Claypaky C61408 User manual

1

A.LEDA WASH K10 CC - A.LEDA WASH K10 W

A.LEDA WASH K10 TW - A.LEDA WASH K20 CC

A.LEDA WASH K20 W - A.LEDA WASH K20 TW

C61408

C61407

C61406

C61413

C61412

C61411

INSTRUCTION MANUA

Congratulations on choosing a Cla Pak product!

We thank ou for our custom.

Please note that this product, as all the others in the rich Cla

Pak range, has been designed and made with total qualit to

ensure excellent performance and best meet our expectations

and requirements.

Carefully read this instruction manual in its entirety and keep it

safe for future reference. It is essential to know the information

and comply with the instructions given in this manual to ensure

the fitting is installed, used and serviced correctly and safely.

CLAY PAKY S.p.A. disclaims all liability for damage to the fitting

or to other property or persons deriving from installation, use and

maintenance that have not been carried out in conformity with this

instruction manual, which must always accompany the fitting.

CLAY PAKY S.p.A. reserves the right to modify the

characteristics stated in this instruction manual at any time and

without prior notice.

ENG ISH

INDEX

Page

2

12

13

14

16

22

24

25

25

Contents

Safety information EN-IT- R-DE-ES

Unpacking and preparation

Installation and start-up

Control panel

Menu setting

Maintenance

Optional accessories

Technical information

Cause and solution of problems

This manual suits for next models

11
