Clage MCX 3 User manual

Zip

Instantaneous Hot Water

Electronically controlled instantaneous water heater

MCX: 27300, 27400 and 27600 models

Instructions for the user

These appliances deliver water not exceeding 50°C in accordance with AS3498

Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036

Contents

1. Safety instructions..............................................................................................3

2. Overview ..................................................................................................... 5

3. Technical data .................................................................................................6

4. Description of the appliance ..................................................................................... 6

5. Typical installations.............................................................................................7

6. Operation .....................................................................................................8

Temperature setting ............................................................................................ 8

Key lock and temperature lock.................................................................................... 8

Additional features ............................................................................................. 8

7. Cleaning and Maintenance ......................................................................................9

8. Troubleshooting and service ....................................................................................10

Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036

1. Safety instructions

Please read these instructions carefully before installing or using the appliance!

Keep the instructions handy with the appliance for future use!

Installation, initial operation and maintenance of this appliance must only be con-

ducted by an authorised professional, who will then be responsible for adherence to

applicable standards and installation regulations. We assume no liability for any dam-

ages caused by failure to observe these instructions.

• Do not use the appliance until it has been correctly installed and unless it is

in perfect working order.

• Do not remove the front cover under any circumstances before switching off

the mains electrical supply to the unit.

• Never make technical modifications, either to the appliance itself or the

electrical leads and water pipes.

• The appliance must be earthed at all times.

• Pay attention to the fact that water temperatures in excess of approx. 43 °C

are perceived as hot, especially by children, and may cause a feeling of

burning. Please note that the fittings and taps may be very hot when the

appliance has been in use for some time.

• The appliance is only suitable for domestic use and similar applications

inside closed rooms, and must only be used to heat incoming water from

the mains supply.

• The appliance must never be exposed to frost.

• The values stated on the rating plate must be observed.

• In case of malfunction, disconnect the fuses immediately. In case of leaks,

cut off the mains water supply instantly. Repairs must only be carried out by

the customer service department or an authorised professional.

• This appliance can be used by children aged 3years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or instruction concern-

ing use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and user maintenance

shall not be performed by children without supervision.

• If the appliance is factory equipped with a power supply cable, it must be

replaced with an original spare cable from the manufacturer in case of dam-

Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036

To observe additionally for pressureless installation:

• The water outlet behind the devices must not be blocked, and the water

flow must not be restricted.

• The water outlet facilities, such as jet control and other outlet unit, must be

decalcified regularly. Deposits must be removed in regular intervals.

• Only the fittings recommended by the manufacturer may be used.

age by an authorised technician in order to avoid any hazards.

• For appliances with direct connection, an all-pole disconnecting device

with a contact opening width of ≥3 mm per phase must be provided at the

installation end, according to Australian wiring rules AS/NZ3000.

• The wall bracket must be secured with the supplied screws and dowels. The

appliance must be secured to the wall bracket. The appliance may only be

operated if it has been properly mounted on the wall bracket.

• The prescribed nominal pressure stated on the rating plate may not be

exceeded at any time.

• The required water resistance may not fall below the value stated on the

rating plate at any time.

1. Safety instructions

• This appliance is not suitable for hot water supply to showers.

Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036

2. Overview

When ordering spare parts, please always specify the appliance model and serial number.

Parts in Bold Type are available as Spare Parts. Other parts are available on request

Pos. Part.-No. Description

6 93184 MCX complete fixing set (wall bracket with

screws and dowels)

7 99407 Temperature sensor (polarity protection)

not shown:

MCX 3 mains cable with earthed plug, cable

seal and strain relief

MCX 4 mains cable (without plug), cable seal

and strain relief

MCX 6 mains cable (without plug), cable seal

and strain relief

MCX set of small spare parts (seals, nozzle

for cable entry, terminal, installation grease,

screws, wheel nut & discs)

99430 Aerator / flow restrictor

Pos. Part.-No. Description

1 MCX cover with control panel

2 99403 MCX heating cartridge 3.5 kW /230V

99404 MCX heating cartridge 4.4 kW /230V

99405 MCX heating cartridge 5.7 kW /230V

3 MCX Safety temperature limiter (STB) with

modification instructions, contact fitting,

seals etc.

• 2-pole

• 1-pole

4 99406 MCX Filter

MCX water connector-set with two water

connectors and seals (mounted and greased)

fastening safety earthing terminal and filter

Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036

3. Technical data

The Zip instantaneous water heaters are compact electronically controlled water heaters. It is intended to provide economical heat-

ing of water for a wash basin when installed together with a sanitary water fitting. When the hot-water tap is opened, the heater

switches itself on automatically when the minimum water flow rate is exceeded and heats the water as it passes through the appli-

ance.

There are 3 available temperature settings, 35°C, 38 °C and 45 °C.

For best performance, always fit the special flow controller included with the appliance. This controller is inserted into the outlet at

the end of the tap and fits into any standard sleeve size M 22/24.

The maximum possible outlet temperature is determined by the temperature of the incoming water, the rate of flow and the heating

power of the appliance.

This appliances deliver water not exceeding 50°C in accordance with AS3498.

4. Description of the appliance

Model MCX 3 MCX 4 MCX 6

Part no. 27300 27400 27600

Energy efficiency class A *)

Capacity Liter 0.2

Nominal pressure MPa (bar) 1 (10)

Connecting type pressure resistant / pressureless

Heating system Bare wire heating system IES®

Required water resistance

at 15 °C in Ω cm ≥ 1100 ≥ 800 ≥ 800

Electric supply 1~ / N / PE 220 – 240 V AC

Nominal power rating 3,5 kW 4,4 kW 5,7 kW

Nominal current 15 A 19 A 25 A

Temperature choice 35 °C – 38 °C – 45 °C

Factory temperature setting 38 °C

Maximum inlet temperature 70 °C

Factory flow setting at 3 bar 2,0 l/min 2,5 l/min 3,3 l/min

Maximum temperature

increase at rated power and

a flow rate of…

2,0 l/min 25 K 31 K 41 K

2,5 l/min 20 K 25 K 33 K

3,0 l/min 17 K 21 K 27 K

3,5 l/min 14 K 18 K 23 K

4,0 l/min 12 K 16 K 20 K

Requiredl/min to switch on l/min 1,2 1,5 1,5

Requiredl/min to switch off l/min 1,0 1,3 1,3

Min. required cable size 2) see note 2)

Weight filled with water ca. 1.5 kg

Dimensions (H × W × D) 13.5 × 18.6 × 8.7 cm

Protection class acc. to VDE 1

Type of protection according to VDE IP 25

*) The declaration complies with the EU regulation No812/2013

1) Temperature rise (Kelvin) + cold-water temperature = maximum hot-water temperature (°C) ≤ 70°C

2) The cross sectional area of the connection cable must be in accordance with the power rating of the appliance and the specific requirements of AS/NZS 3000. The

cable size must not exceed 4 mm2

Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036

5. Typical installations

Unvented installation (closed

outlet) with tap for pressurised

appliances

Fit flow controller:

MCX 3/4: CSP 3

MCX 6/7: CSP 6

Electrical connection with

mains power cable (shorten

if necessary)

Angle valve approx. 550

Top edge of wash basin approx. 850

Axis wall bracket approx. 520

Cable entry approx. 553

Angle valve G⅜"

Dimensions in mm

Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036

6. Operation

Temperature setting

The touch key allows you to select one of the three preset temperatures.

Every key press sets the temperature to the next level:

35 °C 38 °C 45 °C (max.)

Press the key once again starts the cycle all over.

The current selected temperature is indicated by one of three coloured LEDs.

Key lock and temperature lock

The current selected temperature setting can be locked against unintended alteration. Thus, the temperature cannot be changed by

a single keypress anymore.

Activate keylock / Deactivate keylock:

Press and hold touch key for approx. 5seconds until the active LED goes out, then release the touch key.

Three coloured LEDs

Touch key

Additional features

As the control panel’s energy saving feature, the active LED turns off automatically about 20seconds after the last operation (e.g.

tapping or temperature selection).

To identify the selected setting at any time, the LED can be enabled permanently and the LED standby function will then be disabled

with the following procedure:

• Close tap (water stop).

• Keep sensor key touched permanently for more than 7seconds. Due to the keylock function the LED always goes out after 5sec-

onds for about 1.5seconds and lights up again.

• While still holding down the key, open the tap now, the LED will go out shortly as confirmation.

• Then release the touch key and close tap (water stop).

If the tap is opened or the touch key is used in LED standby mode (LED off), the last active LED lights up (wake up), but the tempera-

ture setting will not change yet. Only when pressed once again, the temperature setting will be adjusted.

The LED Standby function can be activated in the same way again.

NB:

This function is retained even after power failure.

Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036

7. Cleaning and Maintenance

• The appliance and the fittings should only be cleaned with a damp cloth. Do not use

abrasive or chlorine-based cleaning agents or solvents.

• Keep the control panel area dry!

• Clean the flow controller or the hand-shower regularly and replace as necessary.

• Dirt and scale deposited in the pipes and heater will affect the function of the

heater. Typical indications include reduced rate of flow or noisy flow. In such cases,

have the heater inspected by a technician and, if necessary, have the filter in the

cold-water inlet cleaned.

Instructions for user - MCX - 801052 - January 2020 v1.20 Art.no: 9120-15036

8. Troubleshooting and service

Repairs must only be carried out by

authorised professionals.

If a fault in your appliance cannot be

rectified with the aid of this table,

please contact the service organisa-

tion of your importer or the Central

Customer Service Department. Please

have the details of the typeplate at

hand.

This instantaneous water heater was manufactured conscientiously and checked sev-

eral times before delivery. First attempt to switch the house fuses off and on again in

order to reset the electronics. Next, try to remedy the problem with reference to the

following table. In doing so, you will avoid unnecessary expense of customer service

assistance.

Fault Cause Action

No water flows Water supply is turned off Open the main water valve and the

shut-off valve

Water flows

more slowly than

expected

The flow controller is not

fitted Fit the special flow controller

Water pressure is not suf-

ficient

Check the water flow pressure or

let check the water flow adjust-

ment by an authorized technician

Dirt in the pipes

Remove any dirt from the filter,

valves and taps / check the techni-

cal data

The heater switch-

es itself on and off

Water pressure is varying,

flow rate is too low

Remove any dirt / increase the flow

water pressure, close other taps,

open the shut-off valve further

Water remains

cold

Water pressure is not suf-

ficient

Let adjust the water flow by an

authorized technician, open the

shut-off valve, fit the special flow

controller, check water pressure

Dirt Remove dirt from the inlet and

outlet

Hot water tem-

perature varies

Supply voltage varies Check the supply voltage

Water connections mixed

up Check installation

Hot water tempe-

rature too low and

one LED flashes

slowly

Flow rate is too high or

inlet temperature is too

low

Adjust the flow either at the tap,

the valve or have the flow adjusted

by a authorized technician

One LED flashes

rapidly and water

remains cold

Defective temperature

sensor

Replace temperature sensor

(authorized technician)

Defective heating ele-

ment

Replace heating element (author-

ized technician)

All LEDs flash

rapidly and water

gets warm

Defective control panel

cable

Reposition control panel connector

(authorized technician)

Replace control panel (authorized

technician)

All LEDs flash

rapidly and water

remains cold

Defective power unit Contact Zip customer service

LED turns off

shortly after key-

press

Keylock is active Deactivate keylock (see page 8)

Other manuals for MCX 3

This manual suits for next models

Table of contents

Popular Water Heater manuals by other brands

Kenmore

Kenmore 153.582400 Use & care guide

Applimo

Applimo Edel AIR Installation and operating instructions

STIEBEL ELTRON

STIEBEL ELTRON Eltronom SHU 5 S Operating and installation instructions

Toyotomi

Toyotomi Oil Miser OM-180 installation manual

Bradford White

Bradford White EF Series Service manual

Eccotemp

Eccotemp 40-H Use & care manual

Dimplex

Dimplex ECSd125-580 Installation and user instructions

Dux

Dux 32FCR6N installation manual

Toyotomi

Toyotomi Oil Miser OM-148 (Type D) Operation and maintenance instructions

Noritz

Noritz N-132M Owner's guide and installation manual

TESY

TESY GCV7/4S 10047 Instructions for use and maintenance

A.O. Smith

A.O. Smith Gphe 50 instruction manual

Koryo

Koryo KWHZF15Y user manual

Pentair

Pentair PSC-14-4-02 Installation and operation manual

GE 40M06AAG Energy guide

Thermor

Thermor AEROMAX SPLIT 2 Instructions for use

American Hometec

American Hometec AHQ-B03X Installation and operation manual

PVI

PVI MAXIM Specifications

clage MCX 3 User manual

Popular Water Heater manuals by other brands
