Citronic CU-POD2 User manual
CU-POD2
Item ref: 173.634UK
USB Podcast Microphone & Stand
User Manual
Setting up
Mount the CU-POD2 to the supplied angle-adjustable
holder by rotating it onto the Mounting Thread at the
base of the microphone, surrounding the USB socket.
This holder clamps onto the supplied mini tripod
stand for tabletop use.
Connect the supplied USB lead to the type B Socket
at the base of the microphone housing and the other
end to an available USB port on a PC or Mac
computer.
The computer will recognise the CU-POD2 as a “USB
PnP Sound Device”in the sound or audio settings.
When connected, the blue LED at the front of the microphone will light to indicate that power is present
(this LED flashes when it is sending digital audio to the computer)
Operation
Selecting the CU-POD2 (“USB PnP Sound Device”) as the input device within the recording or streaming
software will set the microphone as the input source.
Turning the front mounted VOLUME control clockwise will increase the output level of the microphone to
the computer and turning it down will decrease the level.
The CU-POD2 can be disconnected and re-connected to USB as a hot-swappable device.
Disconnect from USB after use to preserve the computer battery or power supply.
173.634UK User Manual
Specifications
Capsule
16mmØ back electret
Polar pattern
Cardioid
Connection
USB type B (power & digital audio)
Lead length
1.5m
Frequency response
20Hz - 20kHz
Sampling format
16-bit
Sample rate
44.1kHz or 48kHz
Controls
Volume rotary
S/N ratio
78dB
Sensitivity
-34dB (±2dB)
Dimensions
137 x 48 x 44mm (microphone only)
Weight
148g (microphone only)
Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as
Electrical or Electronic equipment and should not be disposed with other household or commercial waste
at the end of its useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted. Copyright© 2022. AVSL Group Ltd.
Unit 2-4 Bridgewater Park, Taylor Rd. Manchester. M41 7JQ
AVSL (EUROPE) Ltd, Unit 3D North Point House, North Point Business Park, New Mallow Road, Cork, Ireland
