Citizen 0S00 User manual

< Time Standard >

e of

uartz: Tunin

fork t

uartz cr

sta

Frequency : 32,768Hz

Accurac

: ±20 second / month worn under normal circumstances

Minute hand Max. 0.4 μN.m

Center Chrono Second hand Max. 0.11 μN.m

Other small hands Max. 0.02 μN.m

< Function >

Chronograph 1/1 sec. basis (Up to 11 hour. 59 min. 59 sec.)

Powercell Saving Reset Mechanism(PSRM)

Over-loading Compensation Device(OLCD)

Digital Frequency Control(DFC) for time adjustmen

SILVER OXIDE SR927W or equivalent

Φ29.0mm

5.10mm

Battery

Battery Life Approx.5years

* 1 hour chronograph operation per day

Date

Day ○

○

Φ30.8mm

Cal. 0S00

DAY/DATE CHRONOGRAP

0S00

13 1/2'''

Calibre

Case fitting diameter

Total height

Ligne

Overall diameter

Small

Second Hand

Chronograph

Minute Hand

(Small one)

1. Basic Specification

Chronograph

Hour Hand

Chronograph

Second Hand

(Long one)

* Measurement of time rate

The unit(gate) time of measurement must be set at "10 sec." or integer fold value of 10 sec. Owing to

the DFC system, and the measurement must be performed in the form of complete watch.

* Marking on movement

JAPAN

MIYOTA CO.

0S00

NO JEWELS

* Typical clearance

Mov't - Casebac

minimum 150 microns

Top of hands - Glass 300 - 400 microns *

* subject to the glass, case structure, and the length of hand

Thread Ф0.9mm×8.50mm

Setting stem

eng

rom movemen

center to far end of

settin

stem

065- 453 ×1

23.00mm

2. Separated Parts

3. Others

【

Displays and Button

】

A) SETTING THE TIM

1. Pull the crown out to the 2nd Click Position.

2. Turn the crown to set hour and minute hands.

3. After the time has been set, push the crown back to the Normal position.

B) SETTING THE DATE

1. Pull the crown out to the 1st Click Position.

2. Turn the crown anti-clockwise to set the date.

* If the date is set between the hours of around 9:00 PM and 1:00 AM, the date may not change o

the following day.

3. After the date has been set, push the crown back to the Normal position.

C) SETTING THE DA

1. Pull the crown out to the 1st Click Position.

2. Turn the crown clockwise to set the day.

* If the day is set between the hours of around 11:15 PM and 6:00 AM, the day may not change o

the following day.

3. After the day has been set, push the crown back to the Normal position.

D) USING THE CHRONOGRAPH

This chronograph is able to measure and display time in 1/1 second united up to

maximum 11 hour, 59 minutes and 59 seconds.

【Measuring time with the chronograph】

1. Press button " A " to start the chronograph.

2. The chronograph can be started and stopped each time button "A" is pressed.

3. Pressing button "B" resets the chronograph and chronograph hands return to their

Zero positions.

4. Instruction Manual

Reset Time

Measurement Stop

"A"

"B"

"A"

Normal Position

1st Click Position

Button B

2nd Click Position

Small

Second Hand

Chronograph

Hour Hand

Chronograph

Second Hand

(Long one)

Button A

Chronograph

Minute Hand

(Small one)

Date Disc

Day Disc

"B"

E) CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY

)

This procedure shoud be performed when the chronograph second hand does not return to the Zero

position.

1. Pull the crown out to the 2nd Click Position.

2. Press the button "A" once to set the chronograph second hand to the Zero position.

* The chronograph hour and minutes hands are syncronized with chronograph second hand

* The chronograph second hand can be advanced one scale by pressing button "A" once

* The chronograph second hand can be advanced rapidly by continuously pressing button "A"

3. Once the hands been zeroed, reset the time and return the crown to its normal position

* Do not return crown to normal position while chronograph second hand

return to 12:00 (ZERO) position.

Hand stops on the way when crown are returned to normal position and these

positions are recognized as 12:00 (ZERO) position.

These s

ecifications mi

ht be chan

ed without

rior notice

0S10 0S20 0S11 0S21 0S00

13 ½’’’

Size

<ligne>

Height

<mm> 4.13

Accuracy

<per Month> ±20 sec

500 pcs

Original

Package

Clearance

Movement

0.3-0.4mm

0.15mm

Hand

case

5 years

*60 minutes chronograph operation per day

Battery

Life

Battery consumption could be minimum

by pulling out the stem (=Power-Saving)

Minute 0.40

Second 0.11

Small 0.02

Balance

Weight

<μN.m>

Featured by Shock Detection

Φ30.8

Pusher

SR927W

Attached

Stem

065-543

24 Hour

Chronograph

Minute

0S200S10

0S11

0S00

0S21

Date

SUN

Day

12 SUN 7

12 7

Center

Chronograph

Hour

Reset the chronograph

DO NOT set Day and Date

between 9:00pm –1:00am

Setting the Date

Push “A”

Start and Stop the chronograph

Push “B”

Setting the Time

Set CHRONOGRAPH hands to reset

Push A to reset the hands position to the ZERO position,

And continue to push A to put them forward

Small Second

High Hand Ver.

0S1A

0S2A

0S2B

***** CAL.

0S00

MOV'T PARTS LIST *****

ORIGINAL PARTS, MADE IN JAPAN

PART NAME

0S00

BATTERY

280-4400

BATTERY CONNECTOR SPRING

231-345

CALENDAR CORRECTOR LEVER

116-994

CALENDAR CORRECTOR WHEEL

213-380

CALENDAR PLATE

714-075

CANNON PINION WITH DRIVING WHEEL

028-295

CENTER WHEEL COCK

711-163

CHRONOGRAPH COIL NIT 1

246-148

CL TCH WHEEL

064-670

COIL NIT

246-147

DATE DIAL

108-L0XX

DATE DIAL DRIVING WHEEL

103-A14

DATE DIAL G ARD

293-A20

DATE J MPER

109-580

DAY DIAL

308-B8XX

DAY DIAL G ARD

117-359

ELECTRIC CIRC IT NIT

279-J17

FIFTH WHEEL AND PINION

084-640

FLY-BACK CONNECTION LEVER

260-116

FLY-BACK LEVER

270-060

FORTH WHEEL AND PINION

023-267

HO R RECORDING WHEEL

294-808

HO R WHEEL

075-A71

INTERMEDIATE DATE CORRECTING WHEEL

087-620

INTERMEDIATE HO R-RECORDING WHEEL 1

087-135

INTERMEDIATE HO R-RECORDING WHEEL 2

087-136

INTERMEDIATE HO R-RECORDING WHEEL 3

087-137

INTERMEDIATE MIN TE WHEEL

087-138

INTERMEDIATE MIN TE-RECORDIMG WHEEL

087-134

INTERMEDIATE SECOND-RECORDIMG WHEEL

087-221

MIN TE RECORDING WHEEL

291-216

MIN TE WHEEL AND PINION

072-114

ROTOR

285-223

ROTOR FOR CHRONOGRAPH

285-224

SCREW FOR CENTER WHEEL COCK (X3)

923-980

SCREW FOR CHRONOGRAPH COIL NIT 1

923-990

SCREW FOR CHRONOGRAPH G RD(X4)

923-980

SCREW FOR COIL NIT

923-990

SCREW FOR DATE DIAL G ARD 1 (X2)

929-650

SCREW FOR DATE DIAL G ARD 2

922-A02

SCREW FOR DAY DIAL G ARD

929-814

SCREW FOR ELECTRIC CIRC IT (X2)

923-990

SCREW FOR TRAIN WHEEL BRIDGE (X3)

923-980

SECOND CHRONOGRAPH WHEEL

251-180

SECOND WHEEL

025-114

SETTING LEVER

067-993

SETTING STEM

065-453

SETTING WHEEL

076-680

SPACER FOR ELECTRIC CIRC IT 1 (X2)

027-111

SPACER FOR ELECTRIC CIRC IT 2

027-112

SPACER FOR SETTING STEM

212-A54

STATOR

190-126

STATOR FOR CHRONOGRAPH

190-128

STOP LEVER

204-530

S PPORTER FOR PLATE COMPLETE

226-497

S PPORTOR FOR CHRONOGRAPH PLATE

720-969

THIRD WHEEL AND PINION

017-142

TRAIN WHEEL BRIDGE

701-E92

YOKE

071-128

LONG SETTING STEM(24.00MM the length of thread:10mm)

065-557

LONG SETTING STEM(24.00MM the length of thread:5.3mm)

(065-553)
