Clarion PP-4360 User manual

Owner's Manual

PP-4360

Table of contents

1. System Overview �� 2

Control of This Unit �� 2

Steering Remote Control �� 3

Silver box to supply power and simulate some signals �� 4

2. Common Operations �� 5

Home Menu �� 5

Audio Source Switch �� 5

Displays �� 6

Settings �� 6

Connections �� 7

Informations �� 7

3. Bluetooth Operations �� 8

Bluetooth Settings �� 8

Phone Settings �� 9

Bluetooth Phone Operations �� 11

Bluetooth Audio Operations �� 15

4. iPod Operations �� 17

iPod Connection �� 17

iPod Mode Selection �� 17

5. Using Apple CarPlay �� 18

6. Using Siri �� 19

7. Using Android Auto �� 19

8. Declaration of conformity �� 20

English

1. System Overview

Control of This Unit

(Fig 1-1)

[POWER] button: press to turn audio playback on/off.

[VOLUME] knob: rotate to turn volume up/down.

[Day/Night] button: (short) change night mode;

(long) display OFF

[x]: track / folder down;

[v] button: track / folder up.

[MENU] button: press to enter the home menu screen.

[AUDIO] button: press to enter the audio source or

audio playback screen.

[TEL] button: press to switch to the Bluetooth phone

menu screen.

[CAMERA] button: open camera setting.

[BACK] button: press to return to the previous screen.

[TUNE]/[SCROLL] knob: rotate to tune up/down, track

up/down; press to switch sound.

English

Steering Remote Control

3 4 5 7 8

[+] button: volume up.

[-] button: volume down.

[x]: track / folder down

[v] button: track / folder up.

[BACK] button: press to return to the previous screen.

[OK] button: press to enter the audio source or audio playback screen.

[VR] button: start Siri.

[ ] button: press to switch to the Bluetooth phone menu screen or press to

hang up the calling.

English

Silver box to supply power and simulate some signals

NOT USE

the INPUT of +14V

NOT USE

Speed Knob

NOT USE

+B Switch, ACC Switch

and IGN Switch

These LEDS lights when each

switchs(+B, ACC, IGN) become

to turn on

PKB Switch and Navion Switch

NOT USE. Please make usre

to turn off these test switches.

Turning on+B and ACC switch is

as same as key position is ACC

Turning on+B and ACC and IGN switch

is as same as key position is on

English

2. Common Operations

Home Menu

Press the [MENU] button to enter

the main menu screen.

(Fig 2-1-1)

For the CarPlay Audio, Bluetooth

Audio and iPod touchkeys, you

shoud customize the home menu.

■Customize Home Menu

In the home munu screen ((Fig

2-1-1) page 5), please touch

Customize Home Menu to customize the

home menu.

(Fig 2-1-2)

(Next page)

1 2

(Fig 2-1-3)

widget icons

function icons

Drag an icon from the top area to the

bottom area.

Audio Source Switch

While in the audio playback

screen, press [AUDIO] button to

enter the audio source screen.

This unit supports AM/FM,

SiriusXM, USB/iPod, Bluetoot

Audio, Apple CarPlay and Android

Auto audio source plackback.

(Fig 2-2-1)

English

Displays

The audio source playback can be

displayed in the main display, home

menu widget display and the meter

display.

■Main display

(Fig 2-3-1)

■Home Menu Widget Display

For the widget display, please go to

the customized home menu ((Fig

2-1-2) page 5) to customize the

widget display.

(Fig 2-3-2)

(Fig 2-3-3)

■Meter Display

Some information is displayed in this

area.

Bluetooth audio playback, iPod ,

Apple CarPlay music or Bluetooth

phone call information is displayed,

too.

Please press the [X] or [V] button

of the steering remote control to

switch the menu item.

(Fig 2-3-4)

Settings

Press to enter the settings

screen.

(Fig 2-4-1)

(Fig 2-4-2)

■Sound Settings

In the settings screen((Fig 2-4-1)

page 6), please touch Sound to

enter the sound settings screen.

English

(Fig 2-4-3)

■Language Settings

In the settings screen((Fig 2-4-2)

page 6), touch Others and then

Language to enter the language set-

tings screen.

Connections

In the settings screen((Fig 2-4-

1) page 6), please touch

Connections to enter the connections

screen.

(Fig 2-5-1)

GBluetooth : touch to pair, connect or

delete Bluetooth device.

GWi-Fi : touch to connect Wi-Fi.

GUSB : touch to view the information

of connected USB.

GApps : touch to view the

information of connected Apps.

Informations

In the settings screen((Fig 2-4-1)

page 6), please touch Info to

enter the information screen.

(Fig 2-6-1)

Touch System Information to check the

system information.

(Fig 2-6-2)

English

3. Bluetooth Operations

Bluetooth Settings

In the settings screen((Fig 2-4-

1) page 6), please touch

Connections to enter Bluetooth

connections screen.

(Fig 3-1-2)

Touch to enter the Bluetooth

settings screen.

(Fig 3-1-3)

GBluetooth : Bluetooth on or off.

GAllow 2 Phones Simultaneously : allow

connect 2 phones with this unit

simultaneously.

GFavorite Phone : give top priority to

connect to this phone.

GFavorite Audio : give top priority to

connect to this audio device.

GDevice Name : edit the device name

of this unit.

GPIN : edit the PIN code.

■Pairing Bluetooth Device

Please turn Bluetooth of this unit to

be on before pairing.

On the Bluetooth connections

screen ((Fig 3-1-2) page 8),

touch Add New .

(Fig 3-1-4)

Look for this unit’s device name

from your Bluetooth device.

(Default device name: MYCAR)

According the prompt message,

please enter or confirm PIN

to pairing from your Bluetooth

device.

After successful pairing, it

will return to the Bluetooth

connections screen ((Fig 3-1-2)

page 8) and your Bluetooth

device is displayed in the paired

list. “Connected” is displayed

below the device name. And the

corresponding icons and

are lit.

■Connect , Disconnect or Delete a

Paired Bluetooth Device

On the Bluetooth connections screen

((Fig 3-1-2) page 8):

zTouch a paired Bluetooth device

to connect or disconnect to the

device.

zTouch to connect or

disconnect as a phone object.

zTouch to connect or

disconnect as a audio object.

English

zTouch to enter the device

information screen.

(Fig 3-1-5)

You can check the available

features of the device, including

Call, Phonebook, Send Text,

Receive Text, Audio Streaming.

Touch Delete to delete the paired

device.

Phone Settings

In the settings screen ((Fig 2-4-1)

page 6), touch Phone to enter

the phone setting screen.

(Fig 3-2-1)

GConnections : enter the Bluetooth

connections screen ((Fig 3-1-3)

page 8).

GAutomatic Hold : when there is a

coming call whether put the call

on hold or not automatically.

■Adding or Editing Quick Dial

In the phone setting screen ((Fig

3-2-1) page 9), touch Quick Dial

to enter the quick dial screen.

(Fig 3-2-2)

GDelete All : delete all of the quick

dial list.

Touch Edit to enter the quick dial

list screen.

(Fig 3-2-3)

G{Quick Dial List} : touch to edit or

delete the quick dial list.

Touch Add New to enter the adding

new list screen.
