CITROEN C6 2007 User manual

IN BRIEF

E X T E R I O R

113

Glass sun roof

The sun roof provides you with improved ventilation and brightness in the

passenger compartment.

Piloted Deﬂ ector

This deﬂ ector enhances

the aerodynamics and the

braking of your vehicle.

Parking assistance (dis-

play and sound)

This function warns you, whilst

manoeuvring, by detecting

obstacles located in front of and

behind the vehicle.

Lane Departure Warning

System

This driving assistance device

warns you when you unwittingly

cross a lane marking.

The Xenon dual-function

directional headlamps

This additional lighting automati-

cally provides you with enhanced

visibility on bends.

Tyre deﬂ ation detection

This function monitors the pressure of

each tyre and warns you of tyres that

are punctured or deﬂ ated.

IN BRIEF

.Key release / storage.

.Locking of the vehicle.

.Unlocking of the vehicle.

Guide-me-home lighting.

Manual dipstick.

Screen wash and headlamp

wash ﬂ uid.

.Power steering and suspension

oil.

.Engine coolant.

. Engine oil.

. Brake ﬂ uid.

. Air ﬁ lter.

Poles “+” and “-” for starting

with a slave battery.

See “Starting with a slave battery”.

Press on button

to the left of the

dashboard to open the fuel ﬁ ller

ﬂ ap.

Opening and attaching the fuel

cap

REMOTE CONTROL KEY

UNDER THE BONNET

FUEL TANK

132

148

Tank capacity: approxi-

mately 72 litres

O P E N I N G

IN BRIEF

This can be unlocked, vehicle

stopped:

With

either the remote control

or the key.

Using

the interior central unlock-

ing button, or simply by opening

a door.

From the outside, press on lever

•

Lift the boot ﬂ oor using the

strap

Anchor the strap on the roof of

the boot.

To remove the spare wheel,

detach the belt then push the

wheel forwards so as to be able

to lift it.

BOOT

SPARE WHEEL

Note:

The tools are to be found

in a protective holder inside the

spare wheel.

To close, lower the boot using the

gripping handle located on the inte-

rior boot trim.

Press ﬁ rmly shut.

156

O P E N I N G

IN BRIEF

HEAD RESTRAINTS

The rear head restraints have two

positions:

stowed position for when the

seat is not occupied.

deployed position to provide

passenger safety, by raising

them to their locking point.

To lower the head restraints, press

on the tab at the base.

•

The whole or just part of the benchseat can be folded. It is necessary to

remove the head restraints.

Seat cushion

Use the strap to lift the seat cushion, then rest it against the front seat back-

rests. When repositioning the seat cushion, make sure that the seat belt

buckles are correctly in place.

FOLDING REAR BENCHSEAT

Note:

The benchseat backrest can be folded in two sections. When you

reposition the backrest, make sure that it locks in place.

Backrest

Stow the head restraints.

Press the control

located at the end of the backrest and fully tilt for-

wards.

C O N F I G U R AT I O N

IN BRIEF

36-38

114

INTERIOR

Audio and communication sys-

tems

This equipment utilises the latest tech-

nology: MP3 compatible RD4 radio,

RT3 hands free kit, Bluetooth

RD4 radio,

tele-

phone radio with navigation, JBL au-

dio system.

Speed limiter

This driving assistance device allows

you to select a maximum speed that

you do not wish to exceed.

Cruise control

This system allows you to automati-

cally maintain the vehicle speed at the

value programmed by the driver, with-

out the need to press the accelerator.

The automatic gearbox

This device provides you with optimum

driving conditions by combining a fully

automatic mode, along with two spe-

ciﬁ c programmes, as well as a manual

mode.

Automatic air condition-

ing

This air conditioning system

ensures comfort and a suf-

ﬁ cient circulation of air in the

cabin.

Electric parking brake

The electric parking brake combines automatic locking when the engine

is stopped, and automatic unlocking when accelerating (devices acti-

vated by default).

Note:

Manual locking/unlocking is possible.

Head-up display

This device projects a range of impor-

tant information into the driver's ﬁ eld of

vision. In this way, the driver does not

need to take his eyes off the road.

IN BRIEF

Head-up display cavity

Steering column adjustment

Controls - Lighting / Direction indicators / Rear foglamps /

Voice recognition

Instrument panel

Horn

Controls - Wipers

Front passenger's airbag deactivation

Driver's seat adjustment controls and memories

Controls - Windows / Rear view mirrors / Child safety

10.

Driver's airbag

11.

Controls at the steering wheel - Speed limiter and Cruise

control

12.

Electric parking brake

13.

Suspension controls - Ground clearance adjustment/

Sport mode

14.

Automatic gearbox SPORT/SNOW mode controls

15.

Head-up display controls

16.

Oddments tray

17.

Fuel ﬂ ap control

18.

Ignition switch

19.

Controls - Radio controls under the steering wheel

D A S H B O A R D

IN BRIEF

20.

Passenger's airbag

21.

Sunlight sensor

22.

Multifunction display

23.

Central air vents

24.

RD4 radio or RT3 NaviDrive

25.

Controls - Lane Departure Warning System / Anti-

intrusion alarm

26.

Gear lever

27.

Hazard lamps button

28.

Ashtray

29.

Controls - Electronic stability programme (ESP/

ASR) / Central locking of doors and boot / Parking

assistance

30.

Air conditioning controls

31.

Cup-holder

32.

Glovebox / Vehicle document storage / Fusebox

access ﬂ ap / Audio-video sockets

33.

Lateral air vent

34.

Bonnet release

D A S H B O A R D

IN BRIEF

FRONT SEATS

.Adjustment of the backrest

angle.

.Adjustment of the backrest lum-

bar support.

. Seat height and slide adjust-

ments.

. Adjustment of the seat cushion

angle.

.Memorisation of dashboard

adjustments:

- Driver's seat.

- Steering wheel.

- Exterior rear view mirrors.

- Head-up display.

You have the possibility to mem-

orise

two driving positions

using buttons

and

ELECTRICAL ADJUST-

MENTS

While the vehicle is stationary,

unlock the steering wheel by push-

ing the lever forward.

Adjust the height and the reach

of the steering wheel, then lock

the position by pulling the lever

upwards.

MANUAL STEERING COL-

UMN ADJUSTMENT

.Adjustment of the backrest

angle.

.Controls for the heated seats.

G E T T I N G S TA RT E D

IN BRIEF

While the vehicle is stationary,

adjust the height or the reach of

the steering wheel by moving the

control:

forward

or rearward to adjust

the reach,

or down to adjust the

height.

•

The

correct positioning

of the belt

strap is

through the middle of the

shoulder

. See “Seat belts”.

To adjust the seat belt for height,

compress the control and

slide

in the desired direction.

ELECTRIC STEERING

COLUMN ADJUSTMENT

SEAT BELT HEIGHTADJUST-

MENT

REAR VIEW MIRRORS

The steering wheel adjustment

is memorised with the driving

position. (See “Memorisation”).

These provide an automatic and

progressive change between day

use and night use.

Operation

Switch on the ignition and press

button

Warning

lamp

on: automatic

mode.

Warning

lamp

off: automatic

mode stopped. The mirror

remains in its lightest deﬁ nition.

•

G E T T I N G S TA RT E D

IN BRIEF

113

GLASS SUN ROOF

. Driver's electric window control.

. Passenger's electric window

control.

. Right-hand rear electric window

control.

Left-hand rear electric window

control.

. Deactivation control for rear

electric windows and rear door

opening from inside.

. Selection of rear view mirror:

- Left hand side.

- Right hand side.

- Folded / Automatic deploy-

ment.

Mirror directional control.

ELECTRIC EXTERIOR REAR

VIEW MIRRORS

ELECTRIC WINDOWS CON-

TROL

The sun roof is operated by the

electrical control

An action to the ﬁ rst notch of the

control starts a movement which

stops as soon as you release the

control.

An action to the second notch of

the control opens or closes the sun

roof fully. A further action stops the

movement.

G E T T I N G S TA RT E D
