Cobi Rehab Rollator King User manual

Rollator King

Strong and functional rollator designed for the bariatric user.

The Rollator King is intended for users weighing up to 325 kg.

The rollator can be used outdoors and indoors in institutions, care centers

and in private homes. Rollator King comes in two sizes.

Cobi Rehab and Cobi Rehab’s suppliers comply with UN conventions on

child and forced labor and ILO 029, C132 and C182.

USER MANUAL

Scan or click the QR code and find

the product on the Danish AssistData.

| 2021-05 User manual Rollator King

Table of content

1. Safety .................................................................................................................................................................................................3

2. Symbols ...........................................................................................................................................................................................4

3. General .............................................................................................................................................................................................5

4. Using the Rollator King.............................................................................................................................................................5

5. Assembling the rollator.............................................................................................................................................................6

6. Adjustment.....................................................................................................................................................................................6

7. Rollator Support...........................................................................................................................................................................7

8. Cleaning and maintenance ......................................................................................................................................................8

9. Disposal ...........................................................................................................................................................................................8

10. Warranty........................................................................................................................................................................................9

11. Specifications..............................................................................................................................................................................10

12. Ordering ........................................................................................................................................................................................ 11

13. Accessories .................................................................................................................................................................................. 11

| 2021-05 User manual Rollator King

CAUTION

Do not use the Rollator King without prior thorough instruction by

trained staff or by persons who have received instructions in the use of

the rollator. Improper operation may cause injury to the user.

If the Rollator King is used for persons weighing more than the

maximum user weight, the risk of damaging the Rollator King increases.

Carefully study these instructions before using the Rollator

King. Pay attention to Safety Instructions indicated by a warning

triangle .

Cobi Rehab accepts no responsibility for damage caused to the product

nor for personal injury caused by improper installation, assembly or use

of the Rollator King.

Contact Cobi Rehab immediately in the case of damaged or missing

parts. Never use your own spare parts.

SAFETY INSTRUCTIONS

Always lock the rollator before sitting down.

Always remember to tighten the hand nuts for height adjustment.

Never sit on the rollator and push off with the feet.

Never use the rollator on stairs and escalators.

Never use the rollator as a wheelchair.

Never use the rollator to transport large items. Only items that fit in the

basket.

Never use the rollator on surfaces that slope by more than 3,5 degrees.

Never use the rollator on soft and uneven surfaces.

Keep both feet on the ground while using the rollator as resting chair.

This prevents the rollator from tipping backwards if the user leans

against the backrest.

1. Safety

| 2021-05 User manual Rollator King

The following symbols are used in this user manual and/or

on the product label.

Caution!

Declaration of conformity, Medical Device

Regulation, EU 2017/745

IP31

Ingrees Protection Ratings Guide.

Cobi Catalogue number

Serial number

Date of manufacture

Manufacturer

Medical device

Body weight

Consult instructions for use

CE-Label on the product is located on the bottom frame.

See example of label below.

2. Symbols

| 2021-05 User manual Rollator King

The Rollator King should only be used by the

independent user, who are physically and

mentally able to use the rollator safely (e.g., to

walk, steer, brake).

Rollator King is intended for users weighing up to

325 kg. The rollator is designed for use outside

and inside, in institutions, care centers and private

homes.

The rollator should only be used on level

ground and accessible terrain, indoors as well as

outdoors.

Be aware that the user always walks with the

rollator close to the body. Too long distance can

result in instability.

Always consult a therapist before assigning a

Rollator King to a person.

Contraindications

The user of Rollator King must have physical and

cognitive resources to control and operate the

rollator in a safe manner.

This user guide contains important information

about the use of Rollator King and the target

group for the rollator. It also includes a wide

range of specifications on Rollator King.

The most recent version of this user guide can be

found on our website. Check if the version you are

reading now is the most recent.

If you need a user guide that is written in a larger

font size, the guide is available in PDF format at

cobirehab.com, which can be scaled up to the

required font size.

You can always contact Cobi Rehab on + 45 7025

2522 or cobi@cobi.dk if you want more

information about Rollator King.

Cobi Rehab reserves the right to change the

product specifications without providing prior

notice.

The UDI number of the rollator appears on the

label, which is located on the side of the frame.

Product safety notices and product recalls can be

viewed on the website.

https://www.cobirehab.com/kunde-hos-

cobi/vigtig-produktinformation/

4. Using the Rollator King

Rollator King is available in two sizes, 61cm and 71

cm which refers to the distance between the

handles. Both models have a seat width of 51cm,

seat height of 51cm and a seat depth of 37 cm.

The total width of the Rollators is 13 cm more

than the distance between the handles. Be aware

of the model with a width of 84 cm can have

difficulties going through certain doorways.

How to choose the right size

Which size of Rollator King depends on the body

shape of the user. Contact Cobi Rehab for

guidance and instructions on how to choose the

right size.

For users with a lot of fullness around the pelvis

and thighs, we recommend a size 71 cm.

Always measure user standing. For example, place

a book or similar on the side of the user's body

where the user is widest. Then measure the

distance between the two books.

4.1 More use

3. General

| 2021-05 User manual Rollator King

Adjusting the height of the handle

Remove the screw and the height-adjustment

knob from both handles to enable the handles to

move freely up and down.

2. Push the handle up or down until the required

height has been found. Reinsert the screw and the

knob again. Place the bolt on the back side, so it

fits in the hole.

3. Tighten.

Ensure left and right handles are level to avoid

instability problems.

Make sure the user keeps with the Rollator King

close to the body when in use. The correct size of

the rollator is there for important to make sure

the user can place between the handles.

How to fold the rollator?

1. Grab the front of the seat (the side closest to

user) with one hand. Hold one of the handles with

the other hand.

2. Lift the seat.

3. The rollator now folds.

To minimize the size of an already folded rollator,

remove the back and basket.

Adjustment of the brakes

The rollator can brake in two ways:

Brief stops:

Squeeze each brake handles upwards.

Longer stops:

Push both brake-handles downwards, so they lock

in a “down” position. The handles stay in this

position until they are actively released.

Brake inspection

The brakes are properly set on delivery.

Brake operation, and parking brake should be

checked before every use.

If the parking brake cannot lock or if the brakes

are not working correctly, contact Cobi Rehab

immediately.

Service the brakes every three months.

6. Adjustment

In addition to the rollator, the shipped box also

contains two handles (connected to the rollator

by cables), a basket and a safety backrest.

1. Unfold the rollator.

2. Remove the screws for height adjustment from

the handlebar.

3. Attach the bars to the rollator.

4. Mount the back on the front of the rollator by

pulling upwards on the knobs on the left and right

sides, respectively.

Notice that the knob can be locked to make it

easier to mount the back. This is done by pulling

the knob upwards and turning it a quarter turn.

Remember to loosen the knob again to fasten the

safety back rest.

5. Mount the basket in the front by placing the

two hooks on the upper tube below the seat.

Place the notch on the bottom of the basket on

top of the bottom tube.

6. Adjust the height of the handles to suit the user.

7. Adjust the brakes.

Do not use the rollator without the safety

backrest.

The safety backrest ensure that the weight is not

positioned too far forward. If the weight it

positioned too far forward, the rollator may tip.

Do not lay or put extra cushions on the

upholstered seat when in use.

5. Assembling the rollator

| 2021-05 User manual Rollator King

The Rollator King can be transported from one

place to another. Fold the rollator as described

above.

Rollator King cannot be used as a seat in a

motor vehicle.

Rollator King withstands being lifted in the frame,

handles or back rest, but not in the basket.

Contact Cobi Rehab for more information on

transportation or disassembly.

6.1 Transportation in motor vehicle

The Rollator King should be stored in the dark

and covered with a sheet or other cover.

The Rollator King should be stored at

temperatures between -10°- 50°C.

Check regularly that the rollator has not become

wet or damaged during storage.

6.2 Storage (incl. long-term storage)

Rollator Support is in the construction like

Rollator King. Only difference is the height

adjustable forearm supports which will assist the

user to drive the rollator forwards in an upright

position and at the same time relieve the wrists.

If a user needs forearm support for a short or

longer time they can be mounted on the frame of

Rollator King.

Contact Cobi Rehab for more information on

mounting of forearm supports.

Please note that forearm supports are only

possible if the user weighs under 200Kg.

See “Accessories”- section for Rollator Support

item numbers.

7. Rollator Support

| 2021-05 User manual Rollator King

The frame, seat handles, and safety backrest is

cleaned with water and a household detergent.

Contact Cobi Rehab for further guidelines on

cleaning and maintenance.

Disinfection

The frame, seat handles, and safety backrest can

be disinfected with ethanol 70-85% or a chlorine

product 1000-1200 ppm.

The upholstered seat and the back rest must be

replaced or thoroughly disinfected when Rollator

King is transferred to a new user. This is done to

avoid cross-contamination and infections.

Local cleaning and disinfection procedures must

always be followed.

The seat and back holder can be replaced when

switching to a new user.

8.1 Cleaning and disinfection

Check bolts and nuts every three months.

Retighten them if needed.

Non-compliance with the bolt inspection

guidelines can lead to malfunction.

8.2 Maintenance

Products that can no longer be used are to be

disposed of in a sustainable way. Please contact

the relevant authorities for information on proper

disposal.

Recycling

Parts of the rollator can be reused. Contact Cobi

Rehab for more information.

9. Disposal

8. Cleaning and maintenance

| 2021-05 User manual Rollator King

When delivered, the Rehab Rollator King is free

from defects. Should, contrary to all inspections,

there be any defects or damage to the Rollator

King, please contact Cobi Rehab immediately.

The Rollator King is covered by a 1-year warranty

from the date of purchase. The invoice serves as

warranty certificate.

The warranty does not apply to:

- products whose serial number, batch number

etc. have been removed or considerably damaged

- products that have been repaired by

unauthorized staff

- normal wear and tear, for example cleaning,

adjustment, lubrication and update of equipment

or parts.

The warranty is void if Cobi Rehab assesses that

the Rollator King has been used for purposes

other than its intended use, for example, if its

weight capacity is exceeded.

In case of incorrect use, both service and spare

parts will be invoiced.

The warranty described above is the only valid

warranty.

Cobi Rehab may not be held liable for damages of

any kind.

Lack of maintenance can damage the product,

shorten the life, or affect the performance of the

Rollator King.

10. Warranty

Report any incidents related to the use of Rollator

King to Cobi Rehab.

10.1 Unintended incident

After the expected service life, it is important that

an overall assessment of the product is made

before continued use.

After the expected service life, Cobi Rehab

cannot guarantee the suitability and safety of the

product, as Cobi Rehab has no control over how

the product is used and wear and tear.

The overall assessment of the product must be

carried out by qualified professionals, and as a

minimum, consideration must be given to how the

product has been used, the condition of the

product and its components.

Cobi Rehab can always make such an assessment.

10.2 After expiry of expected service life

| 2021-05 User manual Rollator King

Model 61 cm and 71 cm

Maximum user weight

325 kg

Total length

850 mm

Total width

740/840 mm

Width between handles

610/710 mm

Height adjustable in 2.5 cm intervals

770.5 –990 mm

Seat width

510 mm

Seat depth

370 mm

Seat opening

610/710 mm

Seat height

510 mm

Weight

15.7 kg

Weight capacity in basket

5 kg

Foldable

Yes

Massive wheels

Yes

Frame

Powder-lacquered aluminium /SAE41-30

Frame and seat

Flame retardant

Seat and back

Polyurethane

Wheels

8” massive

Expected product life

7 years

ISO-classification

ISO 12 06 06 –11

Risk class

UDI-DI

5740000102490 (61 cm) / 5740000102506 (71 cm)

Basic UDI

5740000100007N8

The surface temperature of the Rollator King can increase or decrease when exposed to external

sources of heat or cold.

11. Specifications

This manual suits for next models

Table of contents

Other Cobi Rehab Mobility Aid manuals

Cobi Rehab

Cobi Rehab XXL-Rehab Rollator King User manual

Cobi Rehab

Cobi Rehab MobiBed User manual

Cobi Rehab

Cobi Rehab XXL-Rehab Stand Tall User manual

Cobi Rehab

Cobi Rehab XXL-Rehab Rollator Support User manual

Cobi Rehab

Cobi Rehab 0130-071-000 User manual

Cobi Rehab

Cobi Rehab 0200-000-000 User manual

Cobi Rehab

Cobi Rehab XXL-Rehab Rollator King User manual

Cobi Rehab

Cobi Rehab XXL-Rehab Crutch User manual

Cobi Rehab

Cobi Rehab XXL-Rehab User manual

Cobi Rehab

Cobi Rehab XXL-Rehab Rollator King User manual

Cobi Rehab

Cobi Rehab XXL-Rehab Crutch User manual

Cobi Rehab

Cobi Rehab 0130-071-000 Dimensions

Cobi Rehab

Cobi Rehab XXL-Rehab User manual

Cobi Rehab

Cobi Rehab 0201-000-000 User manual

Cobi Rehab

Cobi Rehab XXL-Rehab Walking Cane User manual

Cobi Rehab

Cobi Rehab 0205-000-000C User manual

Cobi Rehab

Cobi Rehab 0173-050-000 User manual

Cobi Rehab

Cobi Rehab XXL-Rehab 4-punkt Stok User manual

Popular Mobility Aid manuals by other brands

Alber

Alber Scalamobil iQ operating instructions

Ferno

Ferno CCT-PX user manual

HEPRO

HEPRO Gripo user manual

Otto Bock

Otto Bock Pheon 3R62 Instructions for use

NRS Healthcare

NRS Healthcare M11090 User instructions

Medline

Medline MDS86835DSHEC User Instructions & Warranty

Guldmann

Guldmann Twin Turner II user manual

Drive

Drive ROOMBA Operation manual

Gate

Gate Balder operating instructions

Decon wheel

Decon wheel TNS Notos Assembly instructions

ExoAtlet

ExoAtlet ExoAtlet-II user manual

Invacare

Invacare Storm Series parts catalog

Rhythm Healthcare

Rhythm Healthcare B3800F manual

AMF-BRUNS

AMF-BRUNS PROTEKTOR installation manual

Drive DeVilbiss Healthcare

Drive DeVilbiss Healthcare OTTER Instructions for use

Rhythm Healthcare

Rhythm Healthcare C500U Assembly and Fitting Instructions

Lumex

Lumex RJ4200A manual

Rebotec

Rebotec Jumbo user manual
