Cleanmate S 930 User manual
Cleanmate
Robotic Vacuum Cleaner
Cleanmate S 930
USER MANUAL
1
7
7
7
Contents
Safety Instructions
Product Feature
User Friendly Design
Washable Dust Bin
Product Components 8
Main Body and Accessories 8
Main Body Diagram 9
Dust Bin / Rolling Brush Kit
Charging Docking / Remote Control
Product Operation
Touch Panel Operation
Battery Charging
Starting Up/ Standby/ Sleeping
Schedule
Cleaning Modes
Product Maintenance
Cleaning Side Brush
Cleaning Dust Bin and Filters
Cleaning Sensors and Wheels
Cleaning Charging Poles
Cleaning Rolling Brush Kit
Product Specification
Battery Removal
Usage of Magnetic Strip
Trouble Shooting
Customer support & Warranty
10
11
12
12
13
14
15
17
18
19
19
20
20
20
21
22
22
23
24
1
It indicates that any violations of instruction or improper operation are probably to
cause casualties or severe injuries.
Danger
It indicates that any violations of instruction or improper operation are probably to
cause casualties or severe injuries.
Caution
It indicates that any violations of instruction or improper operation are probably to
cause injuries to people and damage to property.
Notice
It indicates prohibited behavior. Detailed content refer to the sign or the explanation of the sign.
It indicates enforcement behavior. Detailed content referto the sign or the explanation of the sign.
It indicates attention (including warning) content. Detailed content refer to the sign or the
explanation of the sign.
*1. Possible Severe injuries: Blindness, Burns, Electricity Injury, Fracture, Poisoning and other severe injuries that
leave sequela and lead to longterm hospitalization.
*2. Possible Injuries: Burns, and electricity wound that does not require hospitalization.
*3. Possible Property Damage : Damage to furniture, valuable objects and injuries to pets.
Graphic and Sign explanation
Safety Instructions
Before using this product, please read the safety instructions and follow all regular safety precautions.
Warranty service is not applicable to any damage caused by violation of instructions. S 930 cleaning robot
is a sophisticated product which is restricted for indoor cleaning only. DO NOT use the robot for non-cleaning
purpose. Please refer to user manual.
Warning Sign
When the appliance is to be used by a child, the child must be of 8 years old and above. It is recommended
for first time users to keep sight of the appliance during vacuuming to ensure safe operation. For personswith
reduced physical, sensory or mental capabilities or lack of experience and knowledge, proper supervision or
instruction should be given concerning use of the appliance in a safe way to help them understand the hazards
involved. Children should not play with appliance. Cleaning and maintenance should not be made by
children without supervision.
Warning
2
Safety Instructions
Safety Instructions of Product, Charging dock, virtual wall,
power adapter and other accessories.
No Disassembling
Prohibited
Prohibited
Prohibited
Prohibited
Clean Dirt
Alternating Current
Prohibited
Only authorized technicians can disassemble the product. Users are not allowed to
disassemble, repair or modify the product. Otherwise it may cause electric shock,
malfunction and leading to injuries.
It is prohibited to dismantle the battery case.
Dismantling battery case may cause damage or leakage of battery that leads to
re or explosion.
Prohibit using metal or other conducting substance to connect battery postive and
negative ends. It will lead to short circuit and cause explosion.
Do not use a power adapter with AC inverter. It may lead to over heating,
malfunction or fire.
If there are dust accumulations on the metal terminals of the power plug and
surroundings, be sure to clean the dust with a dry cloth.Otherwise it may lead to
electric shock, over temperature or re.
The adapter must use an alternating voltage from 100-240 Vac. Please plug in the
socket correctly.
Only use the original power adapter.
Do not destroy or modify the power cord. Do not over-bend, heat, pull or press the
inflexible cord with heavy objects. Otherwise it will cause damage to cord and
may lead to fire or electric shock
Warning
3
Prohibited
Only use the
product indoors
Prohibited
Prohibited
Prohibited
Prohibited
Do not touch
Do not touch
Do not touch the power cord, plug or adapter with wet hands. Otherwise, it may
cause electric shock.
Never use the product in an environment with volatile substancesto
avoid possibility of fire and danger.
This product is a sophisticated machine for indoor use only.
DO NOT leave the product to children without supervision. Otherwise it may
cause injury.
Do not use this product around flammable substances or in a combustible
environment. Do not use this product around propane gas, gasoline and other
flammable gas and in dustyenvironment; it may lead to explosion or fire.
Do not wash and do not leave this product in a wet or damp environment.
Do not wash main body, charging device. Washing or soaking will cause internal
short circuit.
Do not sit on top of this product. Do not allow adults, children or animals to sit on
this product to avoid damage to the product.
To avoid stumbling on the product, all people in the household should be noticed
when this product is on. Do not touch the wheels or roller brush while product is
working to avoid being pinched by the machine.
Notice
4
Prohibited
Turn off the power
Prohibited
Prohibited
Prohibited
Prohibited
Prohibited
Safety Instructions
Turn the power switch to off when you don’t need to use this product for a long
time. Battery leakage may cause fire, injury or pollution to enviroment. Cut off
power source when unplugging the power adapter and disconnect the plug from
the charging socket. Otherwise, it may cause fire.
Do not cover or wrap the robot while in use.
This product is for indoor use only. Do not use this product to clean bathrooms,
warehouses, factories or bedsetc.
Air outlet
Putting a small or sharp object into air outlet will damage this product.
Do not wash this product. Do not wash the HEPA-filter.
Only dustbin and primary mesh filter are washable. Put dustbin and primary filter
back into main body when dry.
Do not use or expose the product to intense sunlight.
Use the dedicated battery and charging base only. Use of other
batteries or charging base can cause leakage, overheating and/or
explosion.
Charging Notice
Danger
5
Attention
No Disassembling
Prohibited
Prohibited
Prohibited
Unplug the robot when you are not using the robot to avoid short circuit.
Do not dissemble the battery, otherwise, it may cause leakage, overheating
and explosion.
Do not keep necklaces, hairpinsand other metal materials together with this
product during transportation.
Do not throw the battery into a fire or heat the battery.
If there is overheating during charging, stop using theproduct immediately.
To extend the battery’s life, take out the battery and put it in a cool and dry place
when not in use.
Do not immerse this product in water or wash it under running water.
Do not use this product if there are signs of color changes or changes to the
shape.
The battery mush be insulated with tape if recycled or disposed. Contact with
other metal will lead to heating, burst or fire. Bring the used battery to technical
service center, recycler or authorized reseller for disposal. Or dispose the battery
according to local laws.
6
Safety Instructions
Warning
Prohibited
Prohibited
Prohibited
Prohibited
Do not keep necklaces, hairpinsand other metal materials together with this
product during transportation.
Do not charge this battery on other devices.This chargeable battery is designed
for this robot cleaner only.
Do not put the battery back to main body or charge it if there is deformation,
swelling and/or electrolyte leakage from battery case.
Wash off any battery leakage immediately with clean water if there is contact with
skin or clothes.No measures taken may lead to skin inflammation.Do not crush or
throw the battery.
It’s not allowed to copy, publish or record this user manual and related material in any searchable media or
translate to any other languages without our written authorization.
We have made our best efforts to make sure the precision and completeness of this user manual. If there are
any mistakes or omissionsfound, we sincerely thank you for giving us feedback through your local retailer.
As a safety measure, the Cleanmate robot comes with the power switch set to 0 (off). Make sure to
turn it to the on position (1) before charging. See page 9 for the placement of the power switch.
7
Product Feature
Cleanmate S 930 is anautomatic cleaning robot, it has a common sweeping function, double side brush,
strong vacuum power and also a rolling brush kit. It can determine how best to work in order to make it more
efficient in cleaning the floor.
touch the
on the robot, to activate the robot.
User Friendly Design
Operation is simplified,
Washable Dust Bin
Dust bin and primary mesh filter can be washed with water.
Do not wash the HEPA-filter. Simply wash the dust bin under
water after use to avoid dust blowing in the air and cause a second
pollution.
8
Product Components
Main Body and Accessories
Item Description Quantity
1Robot vacuum cleaner 1
2 Charging Docking 1
3 Power Adapter 1
4 Remote Control (no battery inside) 1
5Side Brushes 4
6HEPA-filter 1
7Cleaning brush 1
8User Manual 2
9Magnetic strip 1
