Coleman 5400 Series 9992-141 Application guide

9992-056 (4/8/05)

IMPORTANT!! TO AVOID UNNECESSARY PROBLEMS!!

BEFORE YOU BEGIN: Review this parts list with the parts in

your carton. If you have missing or damaged parts, call this

number IMMEDIATELY, 1-800-356-3612, for the SERVICE

CENTER nearest you.

The Coleman Company, Inc.

3600 N. Hydraulic

Wichita, KS 67219

Internet site:

www.coleman.com

1-800-356-3612

TDD: 316-832-8707

ASSEMBLER / INSTALLER:

Leave these instructions with the consumer.

CONSUMER / USER:

Read all these instructions and keep them in a

safe place for future reference.

Gas Barbecue

Replacement Parts List

5400 LP Gas Series

Gas Barbecue

Replacement Parts List

5400 LP Gas Series

Item

Number

9992-6251

9990-2091

9990-4221

9990-4111

9992-4451

9992-4501

9990-4121

9990-4041

9992-4201

9992-4211

9990-4141

9990-4651

9990-4161

9990-4231

9990-4131

9990-4951

9992-4111

9992-4151

9992-0521

9990-4881

9992-4551

9990-4321

9990-4291

9990-4341

9990-4351

9990-5181

9990-5361

9990-5381

9990-5221

9990-5481

9990-5491

9990-5501

9947-6561

9990-5341

9990-5511

9992-4531

9990-5541

9990-5201

9990-5301

9990-5841

9990-5061

9990-5071

9990-5551

9992-5421

9990-5021

9990-5401

9990-5351

9990-3421

9990-3271

9992-0561

9990-4681

Description

Hood Wrapper Assembly w/heat indicator

Lid Handle Assembly w/hardware

Firebox Assembly (Black PE)

Control Panel (LP Graphics)

Left Side Burner Table Assembly (Silver Vein)

Right Side Table Assembly (Silver Vein)

Cabinet Side Panel (LH)

Cabinet Side Panel (RH)

Cabinet Front Door (LH) W/Hinge (Silver Vein)

Cabinet Front door (RH)w/Hinge (Silver Vein)

Cabinet Bottom Panel

Grease Tray

Trim Panel

Top Panel

Rear Panel

Warming Rack

Hose/Regulator Assembly

Manifold/Valve Assembly

Instruction Manual 5400 Series

Hardware Pack

Side Burner Lid (Silver Vein)

Side Burner Hinge

Side Burner Drip Tray Assembly

Side Burner Electrode

Side Burner Trivet

Cylinder Support Assembly

Electronic Module

Main Burner

Door Magnet

Locking Caster

Caster

Tool Hook

Side Burner

Main Burner Knob

Heat Tent

Back Home Select Logo Plate

Hood Hinge Pin (2 pk)

Collector Box Assembly

Side Burner Hair Pin

Side Burner Control Knob

Drip Cup

Drip Cup Hanger

Control Knob Bezel

Grate-SS Rod Cooking

Door Handle

Lead Wires (2 pk)

Ignitor Switch

Pads - Rubber Lid (2 pk)

Spacer Top Panel

Repair Parts List 5400 Series (not illustrated)

Chain - Matchstick Extension

24 34

136

37 48

The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, KS 67219 U.S.A.

1-800-356-3612 • TDD: 316-832-8707

Coleman® and are registered trademarks of The Coleman Company, Inc.
