may be made of our products.

Check with your local fire safety authority if you have questions

about use.

Other standards govern the use of fuel gases and heat producing prod-

ucts for specific uses.Your local authorities can advise you about these.

• Never refill disposable cylinders.

• Use the preset regulator that came with the stove. Do not attempt to

adjust.

DANGER

DANGER indicates an imminently hazardous situation which, if not

avoided, will result in death or serious injury.

WARNING

WARNING indicates a potentially hazardous situation which, if not

avoided, could result in death or serious injury.

CAUTION

CAUTION indicates a potentially hazardous situation which, if not

avoided, may result in minor or moderate personal injury, or property

damage.

Failure to comply with the precautions and instructions provided with

these stoves can result in death, serious bodily injury and property loss or

damage from hazards of fire, explosion, burn, asphyxiation, and/or carbon

monoxide poisoning.

Only persons who can understand and follow the instructions should use

or service these stoves.

If you need assistance or information such as an instruction manual or

labels, contact the Coleman Co., Inc.

DANGER

General Safety Information

cont.

• BURN HAZARD

• Never leave stove unattended when hot or in use.

• Keep out of reach of children.

WARNING

CALIFORNIA PROPOSITION 65:

WARNING:This fuel, and byproducts of combustion of this fuel,

contain chemicals known to the state of California to cause cancer,

birth defects, or other reproductive harm.

• SERVICE SAFETY

• Keep all connections and fittings clean. Inspect propane cylinder and

stove propane connections for damage before attaching.

• During set up, check all connections and fittings for leaks using

soapy water. Never use a flame. Bubbles indicate a leak. Check that

the connection is not cross-threaded and that it is tight. Perform anoth-

er leak check.If there is still a leak, remove the cylinder and contact

Coleman for service or repairs.

• Use as a cooking appliance only. Never alter in any way or use with

any device or part not expressly approved by Coleman.

• Clean stove frequently to avoid grease accumulation and possible

grease fires.

CAUTION

WARNING

• This product is fueled by propane gas. Propane gas is invisible, odorless,

and flammable. An odorant is normally added to help detect leaks and can

be described as a “rotten egg” smell.The odorant can fade over time so

leaking gas is not always detectable by smell alone.

• Propane gas is heavier than air and leaking propane will sink to the lowest

level possible. It can ignite by ignition sources including matches, lighters,

sparks or open flames of any kind many feet away from the original leak.

Use only propane gas set up for vapor withdrawal.

• Propane gas should be stored or used in compliance with local ordinances

and codes or with ANSI/NFPA 58.Turn off propane when not in use.

DANGER

• CARBON MONOXIDE HAZARD

• This stove is a combustion appliance. All combustion appliances produce

carbon monoxide (CO) during the combustion process. This product is

designed to produce extremely minute, non-hazardous amounts of CO if

used and maintained in accordance with all warnings and instructions. Do

not block air flow into or out of the stove.

• Carbon Monoxide (CO) poisoning produces flu-like symtoms, watery eyes,

headaches, dizziness, fatigue and possibly death.You can't see it and you

can't smell it. It's an invisible killer. If these symptoms are present during

operation of this product get fresh air immediately!

• For outdoor use only.

• Never use inside house, camper, tent, vehicle or other unventilated or

enclosed areas.This stove consumes air (oxygen). Do not use in unven-

tilated or enclosed areas to avoid endangering your life.

To Set Up

DANGER

• CARBON MONOXIDE HAZARD

• For outdoor use only.

• Never use inside house, camper, tent, vehicle or other unventilated or

enclosed areas.This stove consumes air (oxygen). Do not use in unventilated or

enclosed areas to avoid endangering your life.

NOTE: Use Coleman 16.4 oz. dis-

posable propane cylinders.The LP-

gas cylinder(s) used with stoves

must be constructed and marked in

accordance with the specififcations

for LP-gas cylinders of the U.S.

Department of Transportation or

Transport Canada

, CAN/CSA B339.

■ Press on latch to open lid and

position wind baffles as shown.

Insert wire clips into slots.

■ Remove plastic cap from top of

propane cylinder and screw

propane cylinder into regulator

hand tight.

■ Screw regulator into stove

hand tight. CAUTION

• SERVICE SAFETY

Keep all connections and fittings

clean. Inspect propane cylinder and

stove propane connections for

damage before attaching.

During set up, check all connec-

tions and fittings for leaks using

soapy water. Bubbles indicate a

leak. Never use a flame.

To Light

DANGER

• EXPLOSION - FIRE HAZARD

• Propane is heavier than air and can accumulate in low places. If you smell

gas, leave the area immediately.

• Always attach or detach propane source outdoors; never while stove is lighted,

near flame, pilot lights, other ignition sources or while stove is hot to touch.

• This stove is red hot during use and can ignite flammables too close to the

burners. Keep flammables at least 12 inches from the sides and 48 inches from

the top of the stove. Keep gasoline and other flammable liquids and vapors well

away from stove.

■ Close both burner valves firmly.

■ Remove regulator from storage

position under grate and inspect

gasket on the stove connection

before use.

To Light

cont

INSTA

Start

™

Electronic Ignition Stoves:

■Open burner valve and rotate

ignitor knob several times until

burner lights.

Note: If ignitor fails to light stove,

use match to light burner. If the

stove is wet the ignitor may not

spark.

Standard ignition stoves:

■ Hold lighted match near burner

and open burner valve. ■ Adjust flame with burner valves.

■ Flame should be blue with a hint

of yellow on tips.

WARNING

• BURN HAZARD

• Never leave stove unattended when hot or in use.

• Keep out of reach of children.

To Turn Off

■ Close burner valves firmly.

To Store

■ Remove propane cylinder from regu-

lator and replace plastic cap on cylinder.

■ Unscrew regulator from stove

and place in storage position as

shown.

To Store

cont.

■ Lift off grate.

■Wipe clean with soft cloth and

mild household cleaner. Do not use

abrasives.

DANGER

• EXPLOSION - FIRE HAZARD

• Never store propane near high

heat, open flames, pilot lights, direct

sunlight, other ignition sources or

where temperatures exceed 120

degrees F (49°C).

• Refillable propane tanks must

always be stored outdoors in a well

ventilated space. Never store

propane tank in an enclosed area

(house, garage, etc.). If stove is to

be stored indoors, disconnect the

propane tank for outdoor storage.

To Clean

Things You Should Know

1. It is unsafe and illegal in some places to store or use propane cylinders

of greater than 1.14 kg (2.5 lbs) water capacity (approximately 1 lb.

propane) in occupied enclosures.

2. If using refillable propane cylinder, use only Coleman parts and acces-

sories.

3.The usual storage areas for camping and picnic equipment are the

basement, attic, or garage.To avoid the accumulation of dust, cobwebs,

etc., that is common in these areas, place your stove in a plastic bag and

seal it with a rubber band.

4. For repair service call one of the numbers on the front cover for location

of your nearest Coleman Service Center. If a service center is not conve-

niently located, attach to the product a tag that includes your name,

address, daytime telephone number and description of the problem.

Carefully package the product and send either by UPS or Parcel Post

insured with shipping and insurance prepaid to:

For products purchased in the United States:

The Coleman Company, Inc.

3600 North Hydraulic

Wichita, KS 67219

For products purchased in Canada:

Sunbeam Corporation (Canada) Limited

5975 Falbourne Street

Mississauga, Ontario

Canada L5R 3V8

5. If not completely satisfied with the performance of this product, please

call one of the numbers listed on the cover of this manual.

Parts List

Standard Electronic

Ignition Ignition

No. 5430C 5435D Description

1 5430A5471 5430A5471 Burner Assembly - Left

2 5430D1551 5435D1551* Cook Top

3 5430B5401 5430B5401 Grate

4 R413-149T R413-149T Valve Knob Assembly

5 R430A565T R430A565T Regulator Assembly

6 5430-5451 5430-5451 Valve Assembly

7 5430A3461 5430A3461 Burner Assembly

8 5430A5461 5430A5461 Burner Assembly - Right

9 5423A5611 5423A5611 Small Parts Kit

10 413B4971 413B4971 Wind Baffle Clips

11 N/A 413-2201 Ignitor Assembly

12 N/A 413-1481 Ignitor Knob

*Electrode Assembly Included

11 12

Warranty

Limited Lifetime Warranty

The Coleman Company, Inc. (“Coleman”) warrants that for the period that you

own this product, it will be free from defects in material and workmanship.

Coleman, at its option, will repair or replace this product or any component of

the product found to be defective during the warranty period. Replacement will

be made with a new or remanufactured product or component. If the product is

no longer available, replacement may be made with a similar product of equal

or greater value.This is your exclusive warranty.

This warranty is valid for the original retail purchaser from the date of initial

retail purchase and is not transferable. Keep the original sales receipt. Proof of

purchase is required to obtain warranty performance. Coleman dealers, service

centers, or retail stores selling Coleman products do not have the right to alter,

modify or in any way change the terms and conditions of this warranty.

This warranty does not cover normal wear of parts or damage resulting from

any of the following: negligent use or misuse of the product, use on improper

voltage or current, use contrary to the operating instructions, disassembly,

repair or alteration by anyone other than Coleman or an authorized service

center. Further, the warranty does not cover Acts of God, such as fire, flood,

hurricanes and tornadoes.

Coleman shall not be liable for any incidental or consequential damages

caused by the breach of any express or implied warranty or conditions. Except

to the extent prohibited by applicable law, any implied warranty of merchantabil-

ity or fitness for a particular purpose is limited in duration to the duration of the

above warranty or conditions.Some states, provinces or jurisdictions do not

allow the exclusion or limitation of incidental or consequential damages or limi-

tations on how long an implied warranty lasts, so the above limitations or exclu-

sion may not apply to you.This warranty gives you specific legal rights, and you

may also have other rights that vary from state to state or province to province.

How to Obtain Warranty Service

Take the product to an authorized Coleman service center.You can find the

nearest authorized Coleman service center by calling 1-800-835-3278 or TDD

316-832-8707 in the United States or 1 800 387-6161 in Canada.If a service

center is not conveniently located, attach to the product a tag that includes your

name, address, daytime telephone number and description of the problem.

Include a copy of the original sales receipt. Carefully package the product and

send either by UPS or Parcel Post insured with shipping and insurance pre-

paid to:

For products purchased in the United States:

The Coleman Company, Inc.

3600 North Hydraulic

Wichita, KS 67219

For products purchased in Canada:

Sunbeam Corporation (Canada) Limited

5975 Falbourne Street

Mississauga, Ontario

Canada L5R 3V8

Do not mail products with fuel in tanks, or with disposable propane cylinders.

Remove glass globes from lanterns and wrap separately.

DO NOT RETURN THIS PRODUCT TO THE PLACE OF PURCHASE.

If you have any questions regarding this warranty please call 1-800-835-3278

or TDD 316-832-8707 in the United States or 1 800 387-6161 in Canada.

This manual suits for next models

Table of contents

Other Coleman Stove manuals

Coleman

Coleman Denali 9790-A25 User manual

Coleman

Coleman 9946 Series User manual

Coleman

Coleman 5412A Series User manual

Coleman

Coleman Dual Fuel 428 User manual

Coleman

Coleman 2000000117 User manual

Coleman

Coleman 5431A Series User manual

Coleman

Coleman FYRESTORM 9770 User manual

Coleman

Coleman 9944-857 User manual

Coleman

Coleman 5428A Series User manual

Coleman

Coleman Fyreknight Hyperflame 9966 Series User manual

Coleman

Coleman 5431B Series User manual

Coleman

Coleman 425 Guide

Coleman

Coleman 5466A Series User manual

Coleman

Coleman 5432A Series User manual

Coleman

Coleman Denali 9790 User manual

Coleman

Coleman Exponent Gemini 9780 Series User manual

Coleman

Coleman 9944 Series User manual

Coleman

Coleman 5442 Series User manual

Coleman

Coleman Exponent M550B725 User manual

Coleman

Coleman 5444 Series User manual

Coleman

Coleman 5497 Series User manual

Coleman

Coleman 5453A Series User manual

Coleman

Coleman 533B User manual

Coleman

Coleman 5430F Series User manual

Popular Stove manuals by other brands

Arada

Arada Cassette Stove installation guide

Parmco

Parmco FS 600 Installation and operating instructions

MCZ

MCZ SUITE AIR 10 M2 installation guide

HearthStone

HearthStone Stowe DV 8321 Owner's manual & installation guide

Cattara

Cattara FAMILY manual

Stanley

Stanley Argon F500 OVAL Installation and operating instructions

Avalon

Avalon B-VENT instructions

Nordpeis

Nordpeis Vega user manual

Exquisit

Exquisit EKC601-5 Instructions for use and installation

Stanley

Stanley Oisin Oil MK II Installation and operation instruction

Thermocet

Thermocet Brookfield S/CC Operating and installation instructions

HASE

HASE delhi operating instructions

Vermont Castings

Vermont Castings Intrepid 2 User instructions

Italiana Camini

Italiana Camini CLASSICA Installation, use and maintenance

Avalon

Avalon Vashon Avanti DVS FS manual

Spartherm

Spartherm ambiente a1 Installation and operating manual

Dimplex

Dimplex MCFSTV12AU manual

Warmlite

Warmlite WL46040 manual
